- Page 1 SCHMEISER TILL AN’ PAK™ AND ACCESSORIES T. G. SCHMEISER OPERATION AND PARTS MANUAL Version 2.0 July 2019 Read and understand the manual. This manual provides information and procedures to safely operate and maintain the Till An’ Pak...
- Page 2 Copyright © 2019 T. G. Schmeiser Co., Inc. All rights reserved...
-
Page 3: Table Of Contents
Till An’ Pak™ CONTENTS INTRODUCTION............4 MAINTENANCE............16 Engineered for Long Life........4 Maintenance Schedule...........16 Serial Number Information ........4 Lubrication Points...........17 Replacement Parts...........4 Ground Engaging Components......17 Warranty Information..........4 STORAGE..............17 Serial Number Location..........4 Storage Preparation..........17 Factory Contact Information........4 Placing In Storage..........17 Dealer Contact Information........4 Removing From Storage.......17 Till An’... -
Page 4: Introduction
T. G. Schmeiser Co., Inc. It is important that the Warranty Card be completed and P.O. Box 1392 sent to Schmeiser. The warranty will not be valid until Selma, CA 93662 not contained in this manual is needed, contact your Phone: (559) 268-8128 Schmeiser dealer. -
Page 5: Till An' Pak™ And Accessories
Till An’ Pak™ TILL AN’ PAK™ AND ACCESSORIES Ph. (559) 268-8128 www.tgschmeiser.com Fax (559) 268-3279... -
Page 6: Safety
. Indicates that equipment or property damage can result if instructions are not followed. T.G. Schmeiser cannot anticipate every possible circumstance that might involve a potential hazard. The SAFETY INSTRUCTIONS warnings in this manual and on the product are, therefore, not all-inclusive. -
Page 7: Safety Icons Nomenclature
Till An’ Pak™ Safety Icons Nomenclature Hazard Avoidance SLOW VEHICLE PLACARD This manual and the equipment has numerous safety icons. BLOCK WHEELS SET PARKING BRAKE These safety icons provide important operating instructions CRUSHING HAZARD (body) which alert you to potential personal STOP ENGINE STOP injury hazards. -
Page 8: General Safety
Till An’ Pak™ GENERAL SAFETY To prevent injury, use a tractor equipped with a Roll Over Protective System (ROPS) . Read and Understand Manual Visually Inspect To prevent personal injury or even death, be sure Visually inspect the unit for any loose bolts, you read and understand all of the instructions in worn parts, or cracked welds, and make this manual and other related OEM equipment manuals! -
Page 9: Operation Safety
Till An’ Pak™ OPERATION SAFETY SAFETY INSTRUCTIONS Do not use a tractor of more than the recommended HP to prevent damaging implement components. Crush Hazard (Rolling Over) Do not clean, lubricate, or make adjustments while the unit is moving . Tractor Safety Devices If transporting or operating the tractor and implement Never allow inexperienced or untrained... -
Page 10: Tractor Safety Devices
Till An’ Pak™ MAINTENANCE SAFETY Connecting to Tractor Use Properly Rated Tools Crush Hazard Use sufficient tools, jacks, and hoists that Use care when attaching the unit have the capacity for the job . to the tractor . Never place any Crush Hazard part of your body under the tongue or hitch assembly . -
Page 11: Bolt Torque Requirements
DISPOSAL OF EQUIPMENT AT END OF USEFUL LIFE Welding Repairs The T. G. Schmeiser has been designed implement for Before performing any type of welding repair to the specific purpose of conditioning the ground in the implement, contact T.G. Schmeiser Co., Inc. -
Page 12: Safety Signs And Decals
Till An’ Pak™ SAFETY SIGNS AND DECALS • When parts that display a safety sign are replaced, the replacement part should display the same sign. Replace all worn or damaged safety and • Make sure the safety signs and other instructional instruction decals . -
Page 13: Safety Signs And Decals
Item Part Number Description Qty. D28X048PPT Pinch Point D48X038RTM Read the Manual D48X038CRR Crush / Rollover Hazard D48X48QR Scan to Access Online Manual — FEMA D32X048RBC Made in the USA D32X208TGS Schmeiser (13”) Ph. (559) 268-8128 www.tgschmeiser.com Fax (559) 268-3279... -
Page 14: Operation
Till An’ Pak™ OPERATION Implement Break-In Although there are no operational restrictions on the Till An’ Pak when used for the first time, it is recommended that the following mechanical items be Understand Safety Procedures! checked: Read and understand all safety procedures described in this manual before performing any work 1. -
Page 15: Ring Roller Orientation
Till An’ Pak™ 7. Slow the tractor when making turns, and remember that Detaching From Tractor the Till An’ Pak is wider than the tractor when turning. 1. Move the Till An’ Pak to a level storage location. Park 8. Always operate safely and follow all the instructions in the tractor, place the transmission in park or neutral, this manual. -
Page 16: Maintenance
Till An’ Pak™ MAINTENANCE Understand Safety Procedures! Read and understand all safety procedures described in this manual before performing any work on or around the implement. Maintenance Schedule The period recommended is based on normal operating conditions. Severe or unusual conditions may require more frequent service. -
Page 17: Lubrication Points
Till An’ Pak™ Lubrication Points fasteners are tight, and all retaining pins are secured in place with appropriate retaining clips. Bearings come pre-lubed from the factory. Prior to applying grease, allow 40 hours of operation time to 3. Inspect the frame for structural fractures. break in the seals. -
Page 18: Parts Section
Till An’ Pak™ PARTS SECTION Ordering Parts We manufacture a quality product that requires very little maintenance or repair. However, should a part break become damaged, our knowledgeable staff can make sure you receive the part(s) to put your unit back into operation. Till An’... -
Page 19: Smooth An' Roll Assembly
SMOOTH AN' ROLL ASSEMBLY Till An’ Pak™ T. G. SCHMEISER CO., INC. Smooth An’ Roll Assembly ROLLER TUBE TONGUE (see p.9 for all sizes) TILL AN' PAK FRAME Ref No. Part No. Description Qty. per Roller TPP3010 1-1/8" X 6-1/2" Tongue Pin Weldment... -
Page 20: Till An' Pak / Smooth An' Roll Tongue
Till An’ Pak™ TILL AN' PAK / SMOOTH AN' ROLL TONGUES T. G. SCHMEISER CO., INC. Till An’ Pak / Smooth An’ Roll Tongues CLEVIS SIZE Unit Size Clevis Size Tongue Size Tongue Part # 2’ to 5’ 3” 52”... -
Page 21: Till An' Pak Accessories
11 9 10 Ref No. Part No. Description Qty. per Roller TPF-01A014 Till An' Pak Float Pull Bracket (2 ft. to 13 ft. units) Item Part Number Description Qty. Per Roller TPF-02A014 Till An' Pak Float Pull Bracket (14 ft and up) TPF-01A014 Float Pull Bracket (2’... -
Page 22: Squadron Arm Assembly
Squadron Arms Frame LH and RH (size) GTB-12X96W 3/4" NC Turnbuckle Assembly Weldment TPS-00C000 Squadron Arm Turnbuckle Rod Long TPP3010 1-1/8" X 6" Till An' Pak Tongue Pin GTB-12X96W 3/4” NC Turnbuckle Assembly GPN-040LYN 1/4" Lynch Pin TPP3010 1-1/8” X 6” Tongue Pin GPN-12X040 3/4"... -
Page 23: 3-Point Hitch Ca 1&2
Till An’ Pak™ 3-PT. HITCH CAT. 1 & 2 ASSEMBLY T. G. SCHMEISER CO., INC. 3-Point Hitch CA 1 & 2 TILL AN' PAK FRAME Item Part Number Description Qty. Ref No. Part No. Description Qty. per Roller THS-00A000 Hitch Center Frame GPN-18CA12 Category 1 &... -
Page 24: 3-Point Hitch Ca 2&3
3-PT. HITCH CAT. 2 & 3 ASSEMBLY Till An’ Pak™ T. G. SCHMEISER CO., INC. 3-Point Hitch CA 2 & 3 TILL AN' PAK FRAME WELD TO FIT Ref No. Part No. Description Qty. per Roller THH-00A100 HD Hitch Center Frame Weldment... -
Page 25: Limited Warranty Statement
Except as set forth above, T . G . Schmeiser Co ., Inc . shall have no obligation or liability of any kind on account of any of its equipment and shall not be liable for special or consequential damages . - Page 26 Till An’ Pak™ NOTES www.tgschmeiser.com Ph. (559) 268-8128 Fax (559) 268-3279...
- Page 27 Till An’ Pak™ NOTES Ph. (559) 268-8128 www.tgschmeiser.com Fax (559) 268-3279...
- Page 28 Till An’ Pak™ Version 2.0 July 2019 www.tgschmeiser.com Ph. (559) 268-8128 Fax (559) 268-3279...
