Sloan WES-7000 Installation Instructions

WES-7000 WATERFREE URINAL
NEW CONSTRUCTION
INSTALLATION INSTRUCTIONS
BEFORE STARTING INSTALLATION:
IMPORTANT Do not install on copper DWV
due to copper's susceptibility to corrosion.
•
•
Check rough-in height to achieve 24" rim height
(17" rim height for ADA).
•
Check slope. Downhill slope, per code, is essential
because waterfree urinals depend on gravity flow.
•
Check DWV material. Suitable materials include
cast iron, PVC, ABS and galvanized steel.
TUBE CUTTING CHART
•
Measure drain nipple depth (inches) to find trim
length (inches)
•
13 7/8" or more DO NOT CUT
•
3 3/4" or less DO NOT USE TUBE
OR LESS TRIM OR LESS TRIM OR LESS TRIM
"
13 ¾" ¼ " 10 ¼" 3 ¾" 6 ¾" 7 ¼"
13 ½ ½ 10 4 6 ½ 7 ½
13 ¼ ¾ 9 ¾ 4 ¼ 6 ¼ 7 ¾
1 4 ½ 8
13 9 ½ 6
12 ¾ 1¼ 9 ¼ 4 ¾ 5 ¾ 8 ¼
12 ½ 1½ 9 5 5 ½ 8 ½
12 ¼ 1¾ 8 ¾ 5 ¼ 5 ¼ 8 ¾
12 2 8 ½ 5 ½ 5 9
2¼ 5 ¾ 9 ¼
11 ¾ 8 ¼ 4 ¾
11 ½ 2½ 8 6 4 ½ 9 ½
11 ¼ 2¾ 7 ¾ 6 ¼ 4 ¼ 9 ¾
11 3 7 ½ 6 ½ 4 10
10 ¾ 3 ¼ 7 ¼ 6 ¾
3 ½ 7
10 ½ 7
CUSTOMER SERVICE
1-888-SLOAN-14 (1-888-756-2814)
customer.service@sloanvalve.com
CAUTION
After removing any urinal from the
drain line, it's normal for certain naturally occurring,
but potentially hazardous sewer gases to escape
through the opening until the waterless cartridge
is installed properly into the waterless urinal. If you
need to leave an open drain line unattended after
removing the urinal from the wall, temporarily wedge paper towels or a
rag into the drain hole to reduce any outflow of sewer gases, and remove
the paper towels or rag prior to completing the urinal or cartridge
installation. Never smoke, have an open flame, or place your nose or
mouth near open drain lines or waterless urinal housings into which
a cartridge is not yet properly installed. You also can wear a breathing
mask when removing or installing any waterless urinal or cartridge to
reduce potential exposure to any such gases.
www.sloanvalve.com
The information in this document is subject to change without notice.
© 2015 Sloan Valve Company All rights reserved.
(08-15)Rev1
1
½" ¾"
to
standard 24" rim
10"
for ADA
installation
17"
finished floor
SET DRAIN LINE HEIGHT 17" from
finished floor (standard 24" rim) or 10" for
ADA installation. Threaded nipple should
extend ½ to ¾" from wall.
5
13 ⁄ "
Install plastic anchor
and screw here
MEASURE & MARK THE ROUGH-IN if
in-wall carrier is not used. Use a "
masonry bit to drill hole, then install
the hanger bracket with one plastic
anchor and screw.
8
B
A
C
A. Find the drain nipple depth on B. Cut the tube at the groove using a sharp
the Tube Cutting Chart (left). utility knife to ensure a square, flat cut.
Measure and mark the specified C. Clean burrs from the cut end by using
trim length on the insert tube at
emery paper.
the nearest ¼" groove.
10 11
Install two
additional screws
"
DRILL HOLES masonry
bit for the lower anchor screws
HANG THE BOWL, inserting tailpipe
and mounting plate and insert
into bushing, then install anchor
plastic anchors where indicated. screws with washers.
2 3
2¼
1 ⁄
1 "
13 ⁄ "
A. Clean face of existing drain nipple.
Drain
B. Install the clear inspection disc with
C. Slowly pour water into the drain.
CARRIER STUD PLACEMENT I if using
D. Use a flashlight to check the pitch/
in-wall carrier, set bearing rods as
shown above.
E. Remove disc and nut after inspection.
6
INCORRECT CORRECT
Not centered Centered
A
A. Hang the bowl on the bracket and check tail
pipe alignment, then remove the bowl and
adjust the bracket as needed.
Re-hang and re-check bowl alignment with
the drain line. Tail pipe should align with center
of drain line.
D
D. Apply lubricant to the outside of the
rubber bushing and ribbed inside area.
E. Insert the tube and bushing with arrow
tab at the top. Apply lubricant to tailpipe
of housing. IMPORTANT: Be sure arrow tab
is at 12:00 position.
12
TIGHTEN COMPRESSION
NUT AND HOSE CLAMP.
4
Cut away wall
C D
Lift drain line & brace
with mending plate
compression nut.
ADJUST DRAIN TO ACHIEVE PITCH
only if standing water is present
slope. No water should be present in (code requires ¼" drop per foot of
the inspection disc or nipple. drain line for proper pitch). Seal wall
according to code.
7
B
B. Mark anchor holes then
remove bowl without
DETERMINE THE DRAIN NIPPLE DEPTH
moving hanger bracket.
by measuring the distance between the
back of the sanitary tee (or elbow) to
the front edge of the nipple.
9
E
Arrow
tab UP
PLACE THE HOSE CLAMP
and compression nut onto the
housing tailpipe.
13 14
POUR 5
GALLONS
OF WATER
as rapidly
as possible
into housing CAULK THE BOWL
to ensure TO THE WALL if
good flow there is good flow
and no leaks or and no leaks or
standing water. standing water.
15
CARTRIDGE
INSTRUCTIONS
INSTALL
CARTRIDGE
per the cartridge
instruction sheet.
