Instrument Solution – FAQ
Troubleshooting DSA1000 LAN Connections
Date:01.24.2012
Solution: Communicating over LAN to the DSA series is straightforward. Here are
some things to try if you are having difficulty:
Make sure Ethernet cable is connected properly and that the switch/hubs in
1.
the network configuration are operating properly.
The green LED on the back of the DSA should display a solid
•
illumination when the connection is made.
The yellow LED on the back of the DSA should blink when data is sent
•
and received.
The DSA defaults to communicate over USB. To configure the instrument
2.
for Ethernet, follow these steps:
Press System > I/O Setting > Remote I/O and toggle to LAN
•
Solution Title
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rigol DSA1000
Summary of Contents for Rigol DSA1000
- Page 1 Instrument Solution – FAQ Solution Title Troubleshooting DSA1000 LAN Connections Date:01.24.2012 Solution: Communicating over LAN to the DSA series is straightforward. Here are some things to try if you are having difficulty: Make sure Ethernet cable is connected properly and that the switch/hubs in the network configuration are operating properly.
- Page 2 • Press System to Exit the menu 3. Find LAN configuration and make sure it matches your instrument settings Press System > I/O Setting > LAN •...
- Page 3 Record the IP Address, Subnet Mask, and Gateway •...
- Page 4 Open a web browser (Chrome, Internet Explorer, etc..) and type the IP • address into the address bar at the top. If everything is configured correctly, the DSA's webpage will load •...
