(Legacy): Maestro E206XT

cell router configuration

The Maestro E206XT is a powerful and highly configurable cellular modem and router. This article

details configuring the Maestro E206XT to provide Internet access to an eGauge meter using a

direct Ethernet connection, as well as other general information. Any advanced configuration

questions should be directed to Maestro Wireless Solutions directly.

Additional resources:

Manufacturers product page

SIM Card Installation

The SIM card should come pre-installed if the E206XT is purchased directly from eGauge.

However, if this is not the case the SIM card can be installed or replaced as needed.

Using a paperclip or similar instrument, gently push in the small yellow button to the right of the

SIM tray. This will cause the tray to partially eject from the E206XT, at which point it can be

removed the rest of the way by hand.

To reinstall the SIM tray, gently press it back into the E206XT. The SIM card should have the

contact points facing upward. DO NOT force the SIM tray into the E206XT, as damage may result.

Table of Contents

Do you have a question about the E206XT and is the answer not in the manual?

Page 1 Using a paperclip or similar instrument, gently push in the small yellow button to the right of the SIM tray. This will cause the tray to partially eject from the E206XT, at which point it can be removed the rest of the way by hand.
Page 2 1. Perform a factory reset, if not already done. 2. Power up the E206XT using the included power supply. 3. Using an Ethernet cable, connect a computer to port LAN1 on the E206XT. Make sure all forms of wireless communication are disabled on the computer.
Page 3 If settings are entered incorrectly or if the device password is changed and lost, a factory reset can be performed. To do this, use a paperclip to hold down the reset button (located on the opposite side of the E206XT from the SIM card slot) for at least five seconds. Testing Connection 1.
Page 4 Contact Maestro Wireless Solutions for assistance resolving this issue. It may take the E206XT up to five minutes to obtain a connection after the last configuration setting has been applied. If the E206XT has been configured as described but cannot find a connection after five minutes, there are some common hardware issues that need to be checked.
