- Page 1 RO35C READ THE OPERATING INSTRUCTIONS BEFORE SWITCHING ON THE SYSTEM! KEEP IT IN THE IMMEDIATE VICINITY OF THE MACHINE AT ALL TIMES! Original operating instructions OPERATING INSTRUCTIONS V1.0 04/20...
-
Page 2: Table Of Contents
HydroPower® RO35C Content Introduction ........................ 4 General information ..................... 4 Intellectual and industrial property rights ............4 Property and legal deficiencies ................4 Explanation of signs ..................... 5 1.4.1 Instructions for use ..................5 1.4.2 Enumerations ..................... 5 1.4.3 Hazard classes .................... 6 1.4.4 Warning signs .................... - Page 3 HydroPower® RO35C Content Preparing for use ....................... 15 Construction of the HydroPower RO ..............15 Interfaces ......................15 Transport and storage ..................16 4.3.1 Transportation .................... 16 4.3.2 Storage ...................... 17 4.3.3 Operation the HydroPower RO ..............17 Commissioning ....................18 Operation of the HydroPower RO ................
-
Page 4: Introduction
Claims for material and legal deficiencies presuppose that the operator shall submit the defect in writing without delay, but at the latest within two working days. Unger Germany GmbH is in no case responsible for damage to the system itself, or damage caused by the unit due to improper handling of the product. -
Page 5: Explanation Of Signs
HydroPower® RO35C Explanation of signs Explanation of signs 1.4.1 Instructions for use Instructions for use are shown as follows: To perform an action, proceed as follows: 1. Do this. 2. Do that. This is the intermediate result. 3. Do that. You have completed the action. -
Page 6: Hazard Classes
HydroPower® RO35C Explanation of signs Hazard classes 1.4.3 Safety instructions are shown in this manual with standardized illustrations and symbols. Depending on the probability of the occurrence and severity of the consquence, the following hazard classes are used: DANGER Indicates a hazardous situation that can lead to serious injury or death. Here you will find measures to avoid the danger. -
Page 7: Warning Signs
HydroPower® RO35C Explanation of signs Warning signs 1.4.4 Warning of a hazard. Warning of electrical voltage. Warning of overpressure in containers. Warning of hot surfaces. Warning of suspended loads. Warning of injury to the limbs. Mandatory signs 1.4.5 Application tips and other useful information. Use protective gloves. -
Page 8: Nameplate
HydroPower® RO35C Obligations Nameplate Each HydroPower RO from Unger Germany GmbH has a nameplate on the side. Pic. 1 Nameplate Obligation of the operator The HydroPower RO is used in the commercial sector. The operator must adhere to the statutory obligations to work safety. -
Page 9: Training Of Staff
Contact address Unger Germany GmbH Piepersberg 44 42653 Solingen Germany Telefon: (49) 0212 / 22 07–0 Fax: (49) 0212 / 22 07–2 22 service@ungerglobal.com... -
Page 10: About Hydropower Ro
HydroPower® RO35C Technical specifications About HydroPower RO Verwendung des HydroPower RO Intended use 2.1.1 The HydroPower RO is used for the filtration of drinking water by demineralisation for the purpose of glass and surface cleaning. The HydroPower RO is intended for commercial use only. The HydroPower RO may only be connected to drinking water lines. -
Page 11: Pressure Ratings
HydroPower® RO35C Technical specifications Pressure ratings 2.2.4 Input pressure [bar] 1... 6 Max. operating pressure [bar] Dimensions quick overview 2.2.5 Height [mm] 1070 Width [mm] Depth [mm] Empty weight [kg] 72 kg Media connections 2.2.6 Standard feedwater connection thread ["] Standard concentrate connection thread ["] Standard permeate connection thread ["] 2x 3/4... -
Page 12: Safety
HydroPower® RO35C General safety regulations Safety General safety regulations Basic principles 3.1.1 Special safety regulations may apply to certain activities. Safety instructions and warnings are given in the respective sections of the operating instructions. Operate the HydroPower RO only: • in accordance with the operating instructions for safety and driving safety •... -
Page 13: Mechanical Hazards
Before each use, perform a visual inspection of the power cable for damage. If you notice any damage, contact your distributor. Maintenance on the electrical components of the system may only be carried out by employees of Unger Germany GmbH or their authorized specialist dealers / technicians. Thermal hazards Burns due to hot surfaces. -
Page 14: Hazards From Materials And Substances
HydroPower® RO35C General safety regulations Hazards from materials and substances The safety data sheets of the materials and substances can be found online at www.ungerglobal.com/downloads-safety-data-sheets. Irritation to the eyes, skin and respiratory tract through carelessness. Avoid any contact with the resin when replacing the DI resin cartridge. In case of contact with eyes, remove contact lenses and rinse immediately with plenty of water. -
Page 15: Preparing For Use
HydroPower® RO35C System overview Preparing for use Construction of the HydroPower RO Manometer 1 1 2 2 3 3 TDS-Meter On TDS-Meter Display RO-Membrane 1 RO-Membrane 2 Water flow controller DI resin filter Carbon/sediment combi pre-filter Water inlet 10 2 x Water outlet 11 Main switch (On / Off) 12 Pump Reset 13 Pump ventilation slot... -
Page 16: Transport And Storage
HydroPower® RO35C Transport and storage Transport and storage Transport 4.3.1 The HydroPower RO is delivered on a pallet by a forwarding company. The HydroPower RO is carefully tested and packaged before shipment. However, damage during transport cannot be ruled out. Therefore, immediately check the HydroPower RO for integrity in the presence of the dealer. -
Page 17: Storage
HydroPower® RO35C Operating the HydroPower RO Storage 4.3.2 If the unit is not in use for more than 7 days, the membranes must be protected according to the storage instructions, see chapter „7.2.4 Membrane protection“. Operating the HydroPower RO 4.3.3 Carbon/sediment combi pre-filter RO membrane 1 RO membrane 2... -
Page 18: Commissioning
HydroPower® RO35C Commissioning Commissioning CAUTION Slight injuries due to pressurized containers possible. The 4 filter vessels are pressurized during operation. Never open a filter vessel during operation. Check if the hoses and tubes are water-tight and fit properly before commissioning the system. Use protective gloves. - Page 19 HydroPower® RO35C Commissioning 4.4.1. Commissioning of new or preserved RO35C: The resin filter is not used in new or preserved units, as it must not come into contact with the diaphragm care agent. Before using the resin filter, the membrane maintenance agent must be completely rinsed out. 1.
-
Page 20: Operation Of The Hydropower Ro
HydroPower® RO35C Operation Operation of the HydroPower RO General information Working with the HydroPower RO is only permitted if the operating instructions have been read and understood. DANGER Severe injuries and property damage due to the HydroPower RO falling are possible. -
Page 21: Cleaning Surfaces With The Hydropower Ro / Normal Operation
We recommend regulating the water pressure between the 2 hoses, especially with height differences, with a valve. For example the UNGER hose connection # 18330 incl. water switch or the UNGER HiFloControl # TMOOV, regulate the water quantity at the water fed pole. -
Page 22: Switching Off The Hydropower Ro
HydroPower® RO35C Switching off Switching off the HydroPower RO To switch off the HydroPower RO after finishing the work, proceed as follows: 1. Switch off the unit with the main switch. 2. Disconnect the power supply and the water supply. 3. - Page 23 HydroPower® RO35C Malfunctions Overheating Always ensure that the HydroPower RO is well ventilated and is not too close to objects or walls which could cause air circulation prevent. 1. If the pump motor overheats, the HydroPower RO automatically. 2. Switch off the system at the main switch on the side. 3.
-
Page 24: Maintenance And Servicing
DANGER Electric shock possible through live parts. Maintenance on the electrical components of the system should only be carried out by employees of Unger Germany GmbH or their authorized specialist dealers / technicians. CAUTION Burns due to hot surfaces possible. -
Page 25: Maintenance And Maintenance Plan
If the unit will not be in use for more than 7 days, the membrane must be protected according to the storage instructions, see chapter „7.2.4 Membrane protection.“ If the membrane is not regularly flushed or protected with the UNGER membrane care agent, there is a risk of blockage and thus a strong performance limitation or damage. -
Page 26: Membrane Protection
If the HydroPower RO is not in use for an extended period of time (longer than 7 days), the membrane must be protected against blockage. For this purpose, there is the UNGER Membrane Care Agent (Order No. 15436). You need one bottle (1l) for each membrane. This preserves the current state of the membrane and prevents reduced performance and/ or damage after sitting for a longer period of time. -
Page 27: Repair And Replacement Of Parts
HydroPower® RO35C Replacing filter cartridges Repair and replacement of parts You will find a spare part list on the Unger website www.ungerglobal.com/RO with parts that you can change yourself. For any further repairs, please contact your dealer. Replacing filter cartridges 7.3.1... - Page 28 HydroPower® RO35C Replacing filter cartridges Inserting the filter cartridges Insert a new filter cartridge into the HydroPower RO the right way round. Carbon sediment combi prefilter (#1) Here it does not matter how the filter is inserted. RO Membranes (#2+#3) The 2 RO-membranes have an imprint indicating the flow direction, the arrow must point upwards.
-
Page 29: Switching Off The Device
DANGER Electric shock and burns due to live parts possible. Maintenance on the electrical components of the system may only be carried out by employees of Unger Germany GmbH or their authorized specialist dealers / technicians. CAUTION Burns due to hot surfaces possible. -
Page 30: Recycling
In order to avoid danger to the environment, an approved specialist company is to be commissioned to dispose of the filter cartridges. The local authority can provide information on this. Return the HydroPower RO for disposal to Unger Germany GmbH. www.ungerglobal.com... - Page 31 HydroPower® RO35C Notes...
-
Page 32: Proofreading Documents
