Summary of Contents for CLF Lighting Serius
- Page 1 WWW.CLF-LIGHTING.COM V1.O JUNE 2019...
-
Page 2: Table Of Contents
table of CONTENTS Dimensions Safety Instruction Fixture overview Introduction AC Power Power voltage Power cables Relaying power to other devices Data link Tips for reliable data transmission Physical installation Fastening the fixture to a flat surface Outdoor IP-rated fixtures Condensation/moisture inside housing Fixtures temperature specification Setup Control panel and menu navigation... -
Page 3: Dimensions
Dimensions All dimensions are in millimeters All dimensions are in millimeters 1000 WWW.CLF-LIGHTING.COM... -
Page 4: Safety Instruction
Safety Instruction WARNING! Read the safety precautions in this section before installing, powering, operating or servicing this product. The following symbols are used to identify important safety information on the product and in this manual: DANGER! DANGER! WARNING! WARNING! WARNING! WARNING! WARNING! Safety hazard. - Page 5 PROTECTION FROM BURNS AND FIRE • The exterior of the fixture becomes hot during use. Avoid contact by persons and materials. Allow the fixture to cool for at least 5 minutes before handling. • Keep all combustible materials (e.g. fabric, wood, paper) at least 100 mm away from the fixture. •...
-
Page 6: Fixture Overview
Fixture overview 1 2 3 MENU To select the programming functions DOWN To go backward in the selected functions Button To go forward in the selected functions ENTER To confirm the selected functions Function Display Show the various menus and the selected functions Battery Display Acces menu without power DMX IN... -
Page 7: Introduction
Introduction Affordable lighting essential ■ Unique bracket design ■ Touring proof ■ Smooth RGBW color mixing ■ Fast zoom ■ PowerCON TRUE 1 ® in & out ■ RDM ready ■ Art NET Using for the first time Warning! Read “Safety Information” before installing, powering, operating or servicing the fixture. Before applying power to the fixture: Check that the local AC mains power source is within the fixture’s power voltage and frequency ranges. -
Page 8: Power Cables
Power cables Power input and throughput cables must be rated 16A minimum, have three conductors 1.5 mm² (16 AWG) minimum conductor size and an outer cable diameter of 5 - 15 mm. Cables must be hard usage type (SJT or equivalent) and heat- resistant to 90°C minimum. In the EU the cable must be HAR approved or equivalent. -
Page 9: Physical Installation
Physical installation Warning! The fixture must be either fastened to a flat surface such as a stage or wall, or clamped to a truss or similar structure in any orientation using a rigging clamp. Warning! If the fixture can cause injury or damage if it falls, attach an approved safety cable to one of the safety cable attachment points on the base (see “Fixture overview”). -
Page 10: Outdoor Ip-Rated Fixtures
Outdoor IP-rated fixtures CLF products are applied to official classified IP norm levels. For this product the IP rate is IP22 when using the covers for the chassis parts. Typical use for outdoor rated stage events with normal weather acceptance. So no heavy rain, because then the water pressure over exceeds the IP norm. -
Page 11: Setup
Setup Warning! Read “Safety Information” before installing, powering, operating the fixture. Control panel and menu navigation The onboard control panel and backlit graphic display are used to set the fixture’s DMX address, configure individual fixture settings (personality), read out data and execute service utilities. See “Onboard control menus” for a complete list of menus and commands. Using the control buttons •... -
Page 12: Control Panel
control panel Here you can set all functions for the fixture. Personality To select Dimmer Speed, press the ENTER button to confirm. Use the UP/DOWN button to select Smooth or Fast, Dimmer speed press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. -
Page 13: Dimmer Curve
Dimmer curve provides five dimming options (see picture below): • Optically Linear - The increase in light intensity appears to be linear as DMX value is increased. • Squrare Law - Light intensity control is finer at low levels and coarser at high levels. •... -
Page 14: Onboard Control Menus
Onboard control menus ArtNetSetup Ethernet IP Setup ArtnetPortSetup DMX Address DMX Settings DMX Channel Mode 57 CH 14 CH RDM Device ID Black Out DMX Last State Hold Manual Disable Invert Pixel Order Enable Disable Artnet to DMX Enable Disable Color Calibration Enable Light Mode... - Page 15 Onboard control menus Green Blue Manual Mode White Zoom Inverse No/Yes English Lanuguage Chinese Display Settings Temperature Unit °C/°F Disable Display Warning Enable LED Temperature -40°C - 125°C Fixture Usage Time Fixture Information 99999 LED Light Time 99999 APP: 1.0 Firmware Version Boot: 1.0 Reset Functions...
-
Page 16: Dmx Protocol
DMX protocol 14 CH Function Values Description Tilt 000-255 Tilt Tilt Fine 000-255 Tilt Fine Zoom 000-255 Zoom Dimmer 000-255 Dimmer Dimmer Fine 000-255 Dimmer Fine 000-031 Shutter closed 032-063 Shutter open 064-095 Strobe effect fast to slow 096-127 Shutter open Strobe 128-159 Pulse-effect in sequences... - Page 17 DMX protocol 57 CH Function Values Description 000-255 Tilt Tilt 000-255 Tilt Fine Tilt Fine 000-007 auto speed 008-247 slow-fast Tilt Speed 248-255 auto speed 000-255 Zoom1 Zoom1 000-255 Zoom2 Zoom2 000-255 Dimmer Dimmer 000-255 Dimmer Fine Dimmer Fine 000-031 Shutter closed 032-063 Shutter open...
- Page 18 DMX protocol 57 CH Function Values Description 000-255 0% ~ 100% LED6 GREEN 000-255 0% ~ 100% LED6 BLUE 000-255 0% ~ 100% LED6 WHITE 000-255 0% ~ 100% LED7 RED 000-255 0% ~ 100% LED7 GREEN 000-255 0% ~ 100% LED7 BLUE 000-255 0% ~ 100%...
-
Page 19: Specifications
Specifications Power Input voltage & rate AC 100 ~ 240V, 50/60Hz Standby power “Nominal total power consumption 450W (at nominal voltage 230V) Typical current (at nominal voltage 230V) 1,9A Cos φ Power plug type Configuration LED color RGBW LED color temperature LED CRI level Quantity of LED Dimming frequency... - Page 20 Specifications Control Control protocol Artnett, RDM ready and DMX 512 DMX channel range 14 and 57 CH RDM compliance USIT WDMX DMX input connection 3 & 5 Pin XLR Data input (artnet, SACN) RJ45 Hardware Interface OLED display with battery backup Software upload method Via DMX input Installation...
- Page 21 CLFLIGHTING WWW.CLF-LIGHTING.COM...
