Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Floodlight
FLB141 #2 LED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF FLB141 2 LED
Summary of Contents for WE-EF FLB141 2 LED
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Floodlight FLB141 #2 LED Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards.
- Page 2 Floodlight FLB141 #2 IP66, IK08. Class I. ta = 40°C Weight for FLB141 #2 LED Windage area m² for FLB141 #2 LED 0.0506 Orientation: all directions...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out by a suitably quali ed and trained professional. -
Page 4: Installation
Installation The product must be installed and maintained by a suitably quali ed professional in compliance with latest building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: If the luminaire is modi ed by anybody other than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. -
Page 5: Installation Procedure
Installation Procedure 1) Switch off mains electrical supply. 2) Check that rating shown on luminaire label conforms with mains electrical supply. 07/18 IP66 FLB141-LED 220-240V50-60/Hz 161-XXXX SOE XXXXXXX LED 3000K 18W item no. XXX (example) 3) Remove mounting ange A by loosening 4) Determine position for xing screws D. - Page 6 5) Feed mains supply cable G through the pres- 6) Connect mains supply cable G leads to sure screw I, while setting mounting ange A respective terminals in terminal connector C: in position. To x mounting ange A, insert and a) ON/OFF (L = Phase, N = Neutral, tighten screws D.
- Page 7 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com TO9249W0519 © WE-EF 2019 Technical speci cations are subject to change.
