Dynojet Power Commander V Installation Instructions page 3

FIG.A
FIG.B
FIG.C
I14-033 www.powercommander.com
1 Remove the seat and lift the fuel tank up.
2 Lay the PCV in the tail section as shown in Figure A.
3 Route the PCV harness down the left side of the frame and go towards the
airbox.
4 Unplug the 6-pin connector on the left shown in Figure B.
5 Unplug the 3-pin connector on the right shown in Figure B.
6 Attach the connectors from the PCV to the stock wiring harness as shown in
Figure C.
2014-2016 Ducati M1200 - PCV F/I - 3
