- Page 1 I N N O V A T I V E S A U N A T E C H N O L O G Y SteamRock Basic steam generator Installation and operation manual Made in Germany print no. 29344968 / 42.19 Subject to technical changes Version 09 | firmware R0.91...
-
Page 2: Table Of Contents
Checking the level sensor .................17 Water supply and drain ................18 Steam pipe connection ................18 Electrical connection ....................19 6.1 SteamRock Basic 18 kW terminals ..............19 6.2 SteamRock Basic 9 kW terminals ..............20 6.3 Inner wiring diagrams ................21-22 6.4 Connection to Emotouch II+ Steam.............23 6.5 Connection to Emotouch II+ Sauna, Emotec H, Econ H .......24... - Page 3 Introduction Dear customer Thank you very much for purchasing EOS sauna & steam equipment. You have purchased a mod- ern, technically advanced product which will provide you with years of reliable operation. EOS steam generators have been designed and tested to comply or exceed the currently applica- ble European safety norms and are produced in our factory in accordance with the quality man- agement norms DIN EN ISO 9001:2008.
-
Page 4: Manufacturer
Steam generator SteamRock Basic 1.4 Intended use The SteamRock Basic steam generator is intended for production of steam in steam rooms or sau- na rooms with humid operation. The SteamRock Basic requires an external control unit (e.g. Econ S2) which is not included in the scope of delivery. Third party control units may not be used with-... -
Page 5: Foreseeable Incorrect Use
1.5 Foreseeable incorrect use Following may be regarded as foreseeable incorrect use: • Steam room size does not match the steam generator power (incorrect power selection). • Operation without legally required safety and protection features. • Operation without proper knowledge of the safety advices (chapter 3). •... -
Page 6: Safety Advice
2. Safety advices DANGER Risk of fire and danger of electric shock. Risk of fire by incorrect installation. Make sure to have the steam generator installed only by an ap- • propriately qualified specialist according to the present instruction manual. All electrical connections in the steam generator and other equip- •... - Page 7 DANGER Risk of scalding. Hot steam may cause burns, scalding and dangerous to life injuries, if the steam generator has not been properly installed or is operated not as per its intended use. During planning and installation make sure, that the steam out- •...
- Page 8 WARNING Risk of burns through hot surfaces in the device. The steam generator has hot surfaces, e.g. pipelines, water tank, which may cause burns. Keep a secure distance to hot surfaces of the device. • ATTENTION So-called plasticizers are able to modify the water surface tension in the steam generator water tank.
-
Page 9: Specifications
3. Specifications Dimensions H x W x D [mm] 670 x 460 x 350 mm Weight [kg] 28 kg (type 1 - 9 kW) / 30 kg (type 2 - 18 kW) Water supply pressure [bar] 2 - 8 bar Operation pressure max. -
Page 10: Delivery Scope
4. Delivery scope SteamRock Basic delivery includes: • SteamRock steam generator • 4 mounting screws 5 x 35 • 4 dowels S6 • 2-part brass union 1 1/4“ to 35 mm • 0,5 m steel braided water supply hose 500 mm 3/8“ to 3/4“... -
Page 11: Installation
5. Installation 5.1 Installation overview * for temperature sensor installation de- tails please refer to the corresponding installation manual of the control unit... - Page 12 5.2 SteamRock Basic - construction overview Overpressure release valve view Sicht von with drain hose from top oben Water tank / water tank lid Water filling line (slow) Water filling line (fast) / pressurized water injection Descaler filling tube level sensor...
- Page 13 Water tank Overheating protection and insulation jacket Terminal block with colour coded terminals Main board Water supply tubes Fuse switches 9 kW - F1/F2/F3 18 kW - F1/F2/F3/F4/F5/F6 Dual-way water inlet valve Peristaltic pump for clean- ing / descaling system Thermofuse with manual reset button Solenoid valve for main...
-
Page 14: Mechanical Installation
5.4 Mechanical installation The SteamRock Basic is a wall-hanging device. It is mounted to the wall with 4 screws. Please en- sure that the wall is able to carry the load of min. 45 kg. We recommend to allow certain reserve for safety. - Page 15 Drill 4 mounting holes in the wall as shown on the template below. If necessary use the appropriate dowels to securely mount the screws in the drilled holes. At first screw in the two upper screws. As shown on the pic. 2. please make sure to leave 3 mm gap between the screw head and the wall surface.
-
Page 16: Opening Water Tank
5.5 Opening water tank The water tank can, if necessary, be opened in the following way: 1. Disconnect the generator from the power supply and turn off the water. Unplug 2-core cable from the level probe Loosen 6 allen screws at the main board. - Page 17 9. Put the cover on the vessel again. Make sure that the silicone seal ring fits on the mounting holes so that the Allen screws can be tightened. Also pay attention that the baffle plate on the bottom side of the cover will not be bended. Connect the steam pipeline back to the steam output con- nector on the steam generator.
-
Page 18: Water Supply And Drain
5.7 Water supply and drain connection Important Notice: Please observe the EN 1717 / DIN 1988 and DIN 1986 / EN 12056 4 requirements. It must be ensured that the water may not flow back into the water supply system. If necessary the additional equipment has to be installed to prevent the back-flow. -
Page 19: Steam Pipe Connection
5.8 Steam pipe connection • The steam pipe should be heat-resistant to at least 110°C. We recommend copper or stainless steel pipes with Ø35 mm. Do not use small diameter steam pipes! • The steam pipeline should be reclining towards the steam outlet. Sharp angles should be avoided. -
Page 20: Electrical Connection
PE - control unit Signal - output Signal - output Fragrance Fragrance PE - Fragrance Terminal diagram for SteamRock Basic with 18 kW, 400 V con- nection (3 x 32 A). Pic. 6 Connection terminals and power se- lection switches (18 kW model). -
Page 21: Steamrock Basic 18 Kw Terminals
6.2 SteamRock Basic 9 kW connection terminals Terminal Marking Description L1 phase mains connection L2 phase mains connection L3 phase mains connection PE power supply N - control unit S1 - control unit Steam on - control unit PE - control unit... -
Page 22: Inner Wiring Diagrams
6.3 SteamRock Basic inner wiring diagram SteamRock Basic 9 kW... - Page 23 SteamRock Basic 18 kW...
-
Page 24: Connection To Econ S2
6.4 SteamRock Basic connection to Econ S2 SteamRock Basic 9,0 kW (3 x 16 A) L1 L2 L3 N N N N N S1 Wb PE N A2 PE (Gr) (Gr) (Gr) Econ S2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 Übrige Anschlüsse gemäß... - Page 25 6.5 SteamRock Basic connection to EmoTouch 3 Sauna, Emotec H, Econ H SteamRock Basic 9,0 kW (3 x 16 A) L1 L2 L3 N N N N N S1 Wb PE N A2 (Gr) (Gr) (Gr) Emotec H / EmoTouch 3 / ECON H 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 Übrige Anschlüsse gemäß...
-
Page 26: Leakage Current
6.6 Leakage current Please make sure to observe the DIN EN 60335-1:2012-10 norm in respect to the leakage current. This norm requires that the leakage current may not exceed the following limits at the normal operating temperature: “For stationary class I heating appliances - 0,75 mA or 0,75 mA per kW rated power input of the heating appliance with a maximum of 5 mA, whichever is higher.”... -
Page 27: Cleaning System
Use only the suitable cleaner designed for descaling of water boiling equipment, dilute if necessary as specified by the manufacturer. The approved cleaner is availa- ble at EOS as an accessory. The warranty will be void by the use of an unsuitable and unapproved cleaner liquid. - Page 28 7.2 Functioning of the cleaning system SteamRock Basic steam generator features an integrated automatic descaling and draining system. This system will automatically descale the water tank at certain intervals. These intervals depend on the evaporated water quantity. They do not depend on the total “switched on” time which may have certain intervals without actual steam production.
- Page 29 8. Adjustment of the performance SteamRock Basic steam generators have a fast-tuning performance that can be adjusted to the cabin size in a few seconds on-site. The switching capacity is set by means of F-fuses (see Fig. 9) on the main terminal block.
- Page 30 Special attention is required for power increase. If you are unsure which power to select, start with a lower setting first. If necessary, contact EOS Customer Service. Risk of scalding! SteamRock Basic steam generators feature individually switchable heating elements...
-
Page 31: General Operation
The SteamRock Basic does not have an on / off switch. The device is permanently connected to the mains and is switched on and off by an external control by wiring the inputs WB, S1 and N. - Page 32 9.1 Resetting the thermo-fuse The thermo-fuse switches the heating off in the event of overheating in the vaporiser tank. To perform a restart after overheating, you must press the Reset button. CAUTION Risk of burns from hot parts The steam pipe on the base plate is very hot. Do not touch the steam pipe.
- Page 33 10. Cleaning and maintenance SteamRock Basic steam generators must be regularly maintained and cleaned according to the intensity of use. The built-in cleaning / descaling system increases service intervals and helps to significantly reduce the expenditure and costs of maintenance and service.
-
Page 34: Troubleshooting
11. Troubleshooting SteamRock Basic steam generator will display the operation states and common malfunctions by flashing of the main operation LED (pilot lamp) on the bottom housing of the unit (see page 12). The pilot lamp is off if the generator is off. During active heating the pilot lamp will illuminate continuously. - Page 35 Reason: Water supply blocked. Solution: Check water supply. Check if the filter mesh at the water supply connec- tor is blocked, clean if necessary. Reason: Water filling valve is blocked or faulty. Solution: Clean the valve (e.g. pressurized air) and make sure it is operational. Reason: Water level probe got stuck or is faulty.
- Page 36 2012/19/EU. Do not dispose it with the normal household waste. Service Address: EOS Saunatechnik GmbH Schneiderstriesch 1 35759 Driedorf, Germany Tel: +49 (0)2775 82-514 Fax: +49 (0)2775 82-431 servicecenter@eos-sauna.de...
-
Page 37: Warranty
The manufacturers General Terms and Conditions of Business, which can be found at www.eos-sauna.com/ V. Liability agb, shall apply in addition to the foregoing terms and conditions of service.
