GridScan/Pro

15. Technical data

Optical
Operating range
Number of elements
Max. protection height
Max. ambient light
Mechanical
Cross section
Housing material
Enclosure rating
Temperature range
Electrical
Supply voltage U
SP
Current consumption with
22 elements at 24 VDC
Output
Output load
Typ. response time with
22 elements
Max. response time with
22 elements
HW Watch dog
Max. door closing speed
Max. door opening speed
Status LED Rx:
- Object detected
- No object detected
Power LED Tx:
Power ok
Connection cable and electrical connection
Synchronization cable
Length
Connection
Diameter
Material
Plug color
Wires
brown
•
blue
•
black
•
white
•
12
1...10 m (3 ... 33 ft)
20, 22, 36, 42
2,500 mm (98.5 in)
100,000 Lux
12 mm × 14.5 mm
(0.47 in × 0.57 in)
Natural anodized
aluminum
IP68 (Cable: IP67)
−40 °C ... +60 °C
(−40 °F ... +140 °F)
10 ... 30 VDC
50 mA
PNP/NPN (push-pull)
and FSS
100 mA, 100 nF
40 ms
80 ms
200 ms
1.6 m/s
> 3 m/s
red
green
green
10 m (33 ft)
Screwable M8, 4 pin
Ø 3.5 mm (Ø 0.14 in)
PVC, black
Black
AWG26
U
SP
GND (0 V)
Communication
Not used
Connection cable
Length
Connection
Diameter
Material
Plug color
Wires
brown
•
blue
•
black
•
white
•
gray
•
green
•
General
EMC emmision
EMC immunity
Vibration
Shock
RoHS
Certificates
Safety categories
Applicable standards
English
5 m (16.5 ft)
Screwable M8, 4 pin
Ø 4.2 mm (Ø 0.17 in)
PVC, black
Blue
AWG26
U
SP
GND (0 V)
Output 1 (PNP/NPN and
FSS)
Test input
Selectable output logic
Not used or Output 2
(PNP/NPN)
EN 61000-6-3:2007
EN 12015:2014
EN 61000-6-2:2005
EN 12016:2013
IEC 60068-2-6:2007
IEC 60068-2-27:2008
2011/65/EU
CE, TÜV
EN ISO 13849-1:2015,
Cat. 2, PL D
EN 61508:2010, SIL 2
EN 12978:2009
EN 12453:2017 E device
UL 325:2012
