88 4515 95
Kitchen Cart
IMPORTANT NOTE
.
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
Part List
A.
Top
1 pc.
U.
Base
1 pc.
H.
Back Stretcher
1 pc.
I.
Back Stretcher
1 pc.
J.
K.
Arm
Front Stretcher
1 pc.
2 pcs.
Hardware List
Hex Wrench
1 pc.
Caster
2 lock
2 non-lock
Small Wrench
4 pcs.
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance : www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Side Panel
1 pc.
M.
Side Rack
1 pc.
L.
O.
Tower Bar
Base Rack
1 pc.
1 pc.
M4x32
Cam Lock
Wood Screw
22 pcs. (+6 extra)
8 pcs. (+1 extra)
Cam Lock Screw
Flat Washer
22 pcs. (+2 extra)
8 pcs. (+1 extra)
D.
C.
Middle Panel
Side Panel
1 pc.
1 pc.
N.
Side Rack
1 pc.
R.
P.
Door
Rack
1 pc.
1 pc.
M3x16
M3.5x25
Wood Screw (short)
Wood Screw (long)
for Drawer Base Part
for Drawer Side Part
and Back Panel
24 pcs. (+1 extra)
20 pcs. (+1 extra)
M3x16
Wood Screw
Magnet
for Magnet
2 pcs.
4 pcs. (+1 extra)
F.
E.
Back Panel
Middle Panel
3 pcs.
1 pc.
Q.
Shelf
4 pcs.
T.
Drawer
S.
2 pcs.
Door
(Please refer to the last page of these
1 pc.
instructions for drawer assembly steps.)
M6x25
M4x25
Head Cap Bolt
Machine Screw
4 pcs. (+1 extra)
8 pcs.
M6x12
Head Cap Bolt
Adjustable Pin
for Caster
16 pcs.
16 pcs. (+1 extra)
G.
Back Upright
2 pcs.
Pull Handle
4 pcs.
