- Page 1 Operator’s manual READ CAREFULLY CEA COSTRUZIONI ELETTROMECCANICHE ANNETTONI S.p.A. C.so E. Filiberto, 27 - 23900 Lecco - Italy Tel. ++39.0341.22322 - Fax ++39.0341.422646 Cas. Post. (P.O.BOX) 205 E-mail: cea@ceaweld.com - web: www.ceaweld.com...
-
Page 2: Table Of Contents
Maintenance Description The pointing out of any difficulties The PROJECT 1800 HF is the latest evolution of direct current and their elimination welding generators, using INVERTER technology. This power- ful generator, based on latest generation IGBT, can be used for Troubleshooting table TIG welding of all metals, excepting aluminium and its alloys. -
Page 3: Technical Data
“EARTH” connection. may be connected. PROJECT 1800 HF works with circuit breaker or fusible pow- er switches. Table 2 shows the recommended load values for retardant sup- Usage limits (IEC 60974-1) ply fuses. -
Page 4: Usage Norms
Usage norms CONTROL APPARATUS (Fig. A) Pos. 1 Supply switch. In the “O” position the welder is off. Pos. 2 Weld gas inlet coupling. Pos. 3 Welder cable. Pos. 4 Fast coupling TIG torch gas tube . Pos. 5 Fast coupling reverse polarity . Pos. -
Page 5: Mma Electrode Welding
PART TO BE WELDED The part to be welded must always be connected to earth in or- der to reduce electromagnetic emission. Much attention must be afforded so that the earth connection of the part to be weld- ed does not increase the risk of accident to the user or the risk of damage to other electric equipment. -
Page 6: Tig Welding
• With the machine switched off: TIG welding (Fig. D-E-F-G) - Connect the ground cable to the snap-on connector marked + (positive) (Pos. 5, Fig. A). In the TIG process welding is achieved by melting the two met- - Connect the relative ground clamp to the workpiece or al pieces to be joined, with the possible addition of material to the workpiece support in an area free of rust, paint, from the outside, using an arc ignited by a tungsten electrode. - Page 7 TIG WELDING WITH HIGH FREQUENCY STRIKING (HF) 8) Open the gas cylinder and flow regulator (8-14 l/min). 9) Put the electrode at the point at which welding is to begin, put the TIG torch at an angle so that the edge of the gas nozzle is not on top of the piece to be welded, keeping a 2-3 mm gap between the point of the electrode and the piece to be welded (Fig.
-
Page 8: Maintenance
Maintenance WARNING: Before doing any inspection of the inside of the generator, disconnect the equipment’s power supply and wait for about 5 minutes before working on the inside of the equip- ment, in order to allow the capacitative voltages to drop below the safe electric threshold. -
Page 9: Troubleshooting Table
Troubleshooting table Trouble Reasons Solution Turn on the power source, and fan The power light damaged or connection is not good Test and repair the inside circuit of power light works, but the power light is not on The transformer of power is broken Repair or change the transformer Control PCB failures Repair or change the control PCB... -
Page 10: Meaning Of Graphic Symbols On Machine
Meaning of graphic symbols on machine Power supply switch Fast coupling TIG torch gas tube MMA welding Positive pole snap-in connector TIG welding Negative pole snap-in connector 4 strokes TIG welding Grounding 2 strokes TIG welding Danger! High voltage TIG welding SLOPE DOWN time Warning! System for use in environments with in- MMA ELECTRODE welding ARC FORCE... -
Page 11: Wiring Diagram
Wiring diagram... - Page 12 Reservedelliste LES NØYE ПЕРЕД НАЧАЛОМ РАБОТЫ Список запасных частей ВНИМАТЕЛЬНО ПРОЧТИТЕ ИНСТРУКЦИЮ CEA COSTRUZIONI ELETTROMECCANICHE ANNETTONI S.p.A. C.so E. Filiberto, 27 - 23900 Lecco - Italy Tel. ++39.0341.22322 - Fax ++39.0341.422646 Cas. Post. (P.O.BOX) 205 E-mail: cea@ceaweld.com - web: www.ceaweld.com...
- Page 13 6 poles torch switch connection 352380 Pannello frontale Front panel 235945 Cavo linea Main cable 352379 Pannello posteriore Rear panel 435365 Interruttore alimentazione Main switch 485040 Tubo del gas Gas hose 468704 Adesivo logo CEA CEA logo sticker 420593 Coperchio Steel cover...
- Page 14 Pos. Cod. Descrizione Description 241268 Assieme gruppo inverter Inverter assembly pcb 444504 Ventilatore 404907 Basamento Steel base 377188 Scheda controllo MCU control pcb 455500 Raddrizzatore primario Primary rectifier 353056 Isolamento laterale coperchio Cover insulation...
- Page 15 Pos. Cod. Descrizione Description 425938 Elettrovalvola del gas Solenoid valve 377189 Scheda rack frontale Rack pcb 240248 Induttore Inductor 481417 Trasformatore HF HF transformer 481949 Trasformatore di corrente Hall current transformer 481444 Trasformatore principale Main transformer 478777 Termostato Thermostat...
- Page 16 4) O número de matrícula da própria máquina de soldar EXAMPLE EXEMPLO N. 2 pieces code n. 425938 - for PROJECT 1800 HF - 230 V - N° 2 peças código n. 425938 - para o equipamento PROJECT 50/60 Hz - Serial number ............
- Page 17 CEA COSTRUZIONI ELETTROMECCANICHE ANNETTONI S.p.A. C.so E. Filiberto, 27 - 23900 LECCO - ITALY Cas. Post. (P.O. BOX) 205 Tel. +39 0341 22322 - Fax +39 0341 422646 cea@ceaweld.com www.ceaweld.com ISO 9001: 2008...
