Page 1: Operation Manual
CPLUS-V4H4HP 4K UHD+ 4 x 4 Matrix with USB Power Supply Operation Manual Operation Manual... - Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. Package Contents ........ 2 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........5 6.3 Remote Control ........6 6.4 LCD Menu Tree .........7 6.5 IR Cable Assignments ......7 6.6 RS-232 Protocol .........8... -
Page 6: Introduction
1. INTRODUCTION This 4K UHD 4 by 4 Matrix provides the ability to connect up to four 4K UHD HDMI sources to up to four 4K UHD HDMI displays and freely switch between them. This unit comes with full support for 18Gbps (600Mhz) resolutions up to, and including 4K@60Hz (4:4:4, 8-bit) as well as support for 48-bit Deep Color, HDR (High Dynamic Range), HD audio and other features defined by the HDMI 2.0 specification. -
Page 7: Package Contents
4. PACKAGE CONTENTS • HDMI source equipment such as media players, video game consoles or set-top boxes. • HDMI receiving equipment such as HDTVs, monitors or audio amplifiers. • The use of “Premium High Speed HDMI” cables is highly recommended. 5. -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel OUT A OUT B OUT C OUT D CANCEL MENU LOCK POWER 4x4 4K UHD+ Matrix IN 1 IN 2 IN 3 IN 4 CONFIRM ENTER PRESET MUTE Power: Press this button to power the unit on (green LED) or place it into stand-by mode (red LED). - Page 9 LOCK: Press to lock all button functions on the front panel. Press and hold for 3 seconds to release the lock function. The LCD will display “Lock” when the function is active. MUTE: The “MUTE” button functions as a blank audio/video source. To use it, follow the standard matrix routing instructions, but use the “MUTE”...
-
Page 10: Rear Panel
6.2 Rear Panel HDMI IN OPTICAL /HDMI OUT USB POWER OUTPUT (5V/1A) SERVICE CONTROL RS232 IR IN DC 24V HDMI IN 1~4: Connect to HDMI source equipment such as media players, game consoles or set-top boxes. OPTICAL / HDMI OUT A~D: Connect the HDMI outputs to devices such as HDMI TVs, monitors or amplifiers for digital video and audio output. -
Page 11: Remote Control
6.3 Remote Control POWER: Press to power the unit on or place it into stand-by mode. 1 / A 5 / E INFO 2 / B 6 / F MUTE 1/A ~ 4/D: Press these keys to configure the video routing. Press the “OUT” key 3 / C 7 / G PRESET... -
Page 12: Lcd Menu Tree
6.4 LCD Menu Tree Level Level EDID In1 / In2 / In3 / In 4 / In All Preset Setup 1/2/3/4 Network Status Link (Valid) / Mode (Static/ DHCP)/ IP/Mask/Gate/MAC Network Setup Mode: (Static/DHCP) Static: IP/Mask/Gate Firmware Version Firmware Update USB update Factory Reset Factory reset... -
Page 13: Rs-232 Protocol
6.6 RS-232 Protocol MATRIX REMOTE CONTROLLER Assignment Define TX / RX ► ◄ Baud Rate: 115200bps Data Bits: 8 Parity: None Flow Control: None Stop Bits: 1... -
Page 14: Rs-232 Command
6.7 RS-232 Command Description of parameter Command Name Description Show descript of ? command command. Show descript of HELP ? command command. All Ethernet ETH_FADEFAULT configure set to NONE factory default. Set Ethernet IP SIPMODE P SIPMODE mode. P=Mode(STATIC/DHCP) SETIP P1 P2 P3 Set Ethernet IP P1=IPADDRESS SETIP... - Page 15 Description of parameter Command Name Description System Reset to NONE A1,B2,C3,D4. EM P1 P2 P1=PORT(1~4) P2=(1-FHD2CH, 2-FHD- Setting EDID MCH, 3-4KUHD2CH, 4-4KUH- mode. DMCH, 5-4KUHD+2CH, 6-4KUHD+MCH, 7-TXA,8-TXB, 9-TXC,10-TXD, 11-USER1, 12- USER2, 13-USER3, 14-USER4) Update firmware by SERVICE USB port. note:Device UPDATE NONE will wating for...
- Page 16 Description of parameter Command Name Description OSDOFF P OSDOFF OSD off. P=Output Port(1~4) OSDXY P1 P2 P3 Set OSD coordi- P1=Output Port(1~4) OSDXY nate. P2=x(1~1920) P3=y(1~1080) OSDSTR P1 P2 P3 P1=Output Port(1~4) OSDSTR Set OSD string. P2=Line(1~2) P3=String(1~64 Charac- ters) OSDFSIZE P1 P2 Set OSD font OSDFSIZE...
-
Page 17: Telnet Control
6.8 Telnet Control Before attempting to use telnet control, please ensure that both the unit and the PC/Laptop are connected to the same active networks. To access Telnet in Windows 7, click on the “Start” menu and type “cmd” in the search field, then press “Enter”. Under Windows XP go to the “Start”... -
Page 18: Webgui
This will connect us to the unit we wish to control. Type “help” to list the available commands. 6.9 WebGUI Install the IP Discovery Tool: Please obtain the Device Discovery software from your autho- rized dealer and save it in a directory where you can easily find Note: The unit’s default IP address is 192.168.1.50 Connect the unit and your PC/Laptop to the same active net- work and execute the Device Discovery software. - Page 19 switch the unit into DHCP mode to automatically obtain proper network settings from a local DHCP server. To switch to DHCP mode, please select DHCP from the IP mode drop-down, then click “Save” followed by “Reboot”. Once you are satisfied with the network settings, you may use them to connect via telnet or WebGUI.
-
Page 20: Switch
The following function tabs will always display on left side of the WebGUI to aid with navigation. 6.9.1 Switch This page provides video routing settings, preset saving/loading, and I/O renaming options. Video Routing To begin assigning a new video route, please click the button of the HDMI output you wish to send video to and then click on the button of the preferred HDMI input port. - Page 21 Output Video Mute Each output can be individually muted (black video, no audio). To mute an output, please click the ( ) icon within the ap- propriate output button. To unmute the output, please click the icon a second time. Output and Input Naming All inputs and outputs can be renamed as required.
- Page 22 OSD Text Settings Each output can display up to 2 lines of customized OSD text. The text can be customized in content, color, background trans- parency, size and position. Click the “edit” icon ( ) associated with each output to modify these settings. Please click the “Save” button after making changes to the positioning or content.
-
Page 23: Edid Settings
• Recall: When you wish to load a previously stored preset, please click the “Preset Recall” icon ( ) and you will be presented with a choice of the available 4 presets. Hovering the mouse over each button will display the preset routes stored within it. - Page 24 to the Customer EDID Settings item you would like to change. An EDID Upload window will appear, allowing you to locate and upload your preferred EDID file from the file directory on your local PC. Once the correct file has been selected, please click the “Upload”...
- Page 25 Set EDID Input Content The Set EDID Input Content section allows for the assignment of an EDID to each individual input port, or to all inputs at once. Click on an input to open the EDID Source management win- dow. Multiple inputs can be selected at once, if desired. Select the new EDID source to use and the change will occur immedi- ately.
-
Page 26: System Setting
6.9.3 System Setting This page provides system configuration options including turn- ing the unit’s power on/off, turning the USB power support on/ off, changing the network settings, resetting the system to fac- tory defaults and updating the firmware. 6.9.4 Admin log out Clicking the “Logout”... -
Page 27: Connection Diagram
7. CONNECTION DIAGRAM HDMI TV/Display HDMI TV/Display HDMI TV/Display HDMI TV/Display Blu-ray/PS4 Player Blu-ray/PS4 Player Cable Blu-ray/PS4 Player Blu-ray/PS4 Player HDMI IN OPTICAL /HDMI OUT USB POWER OUTPUT (5V/1A) SERVICE CONTROL RS232 IR IN DC 24V HDMI TV/Display Amplifier Active Speakers HDMI TV/Display HDMI TV/Display... -
Page 28: Specifications
8. SPECIFICATIONS 8.1 Technical Specification Video Bandwidth 18Gbps (600Mhz) Input Ports 4 x HDMI Control Interfaces 1 x IR In 1 x RS-232 1 x Service (USB) 1 x Control Output Ports 4 x HDMI 4 x USB port (5V/1A power supply) Supported Resolutions 480i~4K@24/50/60Hz 4K@50/60Hz... -
Page 29: Support Timing
8.2 Support Timing HDMI HDMI Input & output / Timing (Hz) Input Output 640x480@60/72/75/85 720x400@85 720x480p@59.94/60 720x576p@50 800x600@56/60/72/75/85 1024x768@60/70/75/85 1152x864@75 1280x720p@50/59.94/60 1280x768@60/75 1280x800@60RB/60 1280x960@60 1280x1024@60 1360x768@60 1366x768@60 1440x480i@59.94/60 1440x576i@50 1400x1050@60RB/60 1440x900@60RB/60 1600x900@60 1600x1200@60 1680x1050@60RB/60 1920x1080@60RB 1920x1080i@60 1920x1080p@23.97/24/25/29.97/30/59.94/60 3840x2160p@24/25/30 3840x2160@50/60(4:4:4)/50/60(4:2:0) 4096x2160p@24... -
Page 30: Hdmi Cable Length
8.3 HDMI Cable Length Timing Input Output 1080p 4k2k@30 4k2k@60 (certified HDMI cable) - Page 32 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-V4H4HP...
