Use < and > to move the cursor over the ADDRESS (suite number) and/or VID number to EDIT.
Press ENT to save changes. Press BCK to return to the previous screen(s).
Note: Selecting <DEL> while a device is highlighted will result in the following action:
- If ENROLLED, it will be removed from the NMC list.
- If MISSING, it will be removed from the NMC list
- If UNKNOWN, it will be added to the MISSING category.
Note: Enrolled ISD units only will have their Green LED 'Flicker' during communications with the NMC.

5.14 Removing an ISD from the Network

If a working ISD is to be removed from the network and is to be reused at a later date, or used on a different
network, it should be removed from the NMC network to which it is currently assigned. If the ISD is not removed, it
will display as a Missing device and put the NMC into trouble. If used in another building's network without being
removed, it will show up as an Unknown device.
Use this option to remove an inoperable ISD unit as well before installing a replacement unit. Leave or re-install
the ISD into any AC outlet.
Select [CONFIGURE]
Use < or > to select the desired unit. Press ENT to commence ISD removal.
ADMINISTRATION
TESTS
>CONFIGURE
UP DWN ENT BCK
NOTICE: TO PURGE THE ENTIRE ISD LIST FROM THE NMC, PRESS '8' AND '9'
SIMULTANEOUSLY WHILE IN THE 'REMOVE ISDS' menu. ISD addresses will be shown being
removed.

5.15 Adding an ISD VID number manually

Access Level 3
This process will add an ISD manually to the network via the NMC Keypad without retrieving the VID #
automatically.
.
Select [CONFIGURE]
ADMINISTRATION
TESTS
>CONFIGURE
UP DWN ENT BCK
Enter the 5 digit ADDRESS of the ISD (suite number or room number) followed by ENT. The suite number should
be entered such as: 00103 or 0206B. Refer to Section 5.10 if you wish to designate it as a 'Message Unit'.
Mircom Technologies Inc
[CONFIGURE ISD] [REMOVE ISDS].
CONFIGURE NMC
>CONFIGURE ISD
UP DWN ENT BCK
[CONFIGURE ISD] [MANUAL SET ADDR]
CONFIGURE NMC
>CONFIGURE ISD
UP DWN ENT BCK
EDIT ADDR
>REMOVE ISDS
AUTO-PRGM ISDS
UP DWN ENT BCK
>MANUAL SET ADDR
AUTO SET ADDR
EDIT ADDR
UP DWN ENT BCK
All Rights Reserved
Page 33 of 54
Installation and Programming Manual
NETWORK ID: XXXXX
ADDRESS: XXXXX
VID: XXXXXXXX
< > ENT BCK
NETWORK ID: XXXX
ADDRESS: XXXXX
VID: XXXXXXXX
< > ENT BCK
