Firmware model changing on GCC cutting plotter
Can only way by USB port.
QC Loader file choose rule
M/B base
Puma II, Expert
24/LX, Bengal
Puma II Plus/Puma
III, Expert Pro
Jaguar II/III/IV,
Vogue
LCM TYPE
For example:
Jaguar IV (LCM) to Puma II (NO LCM).
Step1.
Connector PC with Jaguar IV by USB cable, on Jaguar IV press "Pause" key (hold) then turn on
nachine entrance to USB update procedure.
2 in 1 main board
LCM
LCM
V
V
V
V
QC Loader file
NO LCM
V
NO LCM TYPE
Advertisement
Table of Contents
Related Manuals for GCC Technologies Puma II
Summary of Contents for GCC Technologies Puma II
- Page 1 LCM TYPE NO LCM TYPE For example: Jaguar IV (LCM) to Puma II (NO LCM). Step1. Connector PC with Jaguar IV by USB cable, on Jaguar IV press “Pause” key (hold) then turn on nachine entrance to USB update procedure.
- Page 2 Step2. Use Uploader Browse the file “QCLoader_LCM”, select USB then press Start. (If NO LCM machine, please Browse “QCLoader_NO_LCM” in this step) Step3. After file translation finished, make sure no any action on panel please wait 3 minute later then turn off machine.
