Operating Instructions
Temperature Control
When the appliance is first turned on, the default setting is 'freezer' mode. If you wish to use the appliance as another
mode, simply select another storage mode displayed on the internal control panel.
Internal Control Panel
The internal control panel enables you to view and modify all the features and options of your drawer.
To Use the Internal Control Panel
1. Unlock the control panel, press and hold the
button for 3 seconds. The
icon will no longer be illuminated.
2. Simply match the type of items that you wish to store in the CoolDrawer™ to the relevant storage environment
(see 'Operating Instructions' section).
3. To select between different storage environments press the
button to scroll to the desired storage mode, which best represents the food items you wish to store.
4. The storage mode icon selected will flash until the CoolDrawer™ reaches a suitable temperature for food to be
added (this will take between 1 – 6 hours approximately).
https://producthelp.fisherpaykel.com/eu/Cool/Built-In_Refrigeration/CoolDrawer%E2%84%A2/RB90S64MKIW1/User_Guide_...
CoolDrawer™ Control Panel
Updated: Tue, 03 Mar 2020 06:19:17 GMT
Powered by
1
Advertisement
Table of Contents
Related Manuals for Fisher & Paykel COOLDRAWER RB90S64MKIW1
Summary of Contents for Fisher & Paykel COOLDRAWER RB90S64MKIW1
- Page 1 Operating Instructions Temperature Control When the appliance is first turned on, the default setting is ‘freezer’ mode. If you wish to use the appliance as another mode, simply select another storage mode displayed on the internal control panel. Internal Control Panel The internal control panel enables you to view and modify all the features and options of your drawer.
- Page 2 Adjusting the Storage Mode Temperature Each of the storage modes will automatically default to an ideal temperature setting. The recommended temperature setting is always the centre light. If you wish to adjust the temperature of the CoolDrawer™, this can be done by using the temperature adjustment control.
- Page 3 icon will be illuminated when the function is activated. Key Lock Key lock allows you to disable the buttons on the internal control panel so the storage mode cannot accidently be changed. • The control panel automatically locks after 15 seconds if not being used or when the drawer is closed. When the panel is locked, the lock icon will appear above the button.
- Page 4 When the Appliance is in Sabbath Mode: • The light will not operate when the drawer is opened. • The drawer alarm will not operate. • The display will not be illuminated. • Opening the drawer will not affect the compressor or fans. •...
- Page 5 button to select ‘bottle chill’. • The ‘bottle chill’ timer will start automatically, this is indicated by the temperature adjustment lights scrolling back and forth. • Place your beverage into the CoolDrawer™. • To deactivate ‘bottle chill’ at any time, press the button three times until no freezer function lights are illuminated.
- Page 6 • To activate, press and hold the button for 3 seconds to unlock the control panel. • Press the button to select ‘deep freeze’. Place your frozen food into the CoolDrawer™. • To deactivate ‘deep freeze’ at any time, press the button once until no freezer function lights are displayed.
