JRC JMR-7230-S3 Quick Operation Manual

Marine radar equipment
Hide thumbs Also See for JMR-7230-S3:
Table of Contents

Advertisement

Quick Links

JMR-7230-S3/S
JMR-7225-7X3/9X3/6X/9X/6XH
JMR-7210-6X/6XH
JMR-7272-S
JMR-7282-S/SH
JMR-9230-S3/S
JMR-9225-7X3/9X3/6X/9X/6XH
JMR-9210-6X/6XH
JMR-9272-S
JMR-9282-S/SH
Marine Radar Equipment
Quick Operation Guide
1 Introduction ................................................................. 1
1.1 Read Before Use ............................................................ 1
2 Basic Operations ......................................................... 2
2.1 Powering On and Starting .............................................. 2
2.2 Finishing and Stopping Operation .................................. 4
2.3 Adjusting Screen Brightness........................................... 4
2.4 Changing the Observation Range .................................. 6
2.5 Adjusting Gain ................................................................... 7
2.6 Removing Sea Clutters ................................................... 8
2.7 Removing Rain/Snow Clutters ...................................... 10
2.11 Switching the Transmission Pulse Length ........................... 15
2.12 Switching the Azimuth Mode ........................................ 15
2.13 Setting the Motion Mode ............................................... 16
2.14 Displaying Radar Trail .................................................. 17
3 Operation of Target Tracking .................................... 19
3.1 Acquiring a Target ........................................................ 19
3.3 Erasing Tracked Targets .............................................. 20
4 AIS Operation ............................................................ 21
4.1 Setting Up the AIS Display Function ............................. 21
4.2 Activating an AIS Target ............................................... 21
4.3 Displaying the AIS Information ..................................... 22
4.4 Deactivating an AIS Target ........................................... 22
5.1 Setting Up Vectors ........................................................ 23
6 Other Operations ...................................................... 25
6.1 Stopping an Alert .......................................................... 25
6.2 Acknowledging an Alert ................................................ 26
6.3 Operation with the Software Keyboard ......................... 27

Advertisement

Table of Contents
loading

Related Manuals for JRC JMR-7230-S3

Summary of Contents for JRC JMR-7230-S3

  • Page 1: Table Of Contents

    JMR-7230-S3/S JMR-7225-7X3/9X3/6X/9X/6XH JMR-7210-6X/6XH JMR-7272-S JMR-7282-S/SH JMR-9230-S3/S JMR-9225-7X3/9X3/6X/9X/6XH JMR-9210-6X/6XH JMR-9272-S JMR-9282-S/SH Marine Radar Equipment Quick Operation Guide 1 Introduction ..............1 1.1 Read Before Use ............1 2 Basic Operations ............2 2.1 Powering On and Starting ..........2 2.2 Finishing and Stopping Operation ........4 2.3 Adjusting Screen Brightness...........

  • Page 3: Introduction

    1 Introduction 1.1 Read Before Use About the Quick Operation Guide For more details, please read the Operation Manual. Please keep this Quick Operation Guide in an easily accessible place. About the Radar Use the radar solely as a navigation aid. Also, the final decision of maneuvering must be made by the person who maneuvers the ship.

  • Page 4: Basic Operations

    2 Basic Operations 2.1 Powering On and Starting Make sure that the ship's power is on. Press the Power button on the operation unit. The Power button illuminates and the Start screen appears. After the Start screen appears, the Task menu appears next after a while. Click the "Collision Avoidance (RADAR)"...
  • Page 5 The standby/transmission changeover button of the radar system information is switched to "Preheat". Standby/transmission Standby/transmission Standby/transmission changeover button changeover button changeover button When a magnetron radar When a fixed radar antenna antenna is connected is connected Wait until preheating completes. When the preheat time expires, the Preheat Time screen disappears and the standby/transmission changeover button of the radar system information is switched from "Preheat"...

  • Page 6: Finishing And Stopping Operation

    2.2 Finishing and Stopping Operation Click the standby/transmission changeover button of the radar signal information. Radar transmission stops and the rotation of the radar antenna stops. The display of the standby/transmission changeover button is switched from "Transmit" to "Standby". Press the Power button on the operation unit. The power to this equipment stays off.
  • Page 7 2.3.2 When "DISP Brightness" is not being displayed in the Key Assignment Indication Area (key allocation display area) Press the “MULTI” dial for a long time. The Display Brightness function will be assigned to the “MULTI” dial. Adjust the screen brightness by turning the “MULTI” dial to the left or right. The entire screen becomes brighter when the dial is rotated to the right.

  • Page 8: Changing The Observation Range

    2.4 Changing the Observation Range Click the Range Scale button of the presentation and mode information, and then select a range from the pop-up menu that appears. Range Scale button A wider range can be observed by widening the observation range. When the observation range is narrowed down, the area near own ship can be observed by enlarging it.

  • Page 9: Adjusting Gain

    2.5 Adjusting Gain Continue clicking the slider of the "Gain" slider control of the radar signal information, and specify the gain by rotating the trackball. If there is the optional keyboard operation unit, the operation of the "GAIN" dial is also possible.

  • Page 10: Removing Sea Clutters

    2.6 Removing Sea Clutters 2.6.1 When Using the Manual Sea Clutter Suppression Function Click the Automatic Sea Clutter Suppression button. The display of the Automatic Sea Clutter Suppression button changes to "MAN" (Manual). Automatic Sea Clutter Suppression button Continue clicking the slider of the "Sea" slider control of the radar signal information, and adjust the amount of images displayed from reflections of sea clutters on the screen by rotating the trackball to facilitate observation.
  • Page 11 2.6.2 When Using the Automatic Sea Clutter Suppression Function Click the Automatic Sea Clutter Suppression button. The display of the Automatic Sea Clutter Suppression button changes to "AUTO" (Automatic). Automatic Sea Clutter Suppression button Click the slider of the "Sea" slider control, and adjust the amount of images displayed from reflections of sea clutters on the screen by rotating the trackball.

  • Page 12: Removing Rain/Snow Clutters

    2.7 Removing Rain/Snow Clutters 2.7.1 When Using the Manual Rain/Snow Clutter Suppression Function Click the Automatic Rain Clutter Suppression button. The display of the Automatic Rain Clutter Suppression button changes to "MAN" (Manual). Automatic Rain Clutter Suppression button Continue clicking the slider of the "Rain" slider control of the radar signal information, and adjust the amount of images displayed from reflections of rain/snow clutters on the screen by rotating the trackball to facilitate observation.
  • Page 13 2.7.2 When Using the Automatic Rain/Snow Clutter Suppression Function Click the Automatic Rain/Snow Clutter Suppression button. The display of the Automatic Rain Clutter Suppression button changes to "AUTO" (Automatic). Automatic Rain Clutter Suppression button Click the slider of the "Rain" slider control, and adjust the amount of images displayed from reflections of rain/snow clutters on the screen by rotating the trackball.

  • Page 14: Using The Electronic Cursor (Ebl1/Ebl2)

    2.8 Using the Electronic Cursor (EBL1/EBL2) Click either the "EBL1" or "EBL2" button of the Navigation Tools. Either EBL1 or EBL2 is placed in the operating mode and the display of the button changes from "OFF" to the azimuth position. "EBL2"...

  • Page 15: Using Variable Range Marker (Vrm1/Vrm2)

    2.9 Using Variable Range Marker (VRM1/VRM2) Click either the "VRM1" or "VRM2" button of the Navigation Tools. Either VRM1 or VRM2 is placed in the operating mode and the display of the button you clicked changes from "OFF" to the distance position display. "VRM1"...

  • Page 16: Setting Up The Measurement Reference Point Of The Electronic Bearing Line And Variable Range Marker

    2.10 Setting Up the Measurement Reference Point of the Electronic Bearing Line and Variable Range Marker The measurement reference point of this equipment's electronic bearing line (EBL) and variable range marker (VRM) can be selected from the following three types. Set up a measurement reference point according to usage.

  • Page 17: Switching The Transmission Pulse Length

    2.11 Switching the Transmission Pulse Length Click the transmission pulse witch changeover button of the radar system information. Transmission Pulse Width Changeover Button Each time the button is clicked, the transmission pulse witch changes. Example: "MP1"→"MP2"→"LP1"→"LP2" 2.12 Switching the Azimuth Mode Click the Azimuth Mode button of the presentation and mode information.

  • Page 18: Setting The Motion Mode

    2.13 Setting the Motion Mode 2.13.1 Switching the Motion Mode Select the motion mode from "TM", "RM(T)", and "RM(R)". The motion mode switches. 2.13.2 Setting Up Own Ship's Position in the "TM" (True Motion) Mode Click the Motion Mode button of the presentation and mode information. Motion Mode Button Select "TM Reset"...

  • Page 19: Displaying Radar Trail

    2.14 Displaying Radar Trail 2.14.1 Changing the Trail Length Click the Radar Trail Length Changeover button. Radar Trail Length Changeover Button Select a radar trail length. 2.14.2 Erasing a Radar Trail Click the "CLR" (Clear Radar Trails) button. "CLR" (Clear Radar Trails) Button A confirmation dialog box appears.
  • Page 20 2.14.3 Changing the display Mode of Radar Trails Click the radar trail true/relative changeover button. Each time the button is clicked, the radar trail display mode switches between "T" and "R". Radar Trail True/Relative Changeover Button "T": (True motion trail) "R": (Relative motion trail)

  • Page 21: Operation Of Target Tracking

    3 Operation of Target Tracking 3.1 Acquiring a Target Click the cursor mode selection button of the Left Tool Bar. Position the cursor on the target you want to acquire and then click. The target is acquired and an initial acquisition symbol is displayed. A vector is displayed within 1 min.

  • Page 22: Erasing Tracked Targets

    3.3 Erasing Tracked Targets 3.3.1 Erasing One Target At A Time Right click after moving the cursor above the tracked target to be erased. The context menu will be displayed. Click "Cancel TT" on the Context menu. The vector symbol of the tracking target disappears and only radar images remain. 3.3.2 Erasing All Targets Right click after moving the cursor above the tracked target to be erased.

  • Page 23: Ais Operation

    4 AIS Operation 4.1 Setting Up the AIS Display Function Click the "AIS" button. The button is turned on and the AIS function takes effect. On display: The received AIS information is displayed on the screen. 4.2 Activating an AIS Target Right click after moving the cursor above the tracked target to be erased.

  • Page 24: Displaying The Ais Information

    4.3 Displaying the AIS Information Set the cursor mode to the AUTO mode. Position the cursor on the activated AIS target of which you want to display AIS target information and then click. The information of the selected AIS target will be displayed in the right part of the screen. 4.4 Deactivating an AIS Target Right click after moving the cursor over the AIS activated target to be deactivated.

  • Page 25: Operation Common To Target Tracking And Ais

    5 Operation Common to Target Tracking and AIS 5.1 Setting Up Vectors 5.1.1 Setting Up the Vector Mode Click the Vector/Past Position True/Relative changeover button. Vector / Past Position True/Relative selection button Every time this button is clicked, the TT/AIS vector mode is switched between "T" and "R". 5.1.2 Setting Up the Vector Length Set up the vector length in a range between 1 and 120 min in units of 1 min.

  • Page 26: Setting Up The Collision Determining Condition

    5.2 Setting Up the Collision Determining Condition 5.2.1 Setting Up the CPA Limit Click the CPA Limit Value entry box. CPA Limit Value Entry Box The software keyboard is displayed. Enter a CPA limit value. For the input method, please see "6.3 Operating with the Software Keyboard". 5.2.2 Setting Up the TCPA Limit Click the TCPA Limit Value entry box.

  • Page 27: Other Operations

    6 Other Operations 6.1 Stopping an Alert Click the Silence button in the Alert Notification Area or press the "SILENCE" key on the trackball operation unit. Operation on the Screen Silence Button Operation on the Track Ball Operation Unit "SILENCE" Key...

  • Page 28: Acknowledging An Alert

    6.2 Acknowledging an Alert The displayed alert is acknowledged either by clicking the “ACK” button in the detailed display dialog box of the alert, or by pressing the “ALERT ACK” button of the track ball operating unit. Operation on the Screen ACK button Operation on the Track Ball Operation Unit "ALERT ACK"...

  • Page 29: Operation With The Software Keyboard

    6.3 Operation with the Software Keyboard Click the numeric key you want to enter. Verify that the value you specified is correct and then click the "Enter" key. The entry is accepted.
  • Page 32 Not use the asbestos For further information,contact: URL Head office : http://www.jrc.co.jp/eng/ Marine Service Department 　　　　　　　　　　　: msc@jrc.co.jp e - mail One - call 　　　　　　　　　　　: +81-50-3786-9201 ISO 9001, ISO 14001 Certified CODE No.7ZPNA4395 MAY. 2016 Edition 1...
