- Page 1 Description Full Height Turnstile MPT-333 MGC control unit Doc.ID: 5817,0027EN Version 00...
- Page 2 MGC control unit MAGNETIC AUTOCONTROL GMBH Grienmatt 20 D-79650 Schopfheim Germany Phone +49 7622 695 5 Fax +49 7622 695 802 info@magnetic-germany.com www.magnetic-access.com...
-
Page 3: Table Of Contents
MGC control unit Contents Contents Notes on the document Purpose and contents of this description Symbols and illustrations used in this document 1.2.1 Warning notes and notes Target group 1.3.1 Personnel – activities and qualifications Digital inputs, digital outputs and relay outputs Digital inputs Digital outputs and relay outputs Digital power outputs of the MFM01 plug-in modules... - Page 4 MGC control unit Contents Menu "In-/Outputs" 4.3.1 Inputs 4.3.2 Outputs Menu "Service" 4.4.1 Gate HW 4.4.2 Further parameters Menu "System" Menu "Passage counter" Menu "Information" Menu "Factory settings" Function description Versions and definitions Function sequence Start-up and regular movement sequence Operation modes 5.4.1 Pulse operation in both directions...
-
Page 5: Notes On The Document
Gate Controller 4915.1006 Table 1: Programme versions MGC control unit IMPORTANT! For information on design and function, for technical data, installation and assembly, electrical connection, commissioning and cleaning and maintenance, see the separate operating instructions "Full height turnstile MPT-333 (Doc.ID: 5817,0028)". -
Page 6: Symbols And Illustrations Used In This Document
MGC control unit Notes on the document Symbols and illustrations used in this document 1.2.1 Warning notes and notes Warning notes are characterised by pictograms in these operating instructions. A warning note starts with a signal word that expresses the extent of the hazard. -
Page 7: Target Group
MGC control unit Notes on the document Notes and recommendations IMPORTANT! The signal word IMPORTANT highlights useful notes and recommendations as well as information for an efficient and trouble-free operation. Target group 1.3.1 Personnel – activities and qualifications All work on the control unit may only be carried out by technicians and electricians with the following qualifications. -
Page 8: Digital Inputs, Digital Outputs And Relay Outputs
MGC control unit Digital inputs, digital outputs and relay outputs Digital inputs, digital outputs and relay outputs WARNING Improper wiring and parameterisation of the control unit! Improper wiring and parameterisation of the control unit can lead to undesired functions and thus to injuries. ›... - Page 9 MGC control unit Digital inputs, digital outputs and relay outputs Clamp Function – Inputs that you assign this function "–" to are being deactivated. | Emergency open Emergency situation (Fail Safe) Connect fire service switches, emergency opening contacts, etc. to this input.
-
Page 10: Digital Outputs And Relay Outputs
MGC control unit Digital inputs, digital outputs and relay outputs Digital outputs and relay outputs ä For the definition "Entry" and "Exit" see Page 40, chapter 5.1. By parameterising the outputs, you assign certain functions to the outputs. If the function is marked with "|", the output is inverted (Fail Safe). The following functions are assigned to the outputs as default settings. - Page 11 MGC control unit Digital inputs, digital outputs and relay outputs Function Function Passage free entry Control of display "Passage in zone controlled direction cleared" When the passage in the zone controlled direction is cleared, a permanent signal is emitted via this exit. This exit may also be used to block a pulse encoder such as a card reader for the opposite direction.
-
Page 12: Digital Power Outputs Of The Mfm01 Plug-In Modules
MGC control unit Digital inputs, digital outputs and relay outputs Digital power outputs of the MFM01 plug-in modules The control unit is equipped with the plug-in module MFM01 with the function "Magnets for locking". Furthermore, the control unit can be equipped with additional plug-in modules MFM01. -
Page 13: Parameterising Control Unit
MGC control unit Parameterising control unit Parameterising control unit Changing menu language The default setting in the MGC control unit is the menu language "English". Change the menu language as follows: The operational view is displayed. FlowMotion MPT333 – – –... - Page 14 MGC control unit Parameterising control unit The "Main menu" menu is displayed. The "Setup" menu has a dark background and is thus selected. Main menu Setup In-/Outputs Service System Fig. 4: View "Main menu – Setup" Select the menu "System" with the two middle buttons « », «...
- Page 15 MGC control unit Parameterising control unit Confirm selection with the right button « ». The following view is displayed. The menu language "English" is chosen. Language English French Spanish Fig. 7: View "Language - English" Select the language "German" with the two middle buttons « », «...
- Page 16 MGC control unit Parameterising control unit Use the left button « » to leave the "Language" menu. The safety prompt "Save changes? " appears. Language Save changes? Fig. 10: View "Safety prompt – Save changes?" Push the left button « »...
-
Page 17: Entering Password
MGC control unit Parameterising control unit Entering password You need to enter a password in the following cases: › You would like to change parameters in the control unit and the password protection was activated. › You would like to reset the parameters to factory settings. If a password is required, the following view is displayed: Passwort –... -
Page 18: Control Unit Elements
MGC control unit Parameterising control unit Use the right button « » to select the fourth digit of the password. The following view is displayed: Passwort Fig. 14: View "Enter fourth digit of the password" Use the two middle buttons « », «... -
Page 19: Displays Of The Control Unit
– – – – Fig. 16: Example "Operational View" Type pedestrian gate here MPT-333 electromotive Status display, here ready for operation Angle of rotation, here 0 Current function of the right control button, here calling menu "Main menu" Validations exit, here locked... -
Page 20: Symbols In The Display
MGC control unit Parameterising control unit Symbols in the display 3.5.1 Control button functions The control unit is equipped with 4 control buttons. The function of the control buttons change depending on the current view in the display. The current functions are shown in the display. -
Page 21: Further Symbols
MGC control unit Parameterising control unit 3.5.2 Further symbols Clamp Description Wrong password entered. Access denied. Reset values to factory settings. To do this, you must enter the password "0000". The next validation is blocked by the random function. There is information. Check the "Information" menu. To do this, press the left operating button. -
Page 22: Setting Display Contrast
MGC control unit Parameterising control unit Setting display contrast The display contrast of the control unit is adjustable after activation while the logo is still displayed. The logo is displayed for 3 seconds. If you push one of the middle buttons « », «... - Page 23 MGC control unit Parameterising control unit 11. If the changes are to be saved, press the right button « ». The new hold- open time is activated. If the changes are not to be saved, press the left button « ».
-
Page 24: Switching The "Service" Mode On And Off
MGC control unit Parameterising control unit Switching the "Service" mode on and off In service mode, all opening signals are ignored. Switch on mode "Service" Switch the "Service" switch for the "Service" mode. The LED lights red. The display backlighting flashes. Switch off mode "Service"... -
Page 25: Description Of Menus And Parameters
MGC control unit Description of menus and parameters Description of menus and parameters Menu "Information" Call and navigate The operational view is displayed. ä Page 13, Fig. 2. Press left button « ». Use the left button « » to scroll within the menu. The "Information"... -
Page 26: Menu "Setup
MGC control unit Description of menus and parameters Menu "Setup" 4.2.1 Hold-open time Operational view > Main menu > Setup > Hold-open time Parameter Description Hold-open time Set the hold-open time. The hold-open time is started by an opening pulse by a control device, such as a card reader. -
Page 27: Interlock
MGC control unit Description of menus and parameters 4.2.3 Interlock Operational view > Main menu > Setup > nterlock Parameter Description Interlock Activate and deactivate the "Interlock" function. If the interlock has been activated, further rotation of the centre pillar is blocked for 1 second after each pass. -
Page 28: Signalling
MGC control unit Description of menus and parameters 4.2.5 Signalling Operational view > Main menu > Setup > Signalling Parameter Description Buzzer/Siren Activate events for which an acoustic signal is to be triggered. Connect the acoustic signal to the "Buzzer/Siren (alarm)" output. An acoustic signal is possible for the following events: ›... -
Page 29: Random Function
MGC control unit Description of menus and parameters 4.2.6 Random function The MGC control unit is equipped with the "random function" option. This function allows random bag and identity control of persons. If a hit was generated by the random function and the next validation is blocked by the random function, the following symbol appears on the display of the control unit: «... - Page 30 MGC control unit Description of menus and parameters Operational view > Main menu > Setup > Random function Parameter Description Hit range The function depends on the selected mode. For the "Counting" mode, use this parameter to set the value at which a hit is to be generated.
-
Page 31: Menu "In-/Outputs
MGC control unit Description of menus and parameters Operational view > Main menu > Setup > Random function Parameter Description Direction Select the passage direction for which the random hits are to be generated. Options › Both: Random hits occur in both passage directions. With this option, validations are not deleted. -
Page 32: Menu "Service
"Invert magnet RL1" and "Invert magnet RL2". Possible configurations: ä Page 34, Table 18. For the conversion of the locking, see separate operating instructions "Full height turnstile MPT-333 (Doc.ID: 5817,0028)". Operational view > Main menu > Service > Gate HW Parameter Description... - Page 33 MGC control unit Description of menus and parameters Operational view > Main menu > Service > Gate HW Parameter Description Exit direction Unless otherwise ordered, the turnstile is delivered for the "Entrance side right" design. The control unit is parameterised accordingly. If the version "entrance side right"...
- Page 34 MGC control unit Description of menus and parameters Installation version magnets and settings MGC The following installation versions are possible for the magnets RL1 and RL2. The settings for the parameters "Invert RL1" and "Invert RL2" depend on the installation version. The parameter "exit direction"...
-
Page 35: Further Parameters
MGC control unit Description of menus and parameters 4.4.2 Further parameters Operating view > Main menu > Service Parameter Description Cycles Display of complete passage procedures. Lifetime Display operating hours counter. The operating hours counter records the time, during which the pedestrian gate is supplied with electrical power. System time Displays the internal date and the internal clock. -
Page 36: Menu "Passage Counter
MGC control unit Description of menus and parameters Menu "Passage counter" Operational view > Main menu > Passage counter Parameter Description From entry Display for the number of completed passages in zone controlled direction. If necessary, the value can be changed. Setting range ›... -
Page 37: Menu "Factory Settings
MGC control unit Description of menus and parameters Menu "Factory settings" IMPORTANT! The parameters of the control unit are stored in the three memory areas "Default settings", "Factory settings" and "User settings". The default settings are identical to the factory settings in these operating instructions. - Page 38 MGC control unit Description of menus and parameters Option "Restore factory settings" The operational view is displayed. ä Page 19, Fig. 16. Press the right button « ». √ The "Main Menu" menu is displayed. Select the menu "Factory Settings" with the two middle buttons « », «...
- Page 39 MGC control unit Description of menus and parameters Confirm selection with the right control button « ». √ The safety prompt "Save changes?" appears. › If the changes are to be saved, press the right button « ». The current settings are reset to factory settings. A restart is performed. ›...
-
Page 40: Function Description
MGC control unit Function description Function description Versions and definitions Left and right › Left: The passage is to the left of the locking comb. › Right: The passage is to the right of the locking comb. Entry and exit The service door or the cover of the support beam points into the zone controlled. - Page 41 MGC control unit Function description Version "Entrance side left" Entry Exit Fig. 22: Version "Entrance side left" – view Fig. 23: Version "Entrance side left" – view from the zone not controlled (ZNC), from the zone controlled (ZC), the exit the entrance is to the left of the is to the right of the locking comb locking comb...
-
Page 42: Function Sequence
MGC control unit Function description Function sequence Start The control unit receives an opening impulse. The free and the blocked Passage is possible. directions can be signalled via optional displays. The hold-open time is started. While the hold-open time is running, passage is possible. The centre pillar remains Has the in the home position. -
Page 43: Start-Up And Regular Movement Sequence
MGC control unit Function description Start-up and regular movement sequence Power-off state As standard, the pedestrian gate is supplied with the "normally open locking" configuration. In this case, the turnstile can be passed in both directions in the de-energised state. The centre pillar can be turned freely. If the pedestrian gate is supplied with the configuration "Locking normally closed", the turnstile is locked in both directions. -
Page 44: Pulse Operation In Both Directions With Vend Count
MGC control unit Function description 5.4.2 Pulse operation in both directions with vend count This operating mode works similarly to pulse operation without vend count. The pulse must be present between 0.2 and 1 sec. In this operating mode, pulses for both passage directions can be stored and processed one after the other. -
Page 45: Emergency
MGC control unit Function description Emergency The turnstile is available in the following configurations: › Locking normally open › Locking normally closed If no details were given in the order, the configuration "Locking normally open" is supplied. If a conversion is necessary, the locking must be converted and the parameters adjusted. -
Page 46: Corrective Action
MGC control unit Corrective action Corrective action Safety in troubleshooting Qualification of personnel › Technician › Electrical specialist ä See Page 7, chapter 1.3.1. Personal protective equipment Wear the following personal protective equipment: › Work clothes › Protective gloves › Safety shoes ›... -
Page 47: Malfunctions Turnstile
MGC control unit Corrective action Malfunctions turnstile Malfunction: Display is difficult or impossible to read. Possible cause Corrective action Removal by Display contact set too light or Technician Correct display contact. ä Page dark. 22, chapter 3.6. Malfunction: Centre pillar does not rotate. Possible cause Corrective action Removal by... -
Page 48: Event, Warning And Error Messages - Logic Control (Control Unit)
MGC control unit Corrective action Error messages "ERROR" Faults that cannot be reset by the control unit are displayed as errors. The pedestrian gate is put out of service. If the function "Error" has been chosen for an output, this output is deactivated at pending errors (fail safe). -
Page 49: Event, Warning And Error Messages - All Modules
MGC control unit Corrective action Number Designation Possible cause Corrective action › FF21 Max. pulse without The set maximum Check card reader / passage number of pulses validation device, e.g. card WARNING without passage has reader. › been reached. Check the "Max imp. w/o passage"... -
Page 50: Perform Reset
MGC control unit Corrective action Perform reset Control unit reset is performed as follows: › Switch of power supply and switch it on again after 10 seconds. › Press the two middle control buttons on the display of the control unit for 5 seconds. -
Page 51: Menu Setup
MGC control unit Menu setup Menu setup FlowMotion MPT333 – – – – Error, Warning, Main menu Event messages Inputs Setup Outputs In-/Outputs Modul info Service System Passage counter Information Factory reset Fig. 24: Menu "Information" and "Main menu"... - Page 52 MGC control unit Menu setup Main menu Setup Hold-open time Permanent open In-/Outputs Interlock Service Vend count Counter entry Counter exit System Max. impulse count Passage counter Max. imp. w/o passage Signalling Buzzer/Siren Information GED mode entry Factory reset GED mode exit Random function Mode Hit range...
- Page 53 MGC control unit Menu setup Main menu Setup In-/Outputs Inputs Digital inputs 1 – 8 Outputs Digital outputs 1 – 4 Relay outputs 1 – 6 Service Gate HW Invert Magnet RL1 Invert Magnet RL2 Exit direction Cycles Lifetime System time Main menu password System Language...
