- Page 1 Inspiron 3593 Setup and Specifications Regulatory Model: P75F Regulatory Type: P75F013 June 2020 Rev. A02...
- Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
-
Page 3: Table Of Contents
Contents 1 Set up your Inspiron 3593......................4 2 Views of Inspiron 3593......................... 6 Left......................................6 Right......................................6 Base......................................7 Display..................................... 8 Bottom....................................8 3 Specifications of Inspiron 3593....................10 Dimensions and weight................................10 Processors.................................... 10 Chipset....................................11 Operating system..................................11 Memory....................................11 Intel Optane memory (optional)............................ -
Page 4: Set Up Your Inspiron 3593
Set up your Inspiron 3593 NOTE: The images in this document may differ from your computer depending on the configuration you ordered. 1. Connect the power adapter and press the power button. NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and press the power button to turn on the computer. - Page 5 Proactively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery tool troubleshoots issues with the operating system. For more information, see the SupportAssist documentation at www.dell.com/support. NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty. Set up your Inspiron 3593...
-
Page 6: Views Of Inspiron 3593
Views of Inspiron 3593 Left 1. Power-adapter port Connect a power adapter to provide power to your computer. 2. USB 3.1 Gen 1 (Type-C) port (optional) Connect to external storage devices. Provides data transfer speeds up to 5 Gbps. NOTE: This port does not support video/audio streaming and Power Delivery. -
Page 7: Base
When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power button for 4 seconds to force shut-down the computer. If the power button has a fingerprint reader, place your finger on the power button to log in. Views of Inspiron 3593... -
Page 8: Display
For computers with optical drive 1. Left speaker Provides audio output. 2. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Views of Inspiron 3593... - Page 9 Provides audio output. 2. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. 3. Right speaker Provides audio output. Views of Inspiron 3593...
-
Page 10: Specifications Of Inspiron 3593
Specifications of Inspiron 3593 Dimensions and weight Table 3. Dimensions and weight Description Values Height: Front • 19.89 mm (0.78 in.—without optical drive) • 20.66 mm (0.81 in.—with optical drive) Rear • 19.90 mm (0.78 in.—without optical drive) • 22.70 mm (0.89 in.—with optical drive) Width 380 mm (14.96 in.) -
Page 11: Chipset
12 GB DDR4 at 2666/3200 MHz (1 x 4 GB + 1 x 8 GB) • 16 GB DDR4 at 2666/3200 MHz (2 x 8 GB) • 16 GB DDR4 at 2666/3200 MHz (1 x 16 GB) Specifications of Inspiron 3593... -
Page 12: Intel Optane Memory (Optional)
Intel Optane Memory M15 is supported on computers that meet the following requirements: • Generation or higher Intel Core i3/i5/i7 processors • Windows 10 64-bit version or higher (Anniversary Update) • Intel Rapid Storage Technology driver version 17 or higher Specifications of Inspiron 3593... -
Page 13: Ports And Connectors
To learn more about the features of different types of M.2 cards, see the knowledge base article SLN301626. Communications Ethernet Table 11. Ethernet specifications Description Values Model number Ethernet controller integrated on the system board Transfer rate 10/100 Mbps Specifications of Inspiron 3593... -
Page 14: Audio
Internal interface High-definition audio External interface Headset combo jack (stereo headphones/microphone-in) Speakers Internal speaker amplifier Supported (audio codec integrated) External volume controls Keyboard shortcut controls Speaker output: Average Peak 2.5 W Subwoofer output Not supported Microphone Supported Specifications of Inspiron 3593... -
Page 15: Storage
Number of keys • United States and Canada: 101 keys • United Kingdom: 102 keys • Japan: 105 keys • Brazil: 104 keys Size X = 19.05 mm key pitch Y = 18.05 mm key pitch Specifications of Inspiron 3593... -
Page 16: Camera
Values Resolution: Horizontal 3215 Vertical 3215 Dimensions: Horizontal 105 mm (4.13 in.) Vertical 80 mm (3.15 in.) Touchpad gestures For more information about touchpad gestures for Windows 10, see the Microsoft knowledge base article 4027871 support.microsoft.com. Specifications of Inspiron 3593... -
Page 17: Power Adapter
–40°C to 65°C (–40°F to 149°F) –40°C to 65°C (–40°F to 149°F) Operating time Varies depending on operating conditions Varies depending on operating conditions and can significantly reduce under certain and can significantly reduce under certain power-intensive conditions. power-intensive conditions. Specifications of Inspiron 3593... -
Page 18: Display
Left: 40 degrees • Right: 40 degrees • Right: 40 degrees Vertical view angle • Top: 10 degrees • Top: 10 degrees • Bottom: 30 degrees • Bottom: 30 degrees Pixel pitch 0.252 mm 0.179 mm Specifications of Inspiron 3593... -
Page 19: Fingerprint Reader (Optional)
Table 25. Computer environment Description Operating Storage Temperature range 0°C to 40°C (32°F to 104°F) –40°C to 65°C (–40°F to 149°F) Relative humidity (maximum) 10% to 90% (non-condensing) 0% to 95% (non-condensing) Vibration (maximum) 0.66 GRMS 1.30 GRMS Specifications of Inspiron 3593... - Page 20 0 m to 10,668 m (0 ft to 35,000 ft) * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse when the hard drive is in use. Specifications of Inspiron 3593...
-
Page 21: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. - Page 22 Table 27. List of keyboard shortcuts Function key Behavior Turn off/on wireless Pause/Break Sleep Toggle scroll lock Toggle between power and battery-status light/hard-drive activity light System request Open application menu Toggle Fn-key lock Page up Page down Home Keyboard shortcuts...
-
Page 23: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 28. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell Tips Contact Support In Windows search, type Contact Support, and press Enter.
