Removing the CCD

1. Turn off the computer, turn it over to remove the battery
2. Lay the computer down on a flat surface with the top case up forming a 90 degree angle.
3. Carefully run your fingers around the inner frame of the LCD panel to lift at points
arrows (Figure 12a).
4. Remove the LCD front cover
a.
1
2
4
b.
(page 2 -
(Figure 12b).
5
3
5
5).
- as indicated by the
1 4
Disassembly
Figure 12
CCD Removal
a. Carefully release the in-
ner frame of the LCD
panel at the points indi-
cated by the arrows.
b. Remove the LCD front
cover.

5. LCD Front Cover
Removing the CCD 2 - 17
