Installation Manual
3D Sonar Visualizer F3D-S
(Option for FSV-25/FSV-25S)
IMPORTANT NOTICES .................................................................................................... i
SYSTEM CONFIGURATION ........................................................................................... ii
1. PREPARATION .......................................................................................................... 1
1.1 Necessary Parts....................................................................................................................1
1.2 Requirements for FSV-25 .....................................................................................................2
1.3 How to Connect the LAN Cable ............................................................................................2
1.4 How to Setup the PC ............................................................................................................3
1.5 How to Install the Driver Install File.......................................................................................3
1.6 How to Install the F3D-S Software........................................................................................4
1.7 How to Start and Quit the Software ......................................................................................6
1.8 Initial Settings........................................................................................................................8
2. DISPLAY SCREEN, OPERATIONAL OVERVIEW .................................................. 11
APPENDIX 1 MENU TREE .......................................................................................AP-1
www.furuno.com
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Furuno 3D Sonar Visualizer F3D-S
Summary of Contents for Furuno 3D Sonar Visualizer F3D-S
-
Page 1: Table Of Contents
Installation Manual 3D Sonar Visualizer F3D-S (Option for FSV-25/FSV-25S) IMPORTANT NOTICES ....................i SYSTEM CONFIGURATION ................... ii 1. PREPARATION ......................1 1.1 Necessary Parts........................1 1.2 Requirements for FSV-25 .....................2 1.3 How to Connect the LAN Cable ....................2 1.4 How to Setup the PC ......................3 1.5 How to Install the Driver Install File..................3... -
Page 3: Important Notices
• The operator of this equipment must read and follow the instructions in this manual. Wrong operation or maintenance can void the warranty or cause injury. • Do not copy any part of this manual without written permission from FURUNO. • If this manual is lost or worn, contact your dealer about replacement. -
Page 4: System Configuration
SYSTEM CONFIGURATION Monitor Processor Unit FSV-2503/2503S LAN cable 12-24 Rectifier RU-1746B-2 (Local supply, program installed in PC) 100/110/115/220/230 VAC, 1ø, 50/60 Hz Control Unit FSV-2501 IF Unit FSV-8502 Hull Unit FSV-253/254 Raise/Lower Control Box FSV-2530 Transceiver Unit 200-220 VAC, FSV-251 3ø, 50/60 Hz Junction Box FSV-2550... -
Page 5: Preparation
PREPARATION Necessary Parts Standard Supply The 3D Sonar Visualizer contains the following items. 3D Sonar visualizer F3D-S (Code No.: 001-546-350) Name Type Code No. Remarks CD-ROM CDR700S.WP. 000-177-025-10 For details, see "Folder S1P10S structure of the CD-ROM". USB Protec- 942-000058-... -
Page 6: Requirements For Fsv-25
1. PREPARATION Requirements for FSV-25 The following updates of programs and printed circuit boards are required to use the F3D-S. If your FSV-25 does not meet the following requirements, contact your dealer. Program version requirements for FSV-25 Unit Name of operation test Program version Processor Unit FSV-2503 FSV-2503... -
Page 7: How To Setup The Pc
1. PREPARATION How to Setup the PC 1. Turn the PC on. 2. Set the IP address and subnet mask in [Internet Protocol Version 4 (TCP/IPv4) Properties]. • IP address: 172.31.10.10 • Subnet mask: 255.255.0.0 3. Acces the power and sleep settings then set [Sleep] and [Screen] to [Never]. 4. -
Page 8: How To Install The F3D-S Software
1. PREPARATION 8. Click [Next] to start the installation. When the installation is complete, the dialog box shown below appears. 9. Click [Finish] to finish. How to Install the F3D-S Software 1. Turn the PC on. 2. Login as a user with administration rights. 3. - Page 9 1. PREPARATION 6. Click [Next]. F3D-S F3D-S F3D-S F3D-S 7. Click [Next]. To change the installation folder, click [Browse] and select the folder before clicking [Next]. F3D-S F3D-S 8. Click [Next] to start the installation. When the installation is complete, the dialog box shown below appears. F3D-S F3D-S 9.
-
Page 10: How To Start And Quit The Software
6. To quit the software, click the close button (x) at the upper right-hand corner of the screen. All setting information is saved to the folder “C: \ Users \ User name \ Doc- uments \ FURUNO \ F3D-S”. Note: If the information has not been saved, open the properties of the above-... - Page 11 1. PREPARATION How to deal with DLL error ® If your Windows OS version is other than the required version, the following message may appear when you try to start the software. Install the VCOMP140.DLL as follows: 1. Access the following URL. https://support.microsoft.com/en-us/help/2977003/the-latest-supported-visual-c- downloads 2.
-
Page 12: Initial Settings
1. PREPARATION Initial Settings You can set the display of the marks from the technician menus. 1.8.1 How to access the technician menus ™ 1. Click on the lower InstantAcces bar to open the lower user menu. 2. Click to open the [Advanced Setting] dialog box. 3. - Page 13 1. PREPARATION 1.8.2 [Display Setting] menu The [Display Setting] menu sets the display of the marks. 1. Click [Setting] on the menu bar. 2. Click [Display …] to open the [Display Setting] dialog box. 3. Referring to the table below, set each menu item. Menu item Description [Range Ring Number]...
- Page 14 1. PREPARATION 1.8.3 [Own Ship Mark Setting] menu The [Own Ship Mark Setting] menu sets the size of the own ship mark, based on your ship's actual dimensions and transducer location. 1. Click [Setting] on the menu bar. 2. Click [Own Ship Mark …] to open the [Own Ship Mark Setting] dialog box. Origin TD Position 1 TD Position 2...
-
Page 15: Display Screen, Operational Overview
DISPLAY SCREEN, OPERATION- AL OVERVIEW This section describes the display and operational overviews. xx xx 33°50.245N 119°44.237W 0.4kn 237° 0.4kn 255° -10.0°C Name Description ™ Upper InstantAccess bar • Click to show the upper user menu. • Click to hide the upper user menu. “Side-View”... - Page 16 2. DISPLAY SCREEN, OPERATIONAL OVERVIEW How to operate the menu ™ 1. Click on the upper or lower InstantAcces bar to open the user menu. 2. Click an icon to execute the menu function. The selected icon is displayed in cyan. The icons that have a at the bottom right have additional menus.
-
Page 17: Appendix 1 Menu Tree
APPENDIX 1 MENU TREE Upper User Menu ™ The upper InstantAccess bar is on the top left side of the screen. Click to show the upper user menu. Click to hide the upper user menu. First level Second level User* Cont.** Reset Viewpoint –... - Page 18 APPENDIX 1 MENU TREE First level Second level User* Cont.** User Program – Save User Program Number Return *: This item can be registered as a user program (shortcut). **: This item keeps the setting from when the software was last used. ***: This item appears when the appropriate mark is right-clicked.
- Page 19 APPENDIX 1 MENU TREE First level Second level User* Cont.** Start Recording – Capture Stop Recording – Advanced Setting – View 3D-View Side-View Top-View Vslice-View1 Vslice-View2 Numeric Data Lat/Lon DPTH Current1 Current2 Current3 Current4 Current5 TEMP Depth Digit Size (Large, Middle, Small) Trawl Door Size (Large, Middle, Small) Trawl Mouth Distance (10 to 2000 m;...
- Page 20 (Elemental Chlorine Free) The paper used in this manual is elemental chlorine free. ・ 機器の修理・使用方法等に関するお問い合わせは、お買い上げの販売店・代理店、最寄りの 当社支店・営業所あてへお願いします。 ・ FURUNO Authorized Distributor/Dealer お問い合わせは 本書の無断複写複製(コピー)は特定の : JUL. 2019 場合を除き、当社権利侵害になります。 : DEC. 12, 2019 Printed in Japan Pub. No. IMC-13442-A1 ( YOTA) F3D-S(FSV-25) 00019680610...
