Spectrum Digital TMS320VC5505 Technical Reference page 11

2
• I C EEPROM (256Kbits) and SPI EEPROM (256Kbits)
• EMIF, I
• External JTAG emulation interface
• Embedded JTAG controller
• Color LCD Display
• 10 User push button switches
1.2 Development Tools
The EVM is designed to work with TI's Code Composer Studio (CCS) Integrated
Development Environment (IDE). Code Composer Studio communicates with the EVM
board through the external emulator header, or on board emulation. An EVM specific
version of Code Composer Studio ships with the EVM.
1.3 Memory Map
Refer to the TMS320VC5505 device documentation for a more specific memory
information on the VC5505 device.
1.4 Power Supply
The EVM operates from a +5V external power supply or battery.
To minimize risk of electric shock hazard, use only the following
power supply for the EVM module with Medical Development
Applications: SL Power AULT Model MW173KB0503F01.
1.5 VC5505 GIO Schedule
The VC5505 has multiple GIO signals that can be used for system level tasks. The GIO
signals are connected to various jumpers on the EVM. By using jumper plugs, these
GIO signals can be used to control different functions on the VC5505 EVM. Refer to the
discussion of the jumper setting later in this document for details of the jumper locations
and options they provide. The table below describes how the GIO lines are used on the
EVM.
2 2
S, I S, UART, SPI interfaces on expansion connectors
WARNING
Spectrum Digital, Inc
1-3
