Sloan ETF-660 Installation Instructions Manual

ETF-660
Sensor Activated Electronic
Lavatory Faucet for tempered
or hot/cold water operation.
Sloan Valve Company warrants its ETF-660 and ETF-770 Faucets to be made of first class materials, free from defects of material or workmanship under normal use and to perform the
service for which they are intended in a thoroughly reliable and efficient manner when properly installed and serviced, for a period of three years (1 year for special finishes) from date of
purchase. During this period, Sloan Valve Company will, at its option, repair or replace any part or parts which prove to be thus defective if returned to Sloan Valve Company, at customer's
cost, and this shall be the sole remedy available under this warranty. No claims will be allowed for labor, transportation or other incidental costs. This warranty extends only to persons or
organizations who purchase Sloan Valve Company's products directly from Sloan Valve Company for purpose of resale.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE COMPANY RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES
OF ANY MEASURE WHATSOEVER.
PRIOR TO INSTALLATION
Prior to installing the Sloan ETF-660 or ETF-770 Faucet, install the
items listed below. Also, refer to the Rough-In.
• When Using Plug-In Transformer — Install electrical receptacle for plug-
in transformer (120 VAC, 2 amp service for each ETF-233 (24 VAC, 35
VA) plug-in transformer used).
• When Using Box Mount Transformer — Install electrical wiring to
transformer location (120 VAC, 2 amp service for each EL-248-40 (24
VAC, 40 VA) transformer used).
• Lavatory/sink
• Drain line
• Hot and cold water supply lines or tempered water supply line
Multiple Faucets
Multiple faucets can be powered by a single transformer, provided that the
transformer has been properly sized. Allow a minimum of 15 VA of current
rating for each solenoid valve used. Refer to "Step 5 — Install Transformer"
for further information.
Mixing Valve
When installing the faucet with a Sloan mixing valve, these Installation
Instructions AND the Installation Instructions packaged with the mixing valve
MUST be followed.
Important:
• INSTALL ALL ELECTRICAL WIRING IN ACCORDANCE WITH
NATIONAL/LOCAL CODES AND REGULATIONS.
• INSTALL ALL PLUMBING IN ACCORDANCE WITH APPLICABLE CODES
AND REGULATIONS.
• A 24 VAC STEP-DOWN TRANSFORMER MUST BE USED.
• USE APPROPRIATE PRECAUTIONS WHILE CONNECTING TRANSFORMER
TO 120 VAC POWER SOURCE.
• DO NOT PLUG TRANSFORMER INTO POWER SOURCE (RECEPTACLE)
INSTALLATION INSTRUCTIONS FOR
ELECTRONIC SENSOR ACTIVATED LAVATORY FAUCETS
ETF-770
Sensor Activated Electronic
Gooseneck Faucet for tempered
or hot/cold water operation.
LIMITED WARRANTY
UNTIL ALL WIRING IS COMPLETED. ALLOWING 24 VAC TRANSFORMER
WIRES TO TOUCH OR SHORT WHILE POWER IS BEING SUPPLIED WILL
CAUSE PERMANENT DAMAGE TO THE TRANSFORMER AND CIRCUIT
CONTROL MODULE.
• KEEP THREAD SEALANT OUT OF YOUR WATERWAY TO PREVENT
COMPONENT PART DAMAGE! DO NOT USE ANY SEALANT ON
COMPRESSION FITTINGS. FOR THREADED PIPE FITTINGS, DO NOT
APPLY SEALANT TO THE FIRST TWO "STARTER" THREADS.
• FLUSH ALL WATER LINES UNTIL WATER IS CLEAR BEFORE CONNECTING
SOLENOID TO SUPPLY STOPS.
TOOLS REQUIRED FOR INSTALLATION
• Open end wrenches for hex sizes: 15/16", 13/16", 11/16", 7/8" & 5/8"
• Basin wrench
• Slotted screwdriver, 3/16"
• Slotted screwdriver (supplied)
• Phillips head screwdriver, #2
• Pliers
• Wire stripper/crimping tool
INSTALLATION OF ETF-660 AND ETF-770 FAUCETS
Bak-Chek ® Tee Usage
When connecting the Sloan ETF-660 or ETF-770 Faucet to both hot and cold
water supplies, a Bak-Chek
can be controlled by adjusting the supply stops. Refer to Rough-in
illustrations on Page 2.
When connecting the faucet to a single line water supply or a pre-tempered
water supply, a Bak-Chek
A Bak-Chek ® Tee is not required or provided when a Temperature Mixing Valve
is included with the faucet.
Compliant to:
ASME A112.18.1 and CSA B125.1
® Tee is provided and required. Water temperature
® Tee is not required.
Code No. 0816154
Rev. 2a (10/08)
