Page 1 SteamRock II Premium SteamRock II Premium NC Steam Generator for Steam Rooms Installation Instructions for Retailers Made in Germany Druck-Nr.: 2902 5125 Stand: 01/2020...
Page 2: Documentation
Cross-reference to a page  Read instructions  Result of a step  Table title  Title of figure Revision history Date Version Description 1 Apr. 2020 01.00 First version of SteamRock II Premium Installation Instructions - SteamRock II Premium...
Page 3: Table Of Contents
Connecting the water supply line and drain outlet ..38 4.2.3 Mounting the steam pipe ............40 Installation work inside the cabin ............44 4.3.1 Inserting the steam pipe into the cabin and installing the steam outlet............45 4.3.2 Specifications for connecting cables........46 SteamRock II Premium - Installation Instructions...
Page 4 Programming of the cabin address ............90 Setting up a multi-cabin installation............. 90 7 Cleaning and servicing..................94 Regular maintenance.................. 94 Servicing the vaporiser tank..............95 Replacing the heating coils ..............106 Resetting the safety temperature limiter ..........107 Troubleshooting..................109 Installation Instructions - SteamRock II Premium...
Page 5 8 Disposal ........................111 9 General terms and conditions of service ..........112 SteamRock II Premium - Installation Instructions...
Page 6: General Safety Instructions
CAUTION Caution Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Notice Indicates a hazardous situation which, if not avoided, will result in damage to the unit. Installation Instructions - SteamRock II Premium...
Page 7: Mounting And Electrical Installation
 When refilling a container, ensure that descaler is not poured into the container for essence.  Never place containers with descaler close to other chemicals.  Never place other chemicals close to the container of descaler. SteamRock II Premium - Installation Instructions...
Page 8 Corrosive or heavy saline atmospheres damage the contacts in the control panel, in the relay box and in the sensors.  The control panel and sensors should not be installed in a cor- rosive or heavy saline atmosphere. Installation Instructions - SteamRock II Premium...
Page 9: Operator Instruction
 If the steam generator does not shut itself off, usage must be su- pervised at all times.  Inspect the steam room each time you start the system. SteamRock II Premium - Installation Instructions...
Page 10: Standards And Regulations
Electromagnetic compatibility – Requirements for household appliances, electric tools and similar apparatus – Part 1: Emission DIN EN 55014-2 Electromagnetic compatibility – Requirements for household appliances, electric tools and similar apparatus – Part 2: Immunity Installation Instructions - SteamRock II Premium...
Page 11: Identification
The SteamRock II Premium steam generator is available in the following models:  SteamRock II Premium: Steam generator incl. EmoTouch 3 control panel.  SteamRock II Premium NC: same as SteamRock II Premium but without control panel. Information about the unit 2.1.1 SteamRock II Premium and SteamRock II Premium NC Nameplate The nameplate is attached to the underside of the base of the housing.
Page 12  Storage temperature: 0°C to 60°C  The water must be potable. The water pressure must be between 2 and 8 bar. The installation wall must be able to support a total weight of max. 45 kg. Installation Instructions - SteamRock II Premium...
Page 13: Emotouch 3 Control Panel
The SteamRock II Premium is operated via the EmoTouch 3 control panel, which is included in the scope of delivery. The SteamRock II Premium NC is used in a multi-cabin installation and con- trolled by the corresponding control unit. SteamRock II Premium - Installation Instructions...
Page 14: Models
Depending on the size of the steam cabin, it is possible to install multiple steam generators for one cabin. A single EmoTouch 3 control panel is installed for controlling the steam generators. Up to 8 steam generators and/or sauna cabins can be controlled by the control panel. Installation Instructions - SteamRock II Premium...
Page 15: Water Hardness
0.14241 French degree 1 °f = 0.56029 0.70157 Russian degree 1 °rH = 0.140 0.176 0.251 0.146 0.025 CaCO (USA) 1 ppm = 0.056 0.07 0.01 mMol/l 1 mMol/l = 5.6077 7.0218 10.009 100.09 SteamRock II Premium - Installation Instructions...
Page 16: Description Of The Units
Description of the units Description of the units SteamRock II Premium The SteamRock II Premium is available with an output power range of 3 to 18 kW. This output capacity can operate steam rooms with a size of 3 m 18 m The vaporiser tank is surrounded by a housing.
Page 17 The message does not indicate which container is empty. If an essence container from a different manufacturer is used, the level is not checked. In this case, the connecting cables for the level probe should be jumped. SteamRock II Premium - Installation Instructions...
Page 18: Scope Of Delivery
Description of the units 3.1.1 Scope of delivery In addition to the SteamRock II Premium steam generator, the scope of delivery also includes the following: A 5 l descaler container with level sensor G 2 brass injection nozzles for essence B 0.5 m connecting hose for 3/8"-3/4"...
Page 19 10 m connecting cable for sauna bus (RJ12/RJ12) 94.5861 25 m connecting cable for sauna bus (RJ12/RJ12) 94.4647 50 m connecting cable for sauna bus (RJ12/RJ12) 94.4648 Power adaptor for extending the control panel's connecting 94.6671 cable to 50 m SteamRock II Premium - Installation Instructions...
Page 20: System Overview Without Housing Cover
D Water drain valve with actuator K Water supply for filling E Essence pumps L Water supply for rinsing F Base plate M Dosing pump for descaler G Relief valve N Safety temperature limiter  Steam generator Installation Instructions - SteamRock II Premium...
Page 21: System Overview With Circuit Board
G Connection terminal for light, fan(s) and optional outputs water level control,  61 H Safety temperature limiter with Reset button Mounting plate with holes for cable ties  Steam generator with circuit board (diagram) SteamRock II Premium - Installation Instructions...
Page 22: Connections On The Base Of The Housing
* The fitting for the line on the base plate and the plug have a guarantee seal. The guarantee is no longer valid if the seal is broken. All supply and return lines are fed through the housing floor and can be accessed from the outside. Installation Instructions - SteamRock II Premium...
Page 23: Connections On The Vaporiser Cover
The heating coils (G) colour-coded. The specially marked heating coil next to the safety temperature limiter (H) must be connected to output U1 (top position) on the circuit board. See 4.5.2 Main circuit board assignments,  60 SteamRock II Premium - Installation Instructions...
Page 24: Vaporiser Opened
See the chapter on 2.3 Models,  14. Furthermore, the steam pipe (D), the supply lines for the water (E, F), and the descaler and drain for excess pressure (G) are fixed to the cover. Installation Instructions - SteamRock II Premium...
Page 25: Emotouch 3
The connecting cables are routed through the back of the housing to the cir- cuit board. The housing for mounting in the wall is included in the scope of delivery. SteamRock II Premium - Installation Instructions...
Page 26: Control Panel Circuit Board
A Round cell battery CR2032 3V D RJ10 jacks for cabin connections 1–8 B Reset button (green LED) E Mounting plate C Memory card connection (type A jack) F Power adaptor connection  EmoTouch 3 circuit board Installation Instructions - SteamRock II Premium...
Page 27: Technical Data
Description of the units Technical data 3.3.1 SteamRock II Premium / SteamRock II Premium NC Dimensions (W x H x D) 670 x 460 x 350 mm Weight 28 kg (type 1 – 9 kW) / 30 kg (type 2 – 18 kW) Max.
Page 28: Emotouch 3
1 x connection for memory card (input/host, jack type A) Connection for power adapter 24 V DC Power supply Via steam generator. Power adapter 24 V DC for 25 m or more of cable Error display Text on the display Installation Instructions - SteamRock II Premium...
Page 29: Mounting
Mounting Mounting The following example shows where the SteamRock II Premium steam generator, the EmoTouch 3 control panel and the steam room can be installed in relation to one another. Utility room Steam room A Temperature sensor E Steam outlet...
Page 30: Steam Generator
Steam room requirements  Floor drain  Air extractor so that temperature control works properly Steam generator 4.1.1 Guidelines  Stable wall  Mains connection (as per technical data)  Water connection  Drain outlet Installation Instructions - SteamRock II Premium...
Page 31 Horizontal: 420 mm Vertical: 535 mm On the side to the left and right Min. 250 mm Min. 500 mm Bottom Approx. 1000 mm The space underneath the unit may not be occupied by other installations. SteamRock II Premium - Installation Instructions...
Page 32: Mounting The Steam Generator
Drill two (2) holes above and below. Distance between lower edge and the floor: min 1000 mm Distance to the ceiling: min. 550 mm Horizontal distance between drill holes: 420 mm Vertical distance between drill holes: 535 mm Installation Instructions - SteamRock II Premium...
Page 33 Lay the shipping plate with the vaporiser on a flat surface. Loosen the vaporiser from the shipping plate.  Remove the screws completely so that the vaporiser can be lifted from the shipping plate. SteamRock II Premium - Installation Instructions...
Page 34 Swing the housing cover carefully toward you and remove it upward.  It must be possible to move the cover's mounting brackets past the side of the metal housing. Loosen the screws from the vaporiser and remove the shipping plate. Installation Instructions - SteamRock II Premium...
Page 35 Tighten the top two screws so that the unit is mounted securely on the wall.  Position the housing cover in place only after the electrical connections and data lines have been mounted. See 4.8 Closing the housing,  72 SteamRock II Premium - Installation Instructions...
Page 36: Water And Steam Pipes
 The connection for the drain must be capable of withstanding a tem- perature up to 110°C. Installation Instructions - SteamRock II Premium...
Page 37  The steam pipe must gradually descend toward the steam outlet at a 1– 2° incline so that no condensate can collect in the pipeline. A siphon may be installed to remove condensate as needed. SteamRock II Premium - Installation Instructions...
Page 38: Connecting The Water Supply Line And Drain Outlet
The vaporiser tank is drained empty very quickly from this suction. This can cause serious overheating.  Use the supplied hose for the cold water supply. Installation Instructions - SteamRock II Premium...
Page 39  See  Correctly and incorrectly installed drain outlets for rinsing,  Run the drain pipe or hose to the drain or attach it to the waste water pipe. SteamRock II Premium - Installation Instructions...
Page 40: Mounting The Steam Pipe
 Connect the essence line so that it is not possible for conden- sate with essence to flow back into the vaporiser tank.  Connect the essence line as close to the steam emission nozzle/ cabin as possible. Installation Instructions - SteamRock II Premium...
Page 41  Connecting the steam pipe  As standard, steam emission runs downwards. The steam emission pipe can also be turned upward via the flexible joint at the vaporiser cover.  Rotate the steam pipe upwards,  42 SteamRock II Premium - Installation Instructions...
Page 42 Loosen the two screws on the base plate used to fix the steam pipe and pull the steam pipe out from the base plate. Rotate the steam pipe upwards and retighten the nut on the flexible joint. Installation Instructions - SteamRock II Premium...
Page 43 Route the steam pipe in the cabin up to the steam outlet.   Inserting the steam pipe into the wall of the cabin,  45 Insulate the steam supply. Next steps: 4.3 Installation work inside the cabin,  44 SteamRock II Premium - Installation Instructions...
Page 44: Installation Work Inside The Cabin
The position of the sensors may vary, e.g. the height at which they are mounted, depending on the layout of the cabin and its relevant compo- nents. The measurements in the figure are therefore intended as guide- lines only. Installation Instructions - SteamRock II Premium...
Page 45: Inserting The Steam Pipe Into The Cabin And Installing The Steam Outlet
 Steam pipe in the cabin Fix the steam pipe to the wall. Put the steam outlet in place and tighten by hand.  The steam emission outlet must face downward. Seal the wall duct with silicone. SteamRock II Premium - Installation Instructions...
Page 46: Specifications For Connecting Cables
14 mm  Drill to drill a hole in the wall: 18–20 mm, so that there is a distance of 2– 3 mm all around for the seal  Silicon for sealing and insulating Installation Instructions - SteamRock II Premium...
Page 47  The sensor must protrude from the cabin by approx. 30 mm. Plug in the data line and pull it through the provided empty pipe. Plug in the data line at the steam generator. Control line connection: 4.7.1 Connecting data lines,  68 SteamRock II Premium - Installation Instructions...
Page 48: Cabin Lighting
 The lighting must conform to protection class IP65 and be re- sistant to ambient temperatures.  Connect only dimmable light sources. Deprogramming the light output: 5.2.4 Defining the light source manually,  79 Control line connection: 4.6 Energy-supplied and switched consumers,  64 Installation Instructions - SteamRock II Premium...
Page 49: Fan
The supply line can short circuit if you use the mains connections L1, L2 or L3 to supply the electric circuit connected to the poten- tial-free contact.  Use the SteamRock II Premium mains connections only for the steam generator.  Do not connect additional devices to the SteamRock II Premium mains connections.
Page 50: Emotouch 3
Control line connection: 4.7.1 Connecting data lines,  68 EmoTouch 3 A Wall for installation C Housing base B Control panel with circuit board D Cable guide, mains supply, control lines  Installation diagram Installation Instructions - SteamRock II Premium...
Page 51: Guidelines
 Mount the control panel far enough away from the area where steam is emitted and can spread.  Mount the control panel on the hinge side of the door. Wall mounting min. 350 mm 189 mm  Installation dimensions for the control panel SteamRock II Premium - Installation Instructions...
Page 52 1.5 m from the installation location. The extension is attached to the side of the steam generator. This requires a coupling (RJ12/RJ12) and an extension cord with an RJ12 plug (optional accessory). Installation Instructions - SteamRock II Premium...
Page 53: Mounting The Control Panel
The control lines are connected to the control panel. Depending on the system installation, they lead to the cabin, to power units, and to the SteamRock II Premium. These control lines are fed through the bottom of the housing. Therefore, they must be installed once the cut in the wall has been made.
Page 54 After routing, pull the control lines through the opening in the housing.  Do not pull the control line too taut so that you can easily remove the control panel at a later time. Installation Instructions - SteamRock II Premium...
Page 55  The housing must sit firmly in the wall cut-out.  As an alternative to clips, the housing can also be fixed by using screws. Screw in screws in the holes on the 4 sides to fix the housing. SteamRock II Premium - Installation Instructions...
Page 56 Slide the ferrite ring onto the bridge on the mounting plate. Connect control lines to socket 1/2 using the RJ10 plugs.  EmoTouch 3 circuit board – jacks  Plug for multi-cabin connection, see 6.1 Configuration options,  83 Installation Instructions - SteamRock II Premium...
Page 57 Press the display carefully with a consistent amount of pressure into the housing until it audibly snaps into place. Remove the foil from the display.  For commissioning information, see 5.2 EmoTouch 3 – program settings,  74 SteamRock II Premium - Installation Instructions...
Page 58: Electrical Installation
Mounting Electrical installation 4.5.1 Main circuit diagram 9 kW/18 kW  SteamRock II Premium 9 kW Installation Instructions - SteamRock II Premium...
Page 59 Mounting  SteamRock II Premium 18 kW The main circuit diagrams are located on the inside of the housing. SteamRock II Premium - Installation Instructions...
Page 60: Main Circuit Board Assignments
J Fan 1, fan 2 E Sensor for cabin temperature K Potential-free outputs O Circuit 2 (9 kW) F Sensor for bench heating L Circuit 1 (9 kW) P Sensor for essence level Q Sensor for descaler level Installation Instructions - SteamRock II Premium...
Page 61: Add-On Board For Water Level Control
The water level is controlled by the add-on board. A Main circuit board (cut-out) C S-Bus for mains supply B Add-on board for water level D Connection for rod electrode Connection cable C is pre-mounted. SteamRock II Premium - Installation Instructions...
Page 62: Mains Connection
DIN EN 60335-1:2012-10:  For stationary class I heating appliances: 0.75 mA or 0.75 mA per kW rated power input of the heating unit, whichever is higher, up to a max- imum of 5 mA. Installation Instructions - SteamRock II Premium...
Page 63: Adjusting The Output
The guarantee is no longer valid if the seal is broken. 4.5.5 Adjusting the output The output of the SteamRock II Premium steam generator can be adjusted to change the effective steam volume and to accommodate the cabin size and situation.
Page 64: Energy-Supplied And Switched Consumers
 Bench heating Together with the appropriate sensor.  Potential-free contact for an additional device. The switching time is set in the control panel. See the operating instruc- tions.  Connecting a switched consumer,  66 Installation Instructions - SteamRock II Premium...
Page 65: Connecting A Consumer
This risk also applies following completion of the installation work.  Electrical installation must only be carried out by a qualified and licensed electrician.  The SteamRock II Premium housing may be opened only by a trained electrician.  Connecting the cabin lighting and fan(s) Feed the connection cable for the consumer through the base plate of the housing.
Page 66 See 5.2.4 Defining the light source manually,   Connecting a switched consumer Feed the connection cable for the switched consumer through the base plate of the housing.  Opening for connecting cables Installation Instructions - SteamRock II Premium...
Page 67 Mounting Connect cables to the corresponding clips on the main circuit board.  Main circuit board – connections for switched consumer Secure the line but ensure it is not pulled too tightly. SteamRock II Premium - Installation Instructions...
Page 68: Data Lines
Mounting Data lines The SteamRock II Premium is controlled by the EmoTouch 3 control panel. The steam generator is equipped with a main circuit board on which all connections for the components are located. Data lines are typically connected prior to commissioning. Additional lines can also be connected at a later time, after the cabin has been outfitted with additional components.
Page 69 C Neutral conductor to PE Connect lines to S1 and PE.  Connecting the temperature sensor Feed the data line for the temperature sensor through the base plate of the housing.  Openings for data lines SteamRock II Premium - Installation Instructions...
Page 70 Feed the control line from the control panel through the base plate of the steam generator.  See  Openings for data lines,  69 Plug the RJ14 plug in the S-Bus jack. S-BUS SENSOR SENSOR SENSOR SENSOR  Connection for control line Installation Instructions - SteamRock II Premium...
Page 71: Level Sensor For Essence (Optional Accessory)
 Connecting the level sensor for essence Connect the red, 2-core line to the clips for the level sensor on the es- sence container. A Line to the steam generator B Intermediary cable  Connection for 2 essence containers SteamRock II Premium - Installation Instructions...
Page 72: Closing The Housing
 Back panel of housing – slot for housing cover  If the steam supply has been fed upward, first cut out the pre- stamped outlet in the top of the housing cover before mounting it. Installation Instructions - SteamRock II Premium...
Page 73  Hanging the housing cover  It must be possible to move the mounting brackets past the side of the metal housing. Fix the housing cover with two screws on the rear wall.  Tighten the housing cover SteamRock II Premium - Installation Instructions...
Page 74: Commissioning
 Date and time are saved if the built-in battery is in working order. All other settings are saved permanently. Add-on modules or accessories are detected once the unit is switched on again and their corresponding icons appear on the main image or in the sub-menus. Installation Instructions - SteamRock II Premium...
Page 75: User Interface Icons
Texts are displayed in the following colours:  White: Status texts, e.g. date, name of sub-menu  Blue: active input digits, e.g. for date, time, timer display  Red: Warning, time display for auto-stop SteamRock II Premium - Installation Instructions...
Page 76: Switching On And Off
The control panel automatically switches to standby mode once connection to the steam generator has been established and it is connected to the mains supply. Choose to switch steam production (heating) on or off. Installation Instructions - SteamRock II Premium...
Page 77: Setup During Commissioning Or After A Reset
Set the time and confirm. Set the date and confirm. Specify and confirm the place of operation.  European Union/CENELEC must be selected if the system is installed in countries under the jurisdiction of the CENELEC. SteamRock II Premium - Installation Instructions...
Page 78  Next, you must select the skin for the cabin and set up the connected modules. Information about setting up the module can be found in each of the individual installation and operating instructions. Open skin selection by pressing Installation Instructions - SteamRock II Premium...
Page 79: Defining The Light Source Manually
Improper setup can damage the unit. In this case, the warranty be- comes void.  Work must only be performed by a trained technician from an authorised company specialised in the trade. For this setting, the lighting must be disconnected. SteamRock II Premium - Installation Instructions...
Page 80  Code 8002: Capacitive load. Disconnect the steam generator from the mains supply and reconnect the light source. Close the housing again.  4.8 Closing the housing,  72 Reconnect the steam generator to the power supply. Installation Instructions - SteamRock II Premium...
Page 81 Press and hold the light icon on the display for 3 seconds. 01. June 2019 18:45:40 Setting Light 100% 01. June 2019 12:45:40  The icon for the current lighting load setting is displayed. Check the setting on the display. SteamRock II Premium - Installation Instructions...
Page 82: Installing Multiple Cabins
3 kW 1,5 kW 1,5 kW 500 W 400V 3N 230V 1N STEAM SAUNA S-BUS S-BUS max. 9 kW max. 3 kW 400V 3N 400V 3N LSG-IR Infrared relay box Sauna heater Vaporiser Modules Installation Instructions - SteamRock II Premium...
Page 83: Configuration Options
 6.1.2 Configuration 2 – 1 steam room and 4 sauna cabins,  85.  6.1.3 Configuration 3 – 2 steam rooms,  86.  6.1.4 Configuration 4 – 2 steam rooms,  87. SteamRock II Premium - Installation Instructions...
Page 84: Configuring 1-8 Steam Rooms
All relay boxes are set by the factory to cabin address 1. See also the following figures:   Jacks – relay box for steam generator/relay box for sauna cabin and IR cabin,  88   Jacks – EmoTouch 3 circuit board,  88 Installation Instructions - SteamRock II Premium...
Page 85: Configuration 2 - 1 Steam Room And 4 Sauna Cabins
Optional See also the following figures:   Jacks – relay box for steam generator/relay box for sauna cabin and IR cabin,  88   Jacks – EmoTouch 3 circuit board,  88 SteamRock II Premium - Installation Instructions...
Page 86: Configuration 3 - 2 Steam Rooms
Optional See also the following figures:   Jacks – relay box for steam generator/relay box for sauna cabin and IR cabin,  88   Jacks – EmoTouch 3 circuit board,  88 Installation Instructions - SteamRock II Premium...
Page 87: Configuration 4 - 2 Steam Rooms
See also the figures for configuration 1:   Jacks – relay box for steam generator/relay box for sauna cabin and IR cabin,  88   Jacks – EmoTouch 3 circuit board,  88 SteamRock II Premium - Installation Instructions...
Page 88: Control Lines And Cabin Addresses
 Jacks – relay box for steam generator/relay box for sauna cabin and IR cabin The relay boxes for sauna cabins or IR cabins are described in detail in sepa- rate instructions.  Jacks – EmoTouch 3 circuit board Installation Instructions - SteamRock II Premium...
Page 89 The number corresponds to the cabin currently selected (not the number of connected cabins). SteamRock II Premium NC The SteamRock II Premium NC steam generator can be connected as fol- lows:  With line RJ12/RJ12 to the SteamRock II Premium relay box.
Page 90: Programming Of The Cabin Address
Installing multiple cabins Programming of the cabin address The SteamRock II Premium steam generator is programmed with cabin address 1 as delivered. To ensure that EmoTouch 3 detects multiple cabins, the cabin address must be changed to a different cabin address starting with cabin 2.
Page 91  The cabin address can be programmed once all lines have been plugged in, see  Programming addresses,  92. SteamRock II Premium - Installation Instructions...
Page 92 The red LED goes off and the green LED starts flashing. The new address is saved. Check if the new cabin is shown on the display.  In the status bar, the icon for multi-cabin operation appears: Installation Instructions - SteamRock II Premium...
Page 93   Mounting the housing cover,  72 Now you can make the settings for each cabin.  Defining the basic settings,  77 For information on cabin settings, see the separate operating instructions. SteamRock II Premium - Installation Instructions...
Page 94: Cleaning And Servicing
Cleaning and servicing Cleaning and servicing The SteamRock II Premium steam generator must be serviced and cleaned regularly. The frequency depends on how often it is used. The integrated cleaning and descaling system increases the service life of the steam gen- erator.
Page 95: Servicing The Vaporiser Tank
Improper installation poses a danger to life and limb from electri- cal currents. This risk exists also after installation work has been completed.  Before servicing the vaporiser tank, disconnect the connection to all power supplies. SteamRock II Premium - Installation Instructions...
Page 96  Remove the cover, if necessary, and manually clean the inside of the vaporiser tank.  Removing the cover from the vaporiser tank,  98  Check the water hardness if there are significant amounts of lime scale and install a water softening system, if needed. Installation Instructions - SteamRock II Premium...
Page 97 Clear the opening with a screwdriver and remove any lime residue. Use pliers to turn the ball valve to the CLOSED position. Push the actuator back into its original position and screw it tight. SteamRock II Premium - Installation Instructions...
Page 98 Cut-out of add-on board – disconnect rod electrode lines  See 4.5.2 Main circuit board assignments,  60 Unplug the connections from the heating coils.  Mark the lines so that you maintain the correct sequence when you plug them back in. Installation Instructions - SteamRock II Premium...
Page 99  The capillary tube may not be kinked, jammed, or damaged. The cap- illary tube sensor may not be damaged. Loosen the 2 hose clamps at the double valve and remove the flexible water supply lines.  Detach the water supply SteamRock II Premium - Installation Instructions...
Page 100 Cleaning and servicing Loosen the steam supply at the housing floor.  Loosen the steam supply Loosen the 2 screws for the steam pipe on the carrier plate.  Loosen the carrier plate Installation Instructions - SteamRock II Premium...
Page 101 NOTICE Put on the cover so it is in the right position, ensuring that the seal is not damaged when the screws are screwed in. Screw in the 6 hexagon socket screws on the top of the cover and tight- SteamRock II Premium - Installation Instructions...
Page 102 Cleaning and servicing Screw in the screws Re-tighten the steam pipe on the carrier plate with both screws.  Screw in the carrier plate Installation Instructions - SteamRock II Premium...
Page 103 Cleaning and servicing Connect the steam supply to the housing floor.  Screw on the steam supply Position the flexible water line in place and fix with the hose clamps.  Connect the water supply SteamRock II Premium - Installation Instructions...
Page 104 Plug in the lines for the heating coils (C) again.  Ensure that you plug in the lines in the correct sequence. The line for the colour-coded heating coil next to the capillary tube sensor must always be connected to connection U1. Installation Instructions - SteamRock II Premium...
Page 105 Diagram of circuit board (18 kW example) – connection U1 for colour-coded heating coil Insert the 2-core rod electrode connecting cable into the add-on board. Add-on board – insert rod electrode connecting cables Replace the housing cover.  See 4.8 Closing the housing,  72 SteamRock II Premium - Installation Instructions...
Page 106: Replacing The Heating Coils
Install the new heating coil and fix it tightly on the cover with the fixing nuts.  Ensure correct fit of the seal. The nuts must be tightened sufficiently so that no vapour can escape. Replace the cover.   Closing the vaporiser tank,  101 Installation Instructions - SteamRock II Premium...
Page 107: Resetting The Safety Temperature Limiter
 Rectify the reason for overheating.  Allow the steam generator to cool for approx. 30 minutes.  The Reset button should be operated only by qualified person- nel. SteamRock II Premium - Installation Instructions...
Page 108  If pressing lightly is insufficient, wait until the unit has cooled down further. Close the housing, see  Mounting the housing cover,  72 Restart the unit.  See 5.2.2 Switching on and off,  76 Installation Instructions - SteamRock II Premium...
Page 109: Troubleshooting
Cleaning and servicing Troubleshooting Error message and icons on the control panel indicate SteamRock II Premium steam generator operating statuses and fault conditions. In multi-cabin installations, the fault is displayed in the status bar as the icon. The cabin overview allows you to find and retrieve the cabin with the fault so you can access further details.
Page 110 Overheating in the water tank Rectify the reason for overheating. (Display error message) Caution: Allow the steam generator to cool at least 30 min. prior to resetting the safety temperature limiter. Press the Reset button. Installation Instructions - SteamRock II Premium...
Page 111 Do not dispose of the unit with household waste. Packaging SteamRock II Premium packaging can be completely separated for dis- posal and recycled. The following materials are used in the packaging:  Used paper ...
Page 112 In the case of a warranty claim, the manufacturer shall provide replace- ment parts necessary for servicing free of charge. IV. Service visit by the manufacturer Services rendered on site by an employee of the manufacturer must be agreed in advance. Installation Instructions - SteamRock II Premium...
Page 113 Complaints in respect of our products shall be reported to the responsible distributer and shall be handled exclusively by said distributer. SteamRock II Premium - Installation Instructions...
Page 114 General terms and conditions of service The manufacturer’s General Terms and Conditions of Business, in the ver- sion available at www.eos-sauna.com/agb, shall apply in addition to the foregoing terms and conditions of service. Installation Instructions - SteamRock II Premium...
Page 115 SteamRock II Premium - Installation Instructions...
