- Page 1 User Manual User Manual Meat Slicer Instruction Manual Model: 177SL612A 10/2018 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
- Page 2 General Installation And Operation Instructions: The Avantco Auto/ Manual slicer is a medium duty electrically driven appliance. The unit has been designed to meet the highest safety and hygiene standards. The robust aluminum construction and powerful drive motors ensure long and reliable operation and use.
- Page 3 User Manual Safety 1. The units are designed to operate an alternating current (A.C) only. DO NOT CONNECT TO DIRECT CURRENT (D.C). 2. Please ensure that the power supply cord does not come into contact with hot surfaces. 3. If the supply cord is damaged, it must be replaced with a new cord assembly. (Available from the suppliers agent.) 4.
- Page 4 User Manual Cleaning 1. It is essential to follow all the safety instructions at all times. 2. Make sure that the unit is unplugged before cleaning. 3. The unit should never be immersed in water. 4. Do not use abrasive cleaning agents or solvents to clean this machine. Clean with a damp cloth. REMEMBER! The blade is extremely sharp and for safety, ensure that the slice thickness knob is in the ‘0’...
-
Page 5: Blade Sharpening
9. Return the sharpening device to its original position by unlocking the safety screw and rotating by 180°. Electrical Connection Information Electrical Connection Information Model Description Volts /HZ Watts Plug Type 177SL612A Avantco 12” Auto / Manual Slicer 120 / 60 1/2 HP 550 W NEMA 5-15P www.AvantcoEquipment.com... - Page 6 User Manual 120V 60Hz Wiring Diagram LEGEND Description PB1/PB3 Push Button Stop PB2/PB4 Push Button Start Over Temp. Safety T1/ T2 Motor R1/R2 Relay 120V C1/C2 Capacitor 20MF Motor - 120V Motor - 120V Cooling Fan F1/ F2 www.AvantcoEquipment.com...
- Page 7 User Manual Exploded Parts Diagrams - SL612A www.AvantcoEquipment.com...
- Page 8 User Manual Diagram Part Name Replacement Quantity Diagram Part Name Replacement Quantity Part # Needed Part # Needed Movable clapboard 177PSLA5 Cam regulator 177PSLA48 Capacitor 177PSLA49 Blade cover 177PSLA6 52,53 Carriage assembly 177PSLA52 Director 177PSLA8 Upper towing bracket 177PSLA54 Motor 177PSLA9 Upper towing bracket 177PSLA57...
-
Page 9: Limited Warranty
Warranty. Using the slicer to slice raw or frozen meat will void the warranty. Residential use voids the warranty. This warranty does not apply to, and Avantco is not responsible for, any warranty claims made on products sold or used outside of the United States. www.AvantcoEquipment.com...
