RouterNode, GatewayNode

4 design and construction

Version
WNM.RN.R(.IO)
WNM.RN.CC(.IO)
WNM.RN.CR(.IO)
WNM.RN.EC(.IO)
EN
Depending on the version, the equipment of your
RouterNode differs:
Screw an-
tenna
✔
✔
RN = RouterNode

C = Cable (RS-485 via clamp connection)

R = Radio

E = Ethernet via RJ45 connection

Older generations of RouterNodes (recognisable by
WN.RN.XX) cannot yet be configured automatically.
4. design and construction
Screw antenna
LED
Init button
+
Power supply
-
RS-485
Ethernet
RS-485
✔
✔
✔
Ethernet
✔
25 / 108
