Relay Control Setting - PureTools PT-C-HDCEC User Manual

User Manual
PT-C-HDCEC
Command
IRSEND[X].
IRDLY:[XXX].
IRPCS[X].
IROFFDLY:[XX].
GIRDLY.
GIRPCS.
GIROFFINT.

Relay Control Setting

6.1.6
Command
RELAY1DLY:[XXX].
RELAY2DLY:[XXX].
GRELAY1COT.
GRELAY2COT.
Function
Send the learned IR command.
X Description
0 SEND IR DISPLAY OFF
1 SEND IR DISPLAY ON
2 SEND IR USER
Set the sending interval time between IR
ON and IR USER to XXX (default 3s, range
of 1S to 180s).
Set the sending number of IR OFF to X.
X Description
0 1 time
1 2 times
Set the two times sending interval time
of IR OFF to XX (default 2s, range of 1S
to 10s).
Report the sending interval time
between IR ON and IR USER.
Report the sending number of IR OFF.
Report the two times sending interval
time of IR OFF.
Function
Set the Relay 1 delay time to XXX
(default 10s, range of 3S to 180s).
Set the Relay 2 delay time to XXX
(default 10s, range of 3S to 180s).
Report Relay 1 delay time.
Report Relay 2 delay time.
Feedback Example
IRSEND0.
SEND IR DISPLAY OFF!
SET IR ON DELAY TIME [XXX]S
SET SEND IR OFF ONE TIME!
SET IR OFF SEND DELAY TIME
[XXX]S
SET IR ON DELAY TIME 3S
SELECT SEND IR OFF ONE TIME!
SET IR OFF SEND DELAY TIME 2S
Feedback Example
SET RELAY 1 TIME DELAY TIME
[XXX]S
SET RELAY 2 TIME DELAY TIME
[XXX]S
SET RELAY 1 TIME DELAY TIME 10S
SET RELAY 2 TIME DELAY TIME 10S
17
