- Page 1 QUICK START GUIDE-M2M products E200 Series – Cellular / WAN / LAN / Wi-Fi Router Version 1.1 Maestro E200 Series www.maestro-wireless.com...
- Page 2 Copyright© 2015 Maestro Wireless Solutions Limited. All right reserved. This document is for the use of intended recipients only and the contents may not be reproduced, redistributed, or copied in whole or in part for any purpose without Maestro prior express consent.
- Page 3 User shall assume the entire risk of using or relying on this software, solution, and application. In no event will Maestro Wireless Solutions Ltd. be liable for any loss or damage including without limitation, indirect or consequential loss, damage, or any loss, damage Maestro E200 Series www.maestro-wireless.com...
- Page 4 Every effort is made to keep the product and its software up and running smoothly. However, Maestro Wireless Solutions Ltd. takes no responsibility for, and will not be liable for, the product or its software being temporarily unavailable due to technical issues beyond our control.
-
Page 5: Table Of Contents
IRELESS E205 ADVANCED CONFIGURATION ................25 12.1 ..............25 LASHING FIRMWARE AND UPDATING YOUR DEVICE APPENDIX ..........................27 13.1 ..........................27 EFAULT SETTINGS 13.2 ..................27 ESET TO FACTORY DEFAULT SETTING 13.2.1 Using the web-based user interface ..................27 Maestro E200 Series www.maestro-wireless.com... - Page 6 13.2.2 Using the reset button on the side of the router ............29 13.3 ...........................30 IST OF ACRONYMS Maestro E200 Series www.maestro-wireless.com...
-
Page 7: Safety Precautions
To ensure error-free usage, please install and operate your router with care and comply with the following: Do not expose the router to extreme conditions such as high humidity/rain, high temperatures, direct sunlight, caustic/harsh chemicals, dust, or water. Maestro E200 Series www.maestro-wireless.com... -
Page 8: Overview
2 Overview 2.1 Scope This document provides you all the information you need to set-up, configure and use the Maestro E200 Series router. 2.2 Target audience This document is intended for customers and integrators who understand basic telecommunications and information technology terminology and concepts. - Page 9 Mae estro E200 S Series www.m maestro-wireless.com...
-
Page 10: Product Overview
Switchable WAN/LAN on RJ45 port (E206XT only) Built-in Wi-Fi with an external RP-SMA antenna connector Automatic WAN / 3G failover Built-in GPS supporting active antenna via an external SMA connector (E205XT02, E205XT04 only) Built-in concurrent diversity/GPS antenna supporting active antenna via an... - Page 11 If any of these items are missing or damaged, please contact Maestro Support immediately. The Maestro Support website can be found at: http://support.maestro- wireless.com/ Maestro E200 Series www.maestro-wireless.com...
-
Page 12: Product Features
6 LED’s on the top of the aluminum alloy casing will help the user ensure that the device is operating correctly. Users can also remotely manage the router is also available through an HTTPS connection over the LAN or WAN. Maestro E200 Series www.maestro-wireless.com... -
Page 13: Physical Dimensions And Led
7 Physical dimensions and LED 7.1 Physical dimensions E200 Series dimensions without connector Lenght 83.9mm Depth 60mm Height 25mm Weight Maestro E200 Series www.maestro-wireless.com... -
Page 14: Led Indicators
Strong signal (CSQ>20) Power Power No al ert, device is ru unning smooth Aler Flashing oftware fault (cr rash, issues…) Hardware e fault (high tem mperature, pro blem with module or r SIM card) aestro E200 Series www.m maestro-wire less.com... - Page 15 Maestro E200 Series www.maestro-wireless.com...
- Page 16 Ethernet po ort is operati ng at a spee ed of 1000M Mbps. Ethernet po ort is operati ng at a spee ed of 10/100 0Mbps or no Ethe ernet cable is s connected aestro E200 Series www.m maestro-wire less.com...
-
Page 17: Hardware Installation
Note: For most applications, the antenna(s) included with the unit will provide suitable reception, but some circumstances/environments may require a higher quality antenna or one mounted in a different location. If this is the case, Maestro has many antenna options to chose from, please contact us or visit maestro-wireless.com. -
Page 18: Connect The Power Supply
Mic cro-Fit 4-pin n male conne ector of the power supp ply to the po ower connec ctor loca ated on the L LAN side of the unit. aestro E200 Series www.m maestro-wire less.com... -
Page 19: E205 Basic Configuration
Quick Setup Figure 1: Quick Setu If yo ou need to a access advan nced feature e you can na vigate direc tly in the me enu. aestro E200 Series www.m maestro-wire less.com... -
Page 20: Lan Configuration
DHCP serve r. The mode em router’s d default LAN IP configura ation is as follo ows: LAN IP a address: 192 2.168.1.1 IPv4 Ne tmask : 255. .255.255.0 aestro E200 Series www.m maestro-wire less.com... -
Page 21: Wan Configuration
IPv4 Address: The IP address to assign to the selected WAN interface. IPv4 Netmask: The Subnet mask of the IP address above. IPv4 Gateway: The gateway to assign this WAN interface. DNS server: The DNS server for the WAN interface. Maestro E200 Series www.maestro-wireless.com... -
Page 22: Automatic
APN: Access Point Name, enter the access point name provided by your network operator PIN: If required please enter your SIM card’s PIN code Username and Password: If required enter login credentials provided by your network operator Maestro E200 Series www.maestro-wireless.com... -
Page 23: Wireless (Wi-Fi)
3G parameters click Edit > Advanced Settings. 9.5 Wireless (Wi-Fi) By default, the Wi-Fi is in Access Point mode: Default SSID: Maestro E200 Default Password: W1rele$$ The E200 Wi-Fi can be configured either as An Access Point, in which case, the Wi-Fi acts as a LAN or As a Wi-Fi Client in which case, the E200 connects to an external Wi-Fi source which will be the source of Internet or WAN for the E200. - Page 24 Wi-Fi w will be conf igured as Ac ccess Point. To verify that your se etup were su uccefully app plied and yo ur router is now runnin g go to N Network/Inter rfaces. aestro E200 Series www.m maestro-wire less.com...
-
Page 25: E205 Advanced Configuration
E200 Series can be updated through the web interface. Go to System/Back-up / Flash Firmware. Under Flash new firmware image, click on Choose File and locate the .bin file on your computer. Once the file located on the computer click Flash image… Maestro E200 Series www.maestro-wireless.com... - Page 26 It might be ne ecessary to r renew the ress of your computer t o reach the device agai n, dependin g on your se ettings. aestro E200 Series www.m maestro-wire less.com...
-
Page 27: Appendix
You are asked to pe erform a fact tory reset by y Maestro su upport staff. Ther re are two m methods you u can use to restore fact tory default... - Page 28 Under the Actions tabs, click the Perform reset button. The router asks you to confirm that you wish to reset all changes. Click OK to continue. The router will erase the configuration partition and reboot. Maestro E200 Series www.maestro-wireless.com...
- Page 29 When you have reset your E200 Series router to its default settings you will be able to access the device’s configuration web interface using http://192.168.1.1 with username admin or root and password admin. Maestro E200 Series www.maestro-wireless.com...
-
Page 30: List Of Acronyms
Machine to machine MAC address Media access control address is a unique identifier assigned to network interfaces for communications on the physical network segment Maximum transmission unit of a communications protocol of a layer is the size (in Maestro E200 Series www.maestro-wireless.com... - Page 31 Wi-Fi Local area wireless technology that allows an electronic device to exchange data or connect to the internet using 2.4 GHz UHF and 5 GHz SHF radio waves Wi-Fi Protected Access Wi-Fi Protected Access II WPA2 Maestro E200 Series www.maestro-wireless.com...
- Page 32 Maestro product or for resolving configuration difficulties at Maestro’s support website, http://support.maestro-wireless.com/knowledgebase.php. Try these troubleshooting steps to eliminate your problem. After working through these steps and if your problem is not solved, please send a ticket to Maestro support team. Fill out an Online Support Request via: http://support.maestro- wireless.com/index.php?a=add.
- Page 33 An archive file “backup-Maestro-201x-xx-xx.tar.gz will be downloaded on your default download folder, please attached the file while filling the support request online. Maestro E200 Series www.maestro-wireless.com...
