3-1-2. LED Indicator ................10 3-1-3. Function Switch ................11 3-2. DC Input Side (Rear Panel) Introduction 3-2-1. Chassis Ground ................12 3-2-2. Remote Control Green Terminal ..........13 3-2-3. DC Input Cables ................13 3-3. Maintenance 400 Watt TS Series Inverter Owner’s Manual...
Page 3
VANNER Owner’s Manual Incorporated OPERATION 4-1. Connecting the DC cable 4-2. Connecting the input power 4-3. Connecting the loads 4-4. Switch ON Inverter 4-5. Protection Mechanism 400 Watt TS Series Inverter Owner’s Manual...
The following precautions should be taken when working on the inverter: Step 1 Remove watches, rings, or other metal objects Step 2 Use tools with insulated handles Step 3 Wear rubber gloves and boots 400 Watt TS Series Inverter Owner’s Manual...
1-2. Other Safety Notes Upon receipt, examine the carton box for damage. If you have found any damage on the carton box please notify Vanner. Do not operate near water or in excessive humidity. Do not open or disassemble the inverter, and warranty may be voided.
VANNER Owner’s Manual Incorporated 2-3-2. Temperature performance Figure 1. TS 400W Output power vs. temperature 400 Watt TS Series Inverter Owner’s Manual...
AC output socket LED Indicator ON / OFF / Remote Main switch Function switch Table 2. TS Series AC output side introduction 3-1-1. Main Switch The 3-stage switch is for turning on, turning off and remote mode. 3-1-2. LED Indicator Inverter status to display fault condition.
Table 5. Function Switch definition: output voltage selection Note! 100V series can be selected between 100/110/115/120VAC 3-1-3-3. Output Frequency Selection (S3) Frequency 50Hz 60Hz Table 6. Function Switch definition: Output Frequency selection 400 Watt TS Series Inverter Owner’s Manual -11-...
TS Series Chassis ground Remote control green terminal DC input connector Table 9. TS Series DC input side introduction 3-2-1. Chassis Ground Must be connected to earth ground prior to making any other connections to the equipment. 400 Watt TS Series Inverter Owner’s Manual...
Fuse Holder Part 014633 Number Table 10. TS Series Wiring Cable diameter and Inline Fuse Note! Batteries are capable of providing very large currents in case of short circuit. The fuse should be as close to the positive battery terminal as possible.
Do not use alcohol or ammonia based solutions. Regular service, and relocation of the inverter, should be performed by a qualified service technician. Avoid spilling liquid on the inverter. 400 Watt TS Series Inverter Owner’s Manual -14-...
Page 15
Set the power switch to the “ON” position. The inverter will carry out self-diagnosis and, the LED’s will also appear various colors. Set the power switch to the “OFF” position. The inverter stops and all the lights that are on will go off. 400 Watt TS Series Inverter Owner’s Manual -15-...
Page 16
Model Shutdown Restart 80°C 60°C Table 12. Over Temperature Protection Mechanism Vanner Incorporated 4282 Reynolds Drive Hilliard, Ohio 43026 Ph: 800-AC POWER Ph: 614-771-2718 Fax: 614-771-4904 www.vanner.com Manual P/N: D918919-A January 2018 400 Watt TS Series Inverter Owner’s Manual -16-...
