- Page 1 User Manual User Manual Meat Slicer Instruction Manual Model: 177SL612A 177SL713A 04/2020 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
- Page 2 Instructions: Instructions: The Avantco Auto/ Manual slicer is a medium duty electrically driven appliance. The unit has been designed to The Avantco Auto/ Manual slicer is a medium duty electrically driven appliance. The unit has been designed to meet the highest safety and hygiene standards. The robust aluminum construction and powerful drive motors ensure meet the highest safety and hygiene standards.
- Page 3 User Manual User Manual Safety Safety 1. The units are designed to operate an alternating current (A.C) only. DO NOT CONNECT TO DIRECT CURRENT (D.C). 1. The units are designed to operate an alternating current (A.C) only. DO NOT CONNECT TO DIRECT CURRENT (D.C). 2.
- Page 4 User Manual User Manual This machine shall be cleaned and sanitized at intervals to comply with national, state and/or local health codes. We recommend that the machines should be properly cleaned at least once a day; if necessary even more. If the machines have not been used for a while they must be cleaned before use as well.
- Page 5 1. Unscrew the knob in order to extract the rod from the tray; Remove the meat pusher. 1. Turn the locking knob counter clockwise all the way, removing the knob itself; Take out the whole group by pulling it upwards. www.Avantco.com...
- Page 6 Remove both the center plate and the locking knob. Remove the slice deflector which is attached to the main slicer body, as shown in the picture. Loosen the knob below the sharpener block without removing it; Then remove the whole sharpener by pulling upwards. www.Avantco.com...
- Page 7 Otherwise, they will not have the abrasive quality necessary to sharpen. Clean as follows: Remove the nuts and take the stones off the shafts. Soak the stones in a solution of dish soap (i.e. Joy, Dawn, etc.) and water for one hour. www.Avantco.com...
- Page 8 Sanitize and dry in the same way using a dry cloth. Repeat cleaning both front and back of knife with clear water. Always move from the center outward. NEVER MOVE YOUR HAND TOWARDS THE EDGE OF THE KNIFE. Sanitize and allow to dry. www.Avantco.com...
- Page 9 1. Make sure the sharpener knob at the base of the sharpener is loose (about 10 turns). 2. Insert the sharpener as shown in the picture until it stops at its correct position and screw the knob. www.Avantco.com...
- Page 10 Insert the tension rod for locking and screw completely. Reassemble carefully and do not strip the rod threads or center plate bushing threads Insert the entire group on the carriage as shown in the picture; Tighten the locking knob. www.Avantco.com...
-
Page 11: Gasket Inspection
The inspections must be made by the manufacturer or its authorized service agent. WARNING The slicer must be removed from service until repaired by the manufacturer or its authorized service agent if any gasket or seal is found to be damaged or missing. www.Avantco.com... -
Page 12: Sharpening Instructions
9. Switch OFF the power. Return the sharpener to its stored position and lock in place. 11. Clean slicer before slicing product. (See “Cleaning and Sanitizing instruction” ). Your slicer is now sharpened, cleaned and sanitized—ready to use. www.Avantco.com... - Page 13 Electrical Connection Information Electrical Connection Information Model Description Volts /HZ Watts Plug Type 177SL612A Avantco 12” Auto / Manual Slicer 120 / 60 1/2 HP 550 W NEMA 5-15P 177SL713A Avantco 13” Auto / Manual Slicer 120 / 60 3/4 HP...
- Page 14 User Manual User Manual 120V 60Hz 120V 60Hz Wiring Diagram Wiring Diagram LEGEND LEGEND Description Description PB1/PB3 PB1/PB3 Push Button Stop Push Button Stop PB 2/PB4 PB 2/PB4 Push Button Start Push Button Start Over Temp. Safety Over Temp. Safety T1/ T2 T1/ T2 Motor...
- Page 15 User Manual Exploded Parts Diagrams - SL612A SL713A www.AvantcoEquipment.com...
- Page 16 User Manual Exploded Parts Legend - SL612A Diagram Part Na me Re placement Quan tity Diagram Part Na me Re placement Quan tity Part # Needed Part # Needed Movable clapboard 177PSLA5 Cam regulator 177PSLA48 Ca pacitor 177PSLA49 Blade cover 177PSLA6 52,53 Ca rriage assembly...
- Page 17 User Manual Exploded Parts Legend - SL713A Diagram Part Na me Re placement Quan tity Diagram Part Na me Re placement Quan tity Part # Needed Part # Needed Movable clapboard 177P 7135 Cam regulator 177PSLA48 Ca pacitor 177PSLA49 Blade cover 177P 7136 52,53 Ca rriage assembly...
- Page 18 Equipment Limited Warranty Avantco w arrants its equipment t o be free from defe cts in material and workmanship for a period of 1 year. T his is the sole and exclusive w arranty m ade by Avantc o covering your Avantc o brand equipment. A claim under this warranty must be made within 1 year from t he date of purchase of t he equipment.
