Interlogix AS502 Installation Sheet page 3

7 (AS502)
9
LED explanation
Green LED Red LED
Flashing Slow Off
Off Flashing Fast
Off Constant On
Off Flashing Slow Low voltage alarm timer expired
ATTENTION!
This product contains a NiCd or Lead Acid-battery.
This battery may be recyclable, but it may be illegal to
dispose of this battery improperly under local, state or
federal laws.
Check with your local authorities for disposal and
recycling options.
P/N 144420999-2 (EN) • REV B • ISS 28FEB19
J10
J8
J9
RED +
To battery
BS121N
BLACK -
1 2 3 4
13.0 -
14.2 VDC
Beacon Siren +12 V 0 V
DC
Siren status
Okay
Siren Hold Off or Low voltage alarm
Siren Hold Off timer expired
8 (AS522)
J10
J8
J9
11
RED +
5 6
Tamper Tamper
4
J8
J9
4700 Ω
5 33 Ω
EOL
Tamper
6
CAUTION!
Risk of explosion if battery is replaced by an
incorrect type.
Replace only with the same or equivalent
type recommended by the manufacturer.
III
J10
J8
J9
Cut J10 to disable the LED function
BLACK -
BS170
Tamper Loop (T5/T6)
J9 Tamper EOL
GND -
GND 4700
Isolated -
4700 Ω
Isolated
Ω
3 / 4
