TABLE OF CONTENTS

Introduction ......................................
CHAPTER 1 SETTING UP THE PRINTER
Unpacking ..............................................................
Connecting Cable...................................................
Installing or Replacing the Paper Roll ....................
Adjustments and Settings ......................................
Using the Printer ....................................................
CHAPTER 2 THE SELF TEST
The Self Test ..........................................................
CHAPTER 3 REFERENCE INFORMATION
Printing Specifications...........................................
Paper Specifications .............................................
Electrical Characteristics.......................................
Environmental Conditions .....................................
CHAPTER 4 TROUBLESHOOTING
General problems .................................................
Printing problems ..................................................
Cleaning the print head.........................................
Auto cutter problems.............................................
Hexadecimal Dump....................................................
APPENDIXES
Appendix A
DIP Switch and Paper Near End Settings.............
Appendix B
Connectors............................................................
iii
1-1
1-2
1-5
1-8
1-9
2-1
3-1
3-3
3-3
3-4
4-1
4-1
4-3
4-4
4-6
A-1
A-7
MU04001A
ii

1. INTRODUCTION

TM200 series printers are high-quality POS printers are designed for use
with electronic instruments such as system ECR, POS, banking
equipment, computer peripheral equipments.
The printers have the following features:
Printing
High-speed printing: 180 mm/sec, 60 lines /sec maximum.
Low-noise thermal printing.
Application Software
Command protocol is based on the ESC / POS standard.
Various layouts are possible by using page mode.
Characters can be scaled up to 4 times as large as standard size.
Bar code printing is possible by using a bar code command. i.e. Bar
codes can be printed both in vertical direction, and in the horizontal
direction.
Repeated operations and copy printing are possible by using macro
definitions.
Character font size (12 x 24 font or 9 x 17 font) can be selected
using a command.
