Seeed Grove Beginner Kit User Manual page 4

Grove Beginner Kit For Arduino®
Note:
By default, Grove modules are connected to Seeeduino via PCB stamp holes. This means you
don't need to use Grove cables to connect if not broken out. The default pins are as follow:
Modules
LED
Buzzer
OLED Display 0.96"
Button
Rotary Potentiometer
Light
Sound
Temperature & Humidity Sensor
Air Pressure Sensor
3-Axis Accelerator
Breakout Instruction
Attention:
Please be careful not to cut your hands when using a knife
If you prefer to use the modules in elsewhere then you can simply follow the procedures to break
the modules out!
Step 1
Use a knife or a sharp object to cut at the stamp holes that connect the sensors together
Step 2
Shake the modules up and down and it should come out quite easily!
Interface Pins/Address
Digital D4
Digital D5
I2C I2C, 0x78(default)
Digital D6
Analog A0
Analog A6
Analog A2
Digital D3
I2C I2C, 0x77(default) / 0x76(optional)
I2C I2C, 0x63(default)
