Summary of Contents for Ickle Bubba Astral
- Page 1 Astral Car Seat Recommended Recommended Mass Group Weight 0-12 months 0-13kg (approx.) IMPORTANT – Read the instructions carefully before use and keep for future reference...
-
Page 2: Table Of Contents
Contents Contents Safety Warnings Car Seat Features Opening the Harness Using the Harness Adjusting the Shoulder Straps Checking the Child is Correctly Fitted Installing the Car Seat Installing on to Pram Adjusting the Handle Position Fitting the Hood Product Maintenance Warranty v.02.20... -
Page 3: Safety Warnings
Safety Warnings WARNING: Read this instruction manual carefully. Study the illustrations in this manual closely before and during installation. Our product is a safety product that is only safe when used according to the instructions given in this manual. To prevent your child from falling out of the seat, always check to make sure the carrying handle is clicked into the carrying position before lifting the seat. - Page 4 Safety Warnings The moving parts of the baby car seat should not be lubricated in any way. No alterations may be made to the baby car seat, as this could affect part or the overall safety of the seat. The baby car seat must not be used without its cover. Always use an original cover, as the cover contributes to the safety of the seat.
-
Page 5: Car Seat Features
Car Seat Features 1. Button for Adjusting 6. Handle Handle 7. Sunshade/Hood 8. Shoulder Straps Slots 2. Adjuster Strap 3. Cloth Cover 9. Slot for Vehicle Shoulder 4. Buckle Strap 5. Shoulder Strap 10. Slot for Vehicle Lap Strap Opening the Harness 1.Open the buckle (press the red button of the buckle);... -
Page 6: Using The Harness
Using the Harness click! 1. Put the two buckle latches together (Figure 1) 2. Put locked latches into the safety buckle, When you hear a "click", it means that the safety buckle has been completely locked (Figure 2) Attention! When inserting locked latches into buckle, make sure to hear a clear "click"... -
Page 7: Adjusting The Shoulder Straps
Using the Harness Releasing the Harness You can release your child from the car seat by pressing the red button on the buckle. Please make sure that the buckle latches are not catching or hooking the child's clothes. Adjusting the Shoulder Straps There are 2 sets of positions for the shoulder straps. -
Page 8: Installing The Car Seat
Installing the Car Seat The type of vehicle belt needed: The child seat can only be installed on the front or back seats equipped with shoulder and lap straps. This child car seat is only suitable when the vehicle seat is equipped with 3-point safety belts with retractor, approved to GB 14166 or ECE R16. - Page 9 Installing the Car Seat Install the infant car seat rearward-facing on the vehicle seat and ensure that it is close to the backrest of the vehicle seat (Figure 1) Put the lap strap of vehicle belt across the slots in the infant car seat and insert the latch of the vehicle belt into its buckle (Figure 2) IMPORTANT: Once fitted, the vehicle seat belt and the handle of the infant car seat cannot be located in the position shown in Figure 2.
-
Page 10: Installing On To Pram
Installing on to Pram v.02.20... -
Page 11: Adjusting The Handle Position
Adjusting the Handle Position To adjust the position of the handle, press the red buttons on both sides of the handle and adjust it to the position you want. There are 4 possible positions: 1. To be used when installing in the car 2. -
Page 12: Product Maintenance
Product Maintenance General Remove the car seat from the car before carrying out any maintenance work. The seat can be cleaned with soap and lukewarm water. Do not use any abrasive detergents. The belt buckle can be cleaned using warm water. Do not lubricate. -
Page 13: Warranty
Warranty We guarantee that this product was manufactured in accordance with the current European safety requirements and quality standards applicable to this product, and is free from defects in workmanship and material at the time of purchase. During the production process the product was subjected to various quality checks.
