- Page 1 SPECIFICATION, INSTALLATION AND OPERATION MANUAL READ ALL INSTRUCTIONS BEFORE USE Woodson Griddle Toaster Models: W.GDT65.15, W.GDT65.20, W.GDT75 A guide on the use, care and maintenance of your quality Woodson product Revision Date: 15/01/2020...
- Page 2 Page Intentionally Left Blank Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 1...
- Page 3 Your New Woodson Product � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �...
-
Page 4: Your New Woodson Product
Your New Woodson Product Thank you for choosing this quality Woodson product� All our products are designed and made to meet the needs of food service professionals� By using, caring for and maintaining your Woodson product according to these instructions, your Woodson product should give you many years of reliable service�... -
Page 5: General Information
Introduction Attention Carefully read this instruction booklet, as it contains important advice for safe installation, operation and maintenance� Keep this booklet on hand in a safe place for future reference by other operators or users� Disclaimer The manufacturer and distributor cannot be held responsible or liable for any injuries or damages of any kind occurred to persons, units or others, due to abuse and misuse of this unit in regards to installation, removal, operation, servicing or maintenance, or lack of conformity with the instructions indicated in this documentation�... -
Page 6: Installation
Installation Setting Up WARNING Improper installation, adjustments, alterations, service or maintenance can cause property damage, injury or death. Handling • Use suitable means to move the unit: e�g� - For smaller items use two people - For large items a fork lift, pallet trolley or similar (the forks should reach completely beneath the pallet) Unpacking •... -
Page 7: Electrical Connection
Installation Electrical Connection WARNING This unit must be installed in accordance with AS/NZS 60335.1 Information Aggregate electrical ratings of the Unit are expressed in kilowatts in this manual� Single Phase Units: Supplied with an appropriately rated plug and lead fi tted and be indicated as: •... -
Page 8: Specification
Specification General Drawing W.GDT65.15 / W.GDT65.20 Specifications Model W.GDT65.15 / W.GDT65.20 Height 344mm Width 540mm Depth 495mm Power 3.3kW / 4.3kW AMPS 15A plug & lead fitted / 20A plug & lead fitted Top View Side View Front View Due to continuous product research and development, the information contained herein is subject to change without notice. - Page 9 Specification W.GDT75 Specifications Model W.GDT75 Height 344mm Width 687mm Depth 643mm Power 6.6kW AMPS Top View Front View Side View Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 8...
-
Page 10: Electrical Diagram
Electrical Diagram W.GDT65.15 P/LIGHT THERMOSTAT T OP E LE ME NT - 10A P/LIGHT B OT T OM E LE ME NT - 5A SIMMERSTAT Due to continuous product research and development, the information contained herein is subject to change without notice. - Page 11 W.GDT65.20 P/LIGHT RELAY THERMOSTAT T OP E LE ME NT - 15A P/LIGHT B OT T OM E LE ME NT - 5A SIMMERSTAT Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 10...
- Page 12 W.GDT75 OPTION: THIS UNIT CAN BE 3Ø REMOVE BRIDGES B1 & B2 AS SHOWN CONNECTOR BLOCKS P/LIGHT RELAY THERMOSTAT T OP E LE ME NT - 10A T OP E LE ME NT - 10A P/LIGHT B OT T OM E LE ME NT - 5A B OT T OM E LE ME NT - 5A SIMMERSTAT Due to continuous product research and development,...
-
Page 13: Initial Start-Up & Operation
Operation Initial Start-up & Operation Control Panel Initial Start-up The hot plate is pre-greased� Exact cooking times and temperatures vary for different cooking conditions� When setting up equipment, the following steps must be followed: 1� Read the complete instruction manual before proceeding 2�... - Page 14 Operation Cleaning General Information • Threaded fasteners can loosen in service� Regular inspection and adjustment should be carried out as required • Cleaning is recommended for health and safety purposes and to prolong the life of the unit • Do NOT use abrasive pads or cleaners on the stainless steel or any other metal parts of the unit •...
-
Page 15: Cleaning Schedule
Operation Cleaning Schedule • Daily cleaning is required for Griddles, Griddle Toasters and external surfaces� This will help to maintain and prolong the efficiency of your unit • The unit should be cleaned at the end of each work day Materials Required •... -
Page 16: Troubleshooting
Operation Troubleshooting • If any faults/issues occur with the unit, follow the below troubleshooting procedures • If the troubleshooting procedures do not correct the problem, contact the Stoddart Service Department WARNING Technician tasks are only to be completed by qualified service people. - Page 17 Page Intentionally Left Blank Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 16...
- Page 18 Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 17...
- Page 19 Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 18...
- Page 20 Australia Service / Spare Parts Sales Tel: 1300 307 289 Tel: 1300 79 1954 Email: service@stoddart.com.au Email: sales@stoddart.com.au Email: spares@stoddart.com.au www.stoddart.com.au Australian Business Number: 16009690251 New Zealand Service / Spare Parts Sales Tel: 0800 935 714 Tel: 0800 79 1954 Email: service@stoddart.co.nz Email: sales@stoddart.co.nz Email: spares@stoddart.co.nz...
