GETTING TO KNOW YOUR
FIOS ExTENDER
1.3/

GETTING TO KNOW YOUR FIOS ExTENDER

1.3a/ FRONT PANEL
The front panel's unified button allows quick access to the Wi-Fi
Protected Setup (WPS) feature and
pairing mode.
The Status LED will be on white and
solid when your Fios Extender is turned
on, connected to the internet, and
functioning normally.
Status LED
Condition Status
Normal
Issue(s)
Power
Please refer to section 5.0 for details on the rear LEDs.
LED Color Fios Extender
WHITE Normal operation (solid)
Fios Extender is booting (fast blink)
BLUE Pairing mode (slow blink)
Pairing successful (solid)
GREEN Wi-Fi has been turned off (solid)
YELLOW No internet connection (solid)
Extender is too far from the Router. Poor
backhaul signal (slow blink)
Extender is too close to the Router. Poor
Wi-Fi coverage (fast blink)
RED Hardware/System failure detected (solid)
Overheating (fast blink)
Pairing Failure (slow blink)
OFF Power off
