From Bicom Systems Wiki
Contents
1 Introduction - How to use Snom 320 with PBXware
2 Registering Snom 320
2.1 Requirements
2.2 Manual Configuration
2.3 Auto Provisioning Configuration
2.4 Paging
2.5 Glossary
Introduction - How to use Snom 320 with
PBXware
This "How to" is written to as general guide on how to use your Snom 320 with PBXware using
5.2b Snom 320 firmware. t covers the most common tasks required to have your Snom 320
working efficiently.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snom 320

Summary of Contents for Snom 320

  • Page 1 Introduction - How to use Snom 320 with PBXware This "How to" is written to as general guide on how to use your Snom 320 with PBXware using 5.2b Snom 320 firmware. t covers the most common tasks required to have your Snom 320...

  • Page 2: Manual Configuration

    Registering Snom 320 Requirements 1. Snom 320 firmware. - Make sure that the device is loaded with 5.2b firmware. 2. DHCP server. - Fully configured and operational DHCP server. Manual Configuration UAD Settings STEP ONE: PBXware IP address. 1. Find out the IP address of PBXware server.
  • Page 3 STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD", and click on the "edit" icon corresponding to "Snom 320".
  • Page 4 2. Make sure "Status" is set to "active", "Auto provisioning" is set to "No" and "DHCP" is set to "Yes". UAD Settings 3. Click on the "Save" button to save changes. Creating Extension STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension".

  • Page 5: Required Fields

    2. The standard options window will be shown below. 3. Select Snom 320 from the "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extensions registered on LAN. -"Remote" is for all extensions registered from remote networks, WAN, Internet etc.

  • Page 6: Registering Phone

    The secret value can be changed. PIN: An auto-generated PIN will allow access to voicemail and online self care. Registering Phone STEP ONE: Electricity and Ethernet. - The Snom 320 needs electricity. Plug the adapter into its jack then connect it to the electricity...
  • Page 7 3. The IP address will be shown on Snom 320 display. Registering Phone STEP THREE: Snom 320 Web Interface. 1. Open a new browser window and enter the IP address in order to access Snom 320 administration interface. Example: http://192.168.1.101 an example with IP address 2.
  • Page 8 2. Enter the following details into the respective fields. REQUIRED FIELDS: Account <%PRODUCT%> extension number. Example: 1000. Password The Secret of the extension as received in the e-mail associated with this extension. Example: 3dX3r5 Registrar IP address of PBXware server. Example: 192.168.1.2 an example with details filled in 3.
  • Page 9 Snom 320 to PBXware. 4. Click on "Advanced" link. 5. Navigate down and click on "Reboot" button. Snom 320 will reboot for changes to take effect. Azra - Kredite... - Conclusion: If everything is done as above described you should have successfully registered *123 your Snom 320 to PBXware.
  • Page 10 2. Hit "Enter" on your keyboard. 3. Login to PBXware with your e-mail address and password. STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD" and click on the "edit" icon corresponding to "Snom 320".
  • Page 11 2. Make sure "Status" is set to "active", "Auto provisioning" is set to "Yes" and "DHCP" is set to "Yes".
  • Page 12 STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window (below) will be shown. 3. Select Snom 320 from the "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extensions registered on LAN.
  • Page 13 Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages. Example: john@domain.com. Auto provisioning: Set to "Yes". MAC Address: Snom 320 MAC address. Example: 001646f5f797 Creating Extension/Extensions Add an example with details filled in 2. Click on the "Save" button.
  • Page 14 Registering Phone STEP ONE: Electricity and Ethernet. - The Snom 320 needs electricity. Plug the adapter into its jack then connect it to the electricity network. - Connect ethernet port to a hub, router or switch as to access LAN.
  • Page 15 Registering Phone STEP THREE: Snom 320 Web Interface. 1. Open a new browser window and enter the IP address in order to access Snom 320 administration interface. Example: http://192.168.1.101 an example with IP address 2. Hit "Enter" on your keyboard.
  • Page 16 - Conclusion: If everything is done as above described you should have successfully registered your Snom 320 to <%PRODUCT%>. Dial *123 to verify registration. - For further information, please contact the manufacturer or check their web site www.snom.com. Paging Paging is a service that transmits a call through one or multiple phones on their loudspeakers.
