Summary of Contents for CYP CDB-6HP
- Page 1 CDB-6HP HD Audio Amplifier Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Panel Description ......3 7. Connection Diagram ......4 8. Specifications ........5... -
Page 6: Introduction
1. INTRODUCTION This USB to Headphone Audio Converter is a simple but smart device and no external power is required. It allows you to connect your PC/laptop to a set of analog headphones or other analog audio destination devices for delivery of superior audio quality. This compact HD audio product supports LPCM 2.0 audio with a maximum sampling rate of 384kHz/24-bit and utilizes a direct-coupled amplifier, for better frequency response and to avoid signal loss, providing... -
Page 7: Features
5. FEATURES • Output HD audio from your PC/laptop to headphones • Superior USB audio processor (XMOS U8A) supporting sample rates up to 384kHz/24-bit • Superior DAC engine (TI PCM5101A) which supports up to 384kHz for digital to analog signal conversion •... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Panel Description 384KHz HD AUDIO AMPLIFIER USB IN: Connect to computer source equipment with an available USB port such as a PC/Laptop (Windows and Mac Operating Systems are compatible). POWER LED: This LED will illuminate RED to indicate the unit is on and receiving power from the USB connection. -
Page 9: Connection Diagram
7. CONNECTION DIAGRAM Head/Earphones or PC/Laptop Speakers 384KHz HD AUDIO AMPLIFIER... -
Page 10: Specifications
8. SPECIFICATIONS Input Ports 1 x USB 2.0 (Type B) Output Ports 3.5mm headphone jack ESD Protection Human body model: ±8 kV (air-gap discharge) ±4 kV (contact discharge) Chassis Material Aluminum Silkscreen color Black Dimensions 81mm × 22.5mm × 25mm (W×H×D) [Case Only] Operating Temperature 0˚C~40˚C/32˚F~104˚F Weight... - Page 12 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-CDB6HP...
