- Page 1 GridScan/Mini-SR Installation and Operation Manual RoHS EN 13849-1 CEDES AG is certified according to ISO 9001: 2015 English Pages 2 – 11 113 197 | 160615 | V 1.0...
-
Page 2: Table Of Contents
Science Park CH-7302 Landquart GridScan/Mini-SR Switzerland FSS Control Unit Troubleshooting 10.1 GridScan/Mini-SR 10.2 FSS Control Unit Maintenance Disposal Technical data Dimensions CEDES AG reserves the right to modify or change technical data without prior notice. © CEDES | V 1.0... -
Page 3: Safety Information
Follow the measures highlighted by the triangle-shaped arrows Any alterations to the device by the buyer, installer or user may result in unsafe operating conditions. CEDES is not Consult safety information responsible for any liability or warranty claim that results Chapter 2 of this manual from such manipulation. -
Page 4: Introduction
4. Introduction Features of the GridScan/Mini-SR • Criss-cross beams The GridScan/Mini-SR is a very compact, Cat. 2 certified • Safety Cat. 2 without testing light curtain designed for safeguarding the entrance area of a freight or platform elevator. The GridScan/Mini-SR •... -
Page 5: General Instructions And Precautions
Avoid interference from blinking lights or infrared light sources such as photo cells or other light curtains. Do not install the GridScan/Mini-SR in places where the emitter and receiver edges are directly exposed to light sources such as FL tubes or energy saving lamps. -
Page 6: Installation
Not used green Figure 5: Connection diagram semiconductor output Important: There has to be a bridge between connector 5 and 6 of the FSS Control Unit. Any unconnected (not used) wire must be separated and isolated. © CEDES | V 1.0... -
Page 7: Timing Diagram
Emitter edge (Tx) Green LED Sensor status Power OK ˜ No power or edge is defective ™ Table 3: LED status description for emitter edge ˜ = LED on ™ = LED off = LED blinking © CEDES | V 1.0... -
Page 8: Troubleshooting
Rapid shut-down, Turn off and on again segments Failure flashing FSS Control Unit is defective Change FSS Control Unit If a problem persists, please contact your local CEDES representative. Visit www.cedes.com for contact data. © CEDES | V 1.0... -
Page 9: Maintenance
Diameter Ø 3.5 mm Material PVC, black 12. Disposal Plug color Black The GridScan/Mini-SR should only be replaced if a similar Wires AWG26 protection device is installed. Disposal should be done brown edges • using the most up-to-date recycling technology according... -
Page 10: Dimensions
2030 POWER 34 33 24 23 A1 Ø 4.7 Ø 5.3 1 BN 2 WE 4 GN1 6 GN2 Height: 57 1 Connector to edges 2 Relay output 4 Mounting holes 5 Cover fixing holes © CEDES | V 1.0... - Page 11 5.11 POWER 34 33 24 23 A1 Ø 0.18 Ø 0.21 1 BN 2 WE 4 GN1 6 GN2 Height: 2.24 1 Connector to edges 2 Relay output 4 Mounting holes 5 Cover fixing holes © CEDES | V 1.0...
