FLEXVIEW QUICK START
1

INSTALL THE SOFTWARE

a.
Download the Flexview software
onto your computer from:
km.kongsberg.com/mesotechsoftware
b.
Run the Setup file.
c.
Apply the default settings during
installation.
d.
Click Yes to install the KML USB
Converter when prompted.
ROV Topside Unit
3

INSTALL YOUR SONAR

a.
Splice the Flexview cable whip to
your ROV junction box cable.
b.
Using a bracket, mount the sonar
to your ROV.
c.
Connect the system units as
shown.
d.
Power on the system.
Kongsberg Mesotech Ltd.
Tel: (604) 464 8144
(Sonar Processor)
To download the Flexview software or manuals, visit:
kongsberg.com/mesotechsoftware
kongsberg.com/mesotechdocumentation
Computer
2

SET YOUR IP ADDRESS

a.
In Windows, open Settings.
b.
Select Network & Internet,
then Change adapter options.
c.
Right-click on your Ethernet
network and select Properties.
d.
Select Internet Protocol v4,
then select Properties.
e.
Set your IP address to
192.168.1.233.
f.
Set the Subnet Mask to
255.255.255.0.
Flexview sonar on ROV
