EEI-2678/2679
Thank you for purchasing the MODWAY TV STAND！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.Owing to the size and weight of the TV stand, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe and
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
Components:
1
Top Panel
x1
4
Customer Service 908-368-1025︱www.modwayfurniture.com
TV STAND
2
2
2
Side Panel
Center Panel
x1
Hardware:
A
B
C
D
E
F
G
H
J
1
2
2
3
5
4
2
5
3
2
5
5
x6
5
Leg
Double-ended Bolt M8x190mm
Dowel ɸ8x40mm
Nut M8
Flat Washer M8
Box Wrench #8
Long Bolt M8x30mm
Short Bolt M6x25mm
Allen Wrench #5
Mat 40x40mm
3
Bottom Panel
x4
Page 1 of 6
x12
x24
x12
x24
x1
x8
x4
x1
x4
x2
Advertisement
Related Manuals for modway EEI-2678
Summary of Contents for modway EEI-2678
- Page 1 EEI-2678/2679 TV STAND Thank you for purchasing the MODWAY TV STAND！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions. 2.Owing to the size and weight of the TV stand, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 EEI-2678/2679 TV STAND STEP 1: Put Top Panel (1) upside down on a carpeted or padded area. Insert 6 pieces of Double-ended Bolt (A) into the corresponding holes in the Top Panel (1) by hand as shown. Tighten all the Double-ended Bolts (A) clockwise until secure.
- Page 3 EEI-2678/2679 TV STAND STEP 3: Put Bottom Panels (3) upside down on a carpeted or padded area. Position 1 piece of Bottom Panel (3) to the assembled Top panel (1) and Side Panels (2) as shown. Please confirm the assembled Double-ended Bolts (A) and Dowels (B) have been inserted into the pre-drilled holes on Bottom Panel (3) fully.
- Page 4 EEI-2678/2679 TV STAND STEP 5: Position Center Panel (4) to the assembled Top Panel (1), Side Panels (2), Bottom Panel (3), and Legs (5) as shown. Insert 4 pieces of Short Bolts (G) with 4 pieces of Flat Washer (D) into the pre-drilled holes in the Legs (5) through the holes In the Center Panel (4).
- Page 5 EEI-2678/2679 TV STAND STEP 7: Position the other piece of Bottom Panel (3) to the assembled Top Panel (1), Side Panels (2), Bottom Panel (3), and Center Panel (4) as shown. Please confirm the assembled Double-ended Bolts (A) and Dowel (B) have been inserted into the pre-drilled holes on the other piece of Bottom Panel (3) fully.
- Page 6 EEI-2678/2679 TV STAND STEP 9: Carefully turn over the assembled TV stand. Assembly is complete. Your TV stand is ready to be used now! Customer Service 908-368-1025︱www.modwayfurniture.com Page 6 of 6...
