5.7 Entering the Date and Time

Access Level 1
Select [ADMINISTRATION]
DISPLAY VERSION
>ADMINISTRATION
TEST
UP DWN ENT BCK
The date is MM/DD/YY format
The time is 12 hour HH:MM
When the cursor is over the AM/PM digit, press 1 to change to AM, or press 7 to change to PM. Press 'ENT',
then 'BCK' out of programming. The time must be changed manually for Daylight Savings Time adjustments.

5.8 Alarm and Trouble Logs

Access Level 1
There are a total of 900 entries combined for alarm and trouble log archival. Once this number is surpassed, the
oldest entry will be dropped from history and replaced with the newest.
Select [ADMINISTRATION]
DISPLAY VERSION
>ADMINISTRATION
TEST
UP DWN ENT BCK

5.9 Resetting the NMC to the Factory Defaults (required after an NMC firmware update)

Access Level 3
To reset the Factory Defaults, select [CONFIGURE]
DEFAULT].
ADMINISTRATION
TESTS
>CONFIGURE
UP DWN ENT BCK
WARNING:
RESET FACTORY
DEFAULTS?
CONT BCK
There will be a 1 second delay between displays of 'Resetting Pass codes', Followed by 'Resetting System
Parameters', 'Resetting ISD Settings' (20 sec),'Resetting Trouble Logs', 'Resetting Alarm Logs', completing by the
final acknowledgement of 'Factory Defaults Set'.
Mircom Technologies Inc
[SET DATE/TIME]
>SET DATE/TIME
VIEW LOGS
CHANGE MSG UNIT
UP DWN ENT BCK
[VIEW LOGS]
SET DATE/TIME
>VIEW LOGS
CHANGE MSG UNIT
UP DWN ENT BCK
>CONFIGURE NMC
CONFIGURE ISD
UP DWN ENT BCK
RESETTING NMC TO
FACTORY DEFAULTS
PLEASE WAIT.....
CONT BCK
All Rights Reserved
11/23/04 17:35AM
DD/MM/YY HH:MM
< > ENT BCK
ALARM LOGS
TROUBLE LOGS
UP DWN ENT BCK
[CONFIGURE NMC]
>NMC NETWORK
SYST PARAMETERS
CONFIG RELAYS
UP DWN ENT BCK
Page 29 of 54
Installation and Programming Manual
[NMC NETWORK]
>FACTORY DEFAULT
UP DWN ENT BCK
LT-1034 Rev.1
