Chapter 3. Reference Information

Printing Specifications

Printing method: Thermal line printing
Dot density: 203 dpi x 203 dpi (8 dot/mm)
Printing direction: Unidirectional with friction feed
Printing width: 72mm (2.83"), 576 dot positions
Characters per line 48 (Font A)
(default): 64 (Font B)
Character spacing (default): 0.28 mm (0.1") (2 dots) (Font A)
(.01") (2 dots) (Font B) Programmable by control
command.
Printing speed --
180 mm / sec (approxi. 7.0" / sec)
60 lines / sec (computed value for 3.18mm (1/8")
High-speed mode:
feed)
28.4 lines / sec maximum
(4.23 mm (1/6") feed,
at 24V, 28 。 C (82 。 F), density level 2)
Paper feeding speed: Approximately 180 mm / sec (7.0"/sec)
continuous paper feeding
Receive Buffer Size 80K Bytes
Number of characters:
Alphanumeric characters: 95
International characters: 32
Extended graphics: 128x7pages
(including one space page)
Traditional/ Simplified Chinese, Japanese, Kanji
characters
Character structure:
Font A: 12 x 24 (including 2-dot
spacing horizontally)
Font B: 9 x 17 (including 2-dot spacing
horizontally)
Kanji: 24 x 24
Default font: Font A
0.28mm
3-1
Standard
W x H (mm) CPL
Font A 1.23 x 2.97
12 x 24 (.05" x .11")
Font B 0.87 x 2.10
9 x 17 (.035" x .08")
Kanji 2.97 x 2.97
24 x 24 (.11" x .11")
Double-width
W x H (mm) CPL
Font A 2.47 x 2.97
12 x 24 (.10" x .11")
Font B 1.73 x 2.10
9 x 17 (.07" x .08")
Kanji 5.92 x 2.97
24 x 24 (.24" x .11")
* CPL = Characters Per Line
* Space between characters is not included
* Characters can be scaled up to 64 times as large as the standard sizes.
Double-height
W x H (mm) CPL
1.23 x 5.92
48 48
(.05" x .24")
0.87 x 4.20
64 64
(.035" x .17")
2.97 x 5.92
24 24
(.11" x .24")
Double-weight/ Double-height
W x H (mm) CPL
2.47 x5.92
24 24
(.10" x .24)
1.73 x 4.20
32 32
(.07" x .17")
5.92 x 5.92
12 12
(.24" x .24")
3-2
