Technical Data - Main Mitre-AS Installation And Service Instructions Manual

Gas fired -instantaneous sink water heater
Table of Contents

Advertisement

Page 1
Ventilation
Fixing
Water connection
Water spout connection
Gas connection
Commissioning appliance
Checking burner pressure
Servicing instructions
To remove case front
To remove spark igniter
To remove. thermocouple/pilot/spark electrode
To remove heating unit
To remove electro. mag. unit
To remove burner assembly and injectors
To remove slow ignition diaphragm
To remove water diaphragm
Short spare parts list

TECHNICAL DATA

DIMENSIONS
Overall mm (in)
WEIGHT EMPTY
kg (1b)
Nominal heat input 11.6 KW : 39,580 Btu/h.
Nominal heat output 8.7 KW : 29,685 Btu/h.
HEIGHT
WIDTH
483 (19)
216 (81/2)
7.25 (16)
DEPTH
210 (8 1/4) Not including
swivel spout
