Information Sheet
IS03013
NARB14
Dual ND500II
(IP66)
IS03013
Original Issue
29 October 2003
Nautel Limited
10089 Peggy's Cove Road,
Hackett's Cove, NS, Canada B3Z 3J4
T.+1.902.823.2233 F.+1.902.823.3183
info@nautel.com
U.S. customers please contact:
Nautel Maine, Inc.
201 Target Industrial Circle, Bangor ME 04401
T.1.207.947.8200 F.1.207.947.3693
info@nautel.com
e-mail: support@nautel.com
www.nautel.com
 Copyright 2003 NAUTEL. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dual ND500II and is the answer not in the manual?

Questions and answers

Related Manuals for Nautel Dual ND500II

Summary of Contents for Nautel Dual ND500II

  • Page 1 10089 Peggy's Cove Road, Hackett's Cove, NS, Canada B3Z 3J4 T.+1.902.823.2233 F.+1.902.823.3183 info@nautel.com U.S. customers please contact: Nautel Maine, Inc. 201 Target Industrial Circle, Bangor ME 04401 T.1.207.947.8200 F.1.207.947.3693 info@nautel.com e-mail: support@nautel.com www.nautel.com  Copyright 2003 NAUTEL. All rights reserved.

  • Page 3: Cabinet Description

    SHTDN ALM main/standby dual installation. See figure 3A1J5-23 from A11J4-17 ('shutdown') 2A or 2B for interconnecting detail. See of transmitter B. NARB14 Dual ND500II (IP66) – IS03013 Page 1 Information Sheet Issue 1.0...

  • Page 4: Installation Information

    10mm and 17mm. of transmitter A, causing a ground to The smaller hole is intended for remote be applied to outputs RMT CHGOV ALM control wiring (plugged if not used). NARB14 Dual ND500II (IP66) – IS03013 Page 2 Issue 1.0 Information Sheet...

  • Page 5: Initial Start-Up Procedures

    Verify that pre-routed AC power cable control mode, using their front panel W1 is connected between transmitter switches. A's AC power cable receptacle (1U2) and the cabinet's AC power duplex receptacle (J2). NARB14 Dual ND500II (IP66) – IS03013 Page 3 Information Sheet Issue 1.0...

  • Page 6: Set Power

    A user-provided coaxial cable should be Connect the antenna system to obtained. transmitter B’s RF output (2A7J2). Feed the cable through the front of the dual cabinet if necessary. NARB14 Dual ND500II (IP66) – IS03013 Page 4 Issue 1.0 Information Sheet...
  • Page 7 Remove jumper connected in step (c). switch (S3) to and then POWER return it to switch of both transmitters POWER and set their LOCAL/REMOTE switches to the desired position. NARB14 Dual ND500II (IP66) – IS03013 Page 5 Information Sheet Issue 1.0...

  • Page 8: Battery Status

    If an external DC power supply is used as voltage source for external SWR ALARM circuits, connect DC return to 3A1TB3-7 (3A1J1-6). BATTERY STATUS Figure 1 External Control/Monitor Interconnecting Wiring NARB14 Dual ND500II (IP66) – IS03013 Page 6 Issue 1.0 Information Sheet...
  • Page 9 Table 1 - Wiring List – NARB14 Dual ND500II Transmitters Cabinet SOURCE DESTINATION CODE SIZE REMARKS P1-Centre P5-Centre Core RG188A/U Coaxial Cable P1-Body P5-Body Shield P4-Centre P9-Centre Core RG188A/U Coaxial Cable P4-Body P9-Body Shield P6-1 P2-24 White P6-2 P2-13 White...
  • Page 10 Table 1 - Wiring List – NARB14 Dual ND500II Transmitters Cabinet (Cont.) SOURCE DESTINATION CODE SIZE REMARKS P7-Centre P11-Centre Core RG58A/U Coaxial Cable P7-Body P11-Body Shield P10-Centre J1-Centre Core RG58A/U Coaxial Cable P10-Body Safety Ground Shield 3A1TB4-3 1A11TB2-1 White 3A1TB4-4...
  • Page 11 Table 2 - Reference Designation Index – NARB14 Dual ND500II Transmitter Cabinet NAME OF PART NAUTEL JAN/MIL/OEM CODE AND DESCRIPTION PART NO. PART NO. CODE Cabinet, Dual ND500II, IP66, 115 VAC NARB14/01 158-8200-01 37338 Cabinet, Dual ND500II, IP66, 230 VAC...
  • Page 12 163-5003-01 163-5003-01 37338 Socket, Relay 163-5003-01 163-5003-01 37338 Socket, Relay 163-5003-01 163-5003-01 37338 Socket, Relay 163-5003 163-5003 37338 NOTE: Prefix with 3A1 to obtain item’s full reference designation. NARB14 Dual ND500II (IP66) – IS03013 Page 10 Issue 1.0 Information Sheet...
  • Page 13 DENOTES TB6 SERVO INHB RMT SHTDN ALM RMT CHGOV ALM Dimensions = mm (inches) Figure 2A - Electrical Schematic - Dual ND500II Transmitter System (NARB14/01 & /02, no Remote Control Unit) Version 1.0 Not to Scale Drawing No. Sheet 1 of 1...
  • Page 14 SOURCE LINE RMT SHTDN ALM RMT CHGOV ALM Dimensions = mm (inches) Figure 2B - Electrical Schematic - Dual ND500II Transmitter System (NARB14/03 & /04, w/ Remote Control Unit) Version 1.0 Not to Scale Drawing No. Sheet 1 of 1...
  • Page 15 EXT RF INPUT (A) EXT RF INPUT (A) K1:E +24VDC (A) 15 J1 1N5624 RMT PWR TRIM (A) RMT PWR TRIM (A) RMT SHTDN ALM STBY 1 (A) K1:A STBY 1 (A) +24V RMT XMTR ON STAT 1N5624 +24VDC (B) 10 K1:B DC SUPPLY DC SUPPLY...
  • Page 16 Dimensions = mm (inches) Figure 4 – Assembly Detail/Dimensional Information – Dual ND500II Transmitters (IP66 NARB14 Cabinet) Version 1.0 Not to Scale Drawing No. Sheet 1 of 1...
  • Page 17 Dimensions = mm (inches) Figure 5 - Assembly Detail – NAX223 Dual Transmitter Interface Assembly Version 1.0 Not to Scale Drawing No. Sheet 1 of 1...
  • Page 18 Dimensions = mm (inches) Figure 6 - Assembly Detail – NAPI66 Dual Transmitter Interface PWB Version 1.0 Not to Scale Drawing No. Sheet 1 of 1...
