Components
A
2x
1
This cart is designed to automatically charge and store 1-35 tablet, smart phone, and hand held devices safely
and effi ciently. Adjustable shelves customize shelf height in
2/3" (1.7 cm) increment to fi t a range of device heights; adjustable bays slide left to right to fi t even the largest
cases.
Please review this manual before installing your equipment to learn how to use the cart safely.The cart is listed to
IEC 60950-1 Information Technology Equipment safety standard, and IEC 62368-1 Audio/Video Information and
Communication Technology Equipment.
AC input: 220-240V~, 10A, 50/60-Hz.
For the latest User Installation Guide please visit: www.ergotron.com
English, Español, Français, Deutsch, Nederlands, Italiano, Svenska, 日本語, 汉语
888-83-086-G-00 rev. B • 05/20
YES 35 Charging Cart
For Tablets
Includes PowerShuttle
Technology
™
B
1x
1x
4mm
C
Safety ......................................................... 2-3
Features & Specifi cations .............................. 4
Set up ......................................................... 5-7
How to Adjust Bay Width ................................. 8
How to Adjust Shelf Height .............................. 9
Specifi cations ................................................ 10
Cleaning & Maintenance ............................... 11
Troubleshooting .......................................... 11
D
40x
1 of 12
Advertisement
Related Manuals for Ergotron YES 35
Summary of Contents for Ergotron YES 35
-
Page 1: Table Of Contents
Communication Technology Equipment. Cleaning & Maintenance ....... 11 Troubleshooting .......... 11 AC input: 220-240V~, 10A, 50/60-Hz. For the latest User Installation Guide please visit: www.ergotron.com English, Español, Français, Deutsch, Nederlands, Italiano, Svenska, 日本語, 汉语 1 of 12 888-83-086-G-00 rev. B • 05/20... -
Page 2: Safety
Never unplug this product from the outlet when your hands are wet. Do not use power cord to pull the cart. Ergotron does not accept any liability for damage if the unit is misused, incorrectly operated or inadequately repaired. Under these circumstances the warranty will be void. - Page 3 Safe Use Recommendations WARNING: Failure to observe the following Cart Use Safety notices may result in serious personal injury or equipment damage. WARNING: Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
-
Page 4: Features & Specifi Cations
Features & Specifi cations For added security, each door features hasps to hold your own padlock (maximum shackle dia 5/16" (0.8 cm); minimum shackle height 2" (5.1 cm)). When installed, your padlock restricts access to the handle so the unit can’t be opened. -
Page 5: Set Up
Open doors. 5 of 12 888-83-086-G-00 rev. B • 05/20... - Page 6 Route cables. 6 of 12 888-83-086-G-00 rev. B • 05/20...
- Page 7 Add the Bay labels to each Bay Plug in and insert devices. NOTE: ALL DEVICES MUST BE TURNED OFF BEFORE CHARGING. Failure to follow these instructions may result in overheating. To charge devices, plug in power cord and turn cart power on. 7 of 12 888-83-086-G-00 rev.
-
Page 8: How To Adjust Bay Width
How to Adjust Bay Width: Remove Divider Install Divider 8 of 12 888-83-086-G-00 rev. B • 05/20... -
Page 9: How To Adjust Shelf Height
How to Adjust Shelf Height: 9 of 12 888-83-086-G-00 rev. B • 05/20... -
Page 10: Specifi Cations
1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifi cations not expressly approved by Ergotron could void the user's authority to operate the equipment. Intended for institutional use. -
Page 11: Cleaning & Maintenance
Ergotron-approved documentation (i.e. installation instructions). Only Ergotron, Inc. or an Ergotron-certifi ed entity may adjust, service or replace Cart components. If any component on the Cart is missing or damaged, the Cart must not be used. Contact Ergotron immediately to request a replacement part. - Page 12 For Warranty visit: www.ergotron.com/warranty For Service visit: www.ergotron.com For local customer care phone numbers visit: http://contact.ergotron.com NOTE: When contacting customer service, reference the serial number. © 2015 Ergotron, Inc. All rights reserved. PowerShuttle is a registered trademark of Ergotron, Inc.
