Avaya IP600 Installation Manual

Avaya IP600 Installation Manual

Rack mount cabinet installation
Hide thumbs Also See for IP600:

Advertisement

Quick Links

Download this manual
Rack Mount Cabinet Installation
This slide show summarizes the installation procedures for the
IP600 rack mounted cabinet (RMC).
Unpack and Inspect
Install the System Cabinet
Check AC Power and Ground
Cable the System
Install Patch Panel and External Modem
Install Circuit Packs
For detailed installation procedures, see the IP600 Installation and
Configuration document in the IP600 Reference section of this
CD.
Avaya IP600
–EXIT
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP600 and is the answer not in the manual?

Questions and answers

Related Manuals for Avaya IP600

Summary of Contents for Avaya IP600

  • Page 1 Install the System Cabinet Check AC Power and Ground Cable the System Install Patch Panel and External Modem Install Circuit Packs –EXIT For detailed installation procedures, see the IP600 Installation and Configuration document in the IP600 Reference section of this...

  • Page 2: Unpack And Inspect

    Items may vary slightly in appearance and may ship in separate packages. – For the IP600 offer, the following circuit packs (CPs) are always provided (as part of the bundled PEC): • TN795 Processor • TN744 Call Classifier / Detector •...
  • Page 3 Avaya IP600 Rack Mount Cabinet Installation . Install the system cabinet – Single cabinet systems can be rack-mounted (preferred) or floor- mounted. • Floor Mount: The bag of fasteners included with the primary cabinet has screw- in plastic feet. –...
  • Page 4 Avaya IP600 Rack Mount Cabinet Installation . Install the system cabinet • Let the weight rest on the screws while adding the other six screws; tighten all eight screws. • If installing a second cabinet, mount it above the first cabinet with minimum space between the cabinets.
  • Page 5 Avaya IP600 Rack Mount Cabinet Installation System grounding must comply with the general rules for grounding provided in Article 250 of the National Electrical Code (NEC), National Fire Protection Agency (NFPA) 70, or the applicable electric code in the country of installation.
  • Page 6 Avaya IP600 Rack Mount Cabinet Installation . Check AC power and ground (continued) – A recommended Uninterruptible Power Supply (UPS) may be used for power holdover. The type of UPS depends on the holdover requirements. The UPS must provide surge protection for the RMC cabinet.

  • Page 7: Cable The System

    Avaya IP600 Rack Mount Cabinet Installation . Cable the system – Install Processor Interface cable and the IP Media Processor adapter and 259A C-LAN adapter. See Figure 8 – Cable a two-cabinet system. • Remove the bottom panel and fan assembly (if not already removed) from the top cabinet (port cabinet).
  • Page 8 Figure 12 –EXIT Note that you may use a locally obtained, type-approved external modem (V.34 protocol). Contact your Avaya representative for more information. Warning: If you use a modem other than the U.S. Robotics modem, it must be configured in NT.
  • Page 9 Avaya IP600 Rack Mount Cabinet Installation – Install patch panel and shelf • Using the supplied mounting screws, mount the patch panels on the rack below the processor cabinet. • Using the supplied mounting screws, mount the shelf on the rack below the patch panels.

  • Page 10: Circuit Pack Installation

    • Install the TN795 Processor circuit pack in slot 2 of the cabinet. See • A TN744D Call Classifier/Tone Detector circuit pack is required. Slot 3 is preferred. • Load all port circuit packs. See the table in the IP600 installation manual for recommended layout. –EXIT...
  • Page 11 Avaya IP600 Rack Mount Cabinet Installation Figure 1 1. RMC Cabinet 2. Screws for rack mounting 3. IP Media Processor adapter 4. 259A adapter for C-LAN 5. Cabinet feet and screws 6. Processor Interface cable 7. Flash card 8. AC power cord 9.
  • Page 12 Avaya IP600 Rack Mount Cabinet Installation Figure 2 1. Rack mount hole spacing 2. Mounting screw –EXIT...
  • Page 13 Avaya IP600 Rack Mount Cabinet Installation Figure 3 –EXIT...
  • Page 14 Avaya IP600 Rack Mount Cabinet Installation Figure 4 Fan assembly –EXIT...
  • Page 15 Avaya IP600 Rack Mount Cabinet Installation Figure 5 A. Processor (lower) cabinet B. Optional Port (upper) cabinet –EXIT...
  • Page 16 Avaya IP600 Rack Mount Cabinet Installation Figure 6 650A Power Supply –EXIT...
  • Page 17 Avaya IP600 Rack Mount Cabinet Installation Figure 7 1. 10 AWG (#25) (6mm ) wire to coupled bonding connector (CBC) 2. 6 AWG (#40) (16mm2) ground wire from single point –EXIT ground block to the approved building ground...
  • Page 18 Avaya IP600 Rack Mount Cabinet Installation Figure 8 1. IP Media Processor adapter 2. 259A adapter for C-LAN 3. Processor Interface cable (slot 2) –EXIT...
  • Page 19 Avaya IP600 Rack Mount Cabinet Installation Figure 9 1. EMI gasket between cabinet 2. TDM/LAN bus terminators –EXIT...
  • Page 20 Avaya IP600 Rack Mount Cabinet Installation Figure 10 1. Cabinet B routing slot plate 2. Cabinet A routing slot plate –EXIT...
  • Page 21 Avaya IP600 Rack Mount Cabinet Installation Figure 11 1. Cabinet B routing slot plate 2. Cabinet A routing slot plate 3. TDM/LAN bus cable –EXIT...
  • Page 22 Avaya IP600 Rack Mount Cabinet Installation Figure 12 1. Circuit pack amphenol connectors and B25A cables 2. Processor Interface cable 3. External modem 4. P2 termination of processor interface cable attached to modem 5. 24-port patch panel 6. 8-port patch panel...
  • Page 23 Avaya IP600 Rack Mount Cabinet Installation Figure 13 1. ESD ground jack 2. 650A power supply 3. TN795 processor circuit pack 4. TN744D call classifier/tone detector 5. TN2301 Media Processor 6. TN799C C-LAN 7. Accessory compartment –EXIT 8. Fiber optic pass-through...
