INSTALLATION OF ACCESSORIES

1. Remove the discharge hose from the left
side of the tank cover.
2. Connect the accessory tool vacuum hose
to the left fitting on tank cover and on to the
end of the cleaning tool wand. The hose
must be connected tightly.
3. Connect solution hose to accessory quick-
disconnect in the back of the extractor and
to quick disconnect located on the handle
of the tool.
4. Turn the solution control knob in the back
of the extractor to the upright position.
Vacuum Hose
Accessory Quick Disconnect
Safety, Operation and Maintenance Manual for TW Compact; Version 1.0
5. Turn ON the solution and vacuum switches.
DO NOT turn on brush switch.
6. Start cleaning by squeezing the trigger on
the wand while slowly pulling the tool
towards you.
7. When finished, turn OFF vacuum and
solution switches, disconnect vacuum and
solution hoses from unit.
8. Re-connect the extractor's discharge hose
to the left fitting of the tank cover.
9. Return the solution control knob to the
normal position.
Solution
Control Knob
