Page 1: Benching Application
DOCUMENT VERSION 1.0 | JANUARY 2020 DYNAMIC MOTION system CONFIGURATION Handbook... - Page 2 LOGICDATA Electronic & Software Entwicklungs GmbH Wirtschaftspark 18 8530 Deutschlandsberg Austria Phone: +43 (0) 3462 51 98 0 Fax: +43 (0) 3462 51 98 1030 Internet: http://www.logicdata.net Email: office.at@logicdata.net INFO This manual is valid for all configurations of the DYNAMIC MOTION system...
-
Page 3: Table Of Contents
DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 3 CONTENTS General information Other applicable documents Copyright Royalty-free use of images and text Trademarks Safety Target audience General safety regulations and obligations Intended use Reasonably foreseeable misuse Explanation of symbols and signal words... - Page 4 DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 4 Connecting Cables Approved Standard Table Systems 5.4.1 Standard Application 1 Approved Benching Systems 5.5.1 Benching Application 1 Approved Conference Applications 5.6.1 Benching Application 1 Approved Conference Applications Changing the table system Replacing an Actuator 6.1.1 Unplugging the Cable from the Actuator...
-
Page 5: General Information
No part of the text and no image may be used without the prior written consent of LOGICDATA. Texts and images may not be sold in their current state, and may not be published or sublicensed digitally. -
Page 6: Safety
In general, the following safety regulations and obligations apply when handling the product: • Do not operate the DYNAMIC MOTION system unless it is in a clean and perfect condition • Do not remove, change, bridge, or bypass any protection, safety, or monitoring equipment •... -
Page 7: Explanation Of Symbols And Signal Words
2.6 LIABILITY LOGICDATA products comply with all relevant industry standards, which are listed in the product's data- sheet. However, risk can result from incorrect operation or misuse. LOGICDATA is in particular not liable for damage or injury caused by: • Improper product use •... -
Page 8: Residual Risks
Table System are detailed in the respective product’s Operating Manual. The risks associated with operating the Table System are detailed in the DYNAMIC MOTION system Manual. See also Chapter 1.1 Other Applicable Documents on page 5. The symbols and signal words used in this Operating Manual are listed in Chapter 2.5 Explanation of Symbols and Signal Words on page 7. -
Page 9: Skilled Persons
Is authorized for installation planning, installation, commissioning, or maintenance/servicing of the product • Has read and understood all DYNAMIC MOTION system documentation and the documentation for other connected products. • Has the technical education, training, and/or experience to perceive risks and avoid hazards •... -
Page 10: Component Overview
Actuators take power from the Power Unit in order to rotate a spindle that moves the table up or down. There are two main categories of Actuator in the DYNAMIC MOTION system: Drives (in which the spindle is per- manently attached to the motor) and Gear Motors (no spindle attached). DYNAMIC MOTION actuators also feature an integrated Control Unit. -
Page 11: Power Units
4.2 POWER UNITS 4.2.1 WHAT IS A POWER UNIT? A Power Unit is a general term that covers DYNAMIC MOTION Power Hubs and all DYNAMIC MOTION- compatible external power supplies. The assembly process differs slightly depending on which type of Power Unit will be installed. -
Page 12: User Interfaces
DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 12 4.3 USER INTERFACES 4.3.1 WHAT IS A USER INTERFACE? A User Interface is a general term that covers Handsets (Basic, Comfort, Paddle) and other products that can control the System, e.g. LOGIClink. Assembly and Operation differ depending on which type of User Interface will be installed. -
Page 13: Cables
DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 13 4.4 CABLES 4.4.1 CONNECTOR TYPES DYNAMIC MOTION DYNAMIC MOTION DYNAMIC MOTION EXTERNAL SENSOR standard motor accessory adapter Connector Type: 3-Pin, Connector Type: 4-Pin Straight Connector Type: 10-Pin Connector Type: 3-Pin Connects to: Power... - Page 14 DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 14 Name and Order Code Key Features Image • Length: 1000 mm Extension Cable • Connector A: 1 x 4-pin • Connector B: 1 x 4-pin DMLIN-EXT-1000 • Application: Extension Cable • Length: 100 mm •...
-
Page 15: Connecting Your System
(Actuator, User Interface, Power Hub, etc.) for that product’s mounting instructions. The configurations listed in this section are those tested and released by LOGICDATA. For al- ternative configuratons, contact LOGICDATA for further details. -
Page 16: Technical Requirements
• The Height-Adjustable Columns have been mounted correctly onto the Table Top • The DYNAMIC MOTION system will be connected at a voltage compliant with the Type Plate • There is no residual voltage on any parts 5.3 CONNECTING CABLES... -
Page 17: Approved Standard Table Systems
DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 17 5.4 APPROVED STANDARD TABLE SYSTEMS This chapter describes assembly for Standard Table Systems (see Chapter 5.1). 5.4.1 STANDARD APPLICATION 1 This system creates: 2-leg table with a single Power Hub (DMP240) -
Page 18: Approved Benching Systems
The Table Top and Height-Adjustable Columns are supplied by the Reseller. Only one type of DYNAMIC MOTION Actuator can be used per Table within the Benching System. Multiple types of Actuator can be used in the system (e.g. -
Page 19: Approved Conference Applications
DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 19 5.6 APPROVED CONFERENCE APPLICATIONS This section describes assembly for DYNAMIC MOTION systems with multiple Power Hubs (Conference Applications). This configuration can adjust heavy or oversized tables, without affecting performance. The system consists of groups of Actuators. Each Power Hub powers one group of Actuators. Groups are connect- ed by Sync Cables. -
Page 20: Approved Conference Applications
Position Reset Procedure for Table Systems controlled by a Handset with an UP Key and DOWN Key (Comfort or Basic Handsets). If your DYNAMIC MOTION system is operated by a different User Interface, consult that product’s operating Manual for instructions on performing a Position Reset Procedure. -
Page 21: Changing The Table System
DYNAMIC MOTION SYSTEM - CONFIGURATION HANDBOOK // PAGE 21 6 CHANGING THE TABLE SYSTEM REPLACING AN ACTUATOR Disconnect the Power Hub from the Mains Disconnect the Actuator from the Power Hub (If necessary) Disconnect the Acuator Cable using the instructions in Chapter 6.1.1... -
Page 22: Additional Information
Instructions for operating the system can be found in the DYNAMIC MOTION system Manual. 7.2 DISASSEMBLY To disassemble the DYNAMIC MOTION system, unplug the Power Hub at the mains, then disconnect all ca- bles from the Power Hub. Then, follow the assembly instructions for your chosen product in reverse order. - Page 23 LOGICDATA LOGICDATA North America, Inc. Broadmoor Ave SE Electronic & Software Entwicklungs GmbH Suite D Wirtschaftspark 18 Grand Rapids 8530 Deutschlandsberg MI, USA, Austria Phone: +43 (0)3462 5198 0 Phone: +1 (616) 328 8841 Fax: +43 (0)3462 5198 1030 Email: office.na@logicdata.net...
