Display Interface and Instructions
10
9
Button
1
Knob
4
XLR
7
Power input(DC/24V)
10
Note:
Please pay attention to the polarity when connecting the speakers, it must
follow the mark on the unit, to avoid any effect to the sound quality.
4
6
8
Remote window
2
RCA
5
Left channel output*
8
2
3
1
5
7
Display
3
Antenna
6
Right channel output*
9
